Shanxi Jurun Technology Co., Ltd., a trusted manufacturer based in Taiyuan, China, specializes in producing premium Electrical Pure Iron Cold Rolled Coils. Our 0.35mm thickness coils deliver exceptional magnetic performance for critical electromagnetic applications, ensuring reliability in demanding industrial environments. With rigorous quality control from our Shanxi facility, we provide material solutions that meet precise technical specifications while optimizing energy efficiency in end products.
Core Features & Technical Advantages:
- Superior Magnetic Properties: Exhibits high magnetic permeability (up to 12,000 μ) and low coercive force (≤80 A/m), reducing energy loss in electromagnetic devices.
- Precision Thickness Control: Maintains consistent 0.35mm ±0.02mm tolerance across coils for uniform performance in layered components.
- Low Impurity Content: Carbon ≤ 0.003%, Sulfur ≤ 0.003%, and Phosphorus ≤ 0.015% ensure minimal eddy current losses.
- Customizable Dimensions: Available in widths ranging from 800mm to 1200mm with coil weights up to 8 metric tons.
Technical Specifications:
| Parameter | Value | Test Standard |
|---|---|---|
| Yield Strength | ≥ 180 MPa | ASTM E8 |
| Coercive Force | ≤ 80 A/m | IEC 60404-4 |
| Surface Roughness (Ra) | ≤ 0.8 μm | ISO 4287 |
| Density | 7.85 g/cm³ | ASTM B311 |
Industrial Applications:
- Transformers & inductors requiring minimal hysteresis loss
- Precision relays and solenoids in automation systems
- Magnetic shielding for sensitive medical equipment
- DC motor cores and generator components
Manufacturing Excellence: Shanxi Jurun Technology employs advanced cold rolling mills with automatic gauge control (AGC) systems, ensuring dimensional accuracy and surface integrity. Our production process includes:
- Vacuum degassing for impurity reduction
- Continuous annealing under hydrogen atmosphere
- In-line eddy current testing for defect detection
Trusted Industrial Partner: Operating from China's steel manufacturing hub in Shanxi Province, we leverage regional material expertise to deliver products with:
- Consistent batch-to-batch magnetic properties
- Traceable material certifications
- Custom slitting and packaging solutions
FAQ Section
Q1: What is the maximum coil width available?
A: Standard widths range from 800-1200mm, with custom widths available upon request.
Q2: Does this material require annealing after punching?
A: Our coils are supplied in fully annealed condition, ready for stamping without additional heat treatment.
Q3: What surface protection is provided?
A: We apply rust preventive oil (RPO) meeting ASTM D665 standards, with VCI paper wrapping optional.
Q4: Can you provide material certification?
A: Yes, mill test certificates including chemical composition and magnetic properties are supplied with each shipment.
Q5: What is the lead time for 20-ton orders?
A: Standard orders ship within 15 working days; expedited production available.
Q6: How does thickness tolerance affect electromagnetic performance?
A: Our ±0.02mm tolerance ensures uniform flux distribution, reducing hotspot formation in laminated cores.
Final Assurance: Shanxi Jurun Technology combines regional manufacturing capabilities with strict adherence to international material standards. Our Electrical Pure Iron coils undergo 12 quality checkpoints before shipment, guaranteeing performance in high-frequency applications. Contact our Taiyuan technical team for customized specifications or sample requests – let us power your precision electromagnetic solutions.
