Shanghai Quanbao Electronic Materials Technology Co., Ltd., a trusted manufacturer based in Shanghai, China, presents our premium Corrosion-Resistant Sanitary Tee Fitting engineered for demanding dairy processing environments. This ISO 2852-compliant fitting delivers exceptional hygiene and durability through advanced 316L stainless steel construction and full CIP/SIP compatibility, ensuring zero contamination risk in critical fluid transfer applications.
Our tee fitting features precision-engineered contours that eliminate dead zones where bacteria could proliferate, while the electropolished surface minimizes adhesion of dairy residues. The tri-clamp connection system enables rapid installation and dismantling for maintenance, reducing downtime during production cycles. With a pressure rating of 10 bar at 120°C, it reliably handles high-temperature cleaning protocols common in modern dairy plants.
Technical Specifications & Performance Advantages:
- Material Integrity: 316L stainless steel with 2.5% molybdenum content provides superior pitting resistance against acidic dairy byproducts like whey and lactic acid.
- Flow Optimization: Internal radius matching pipe ID ensures turbulent-free flow for viscosity-sensitive products (e.g., cream, yogurt).
- Thermal Resilience: Maintains structural stability across 130°C SIP cycles and cryogenic conditions (-10°C) during chilled product transfer.
- Certified Compatibility: Meets 3-A Sanitary Standards (Optional certification available upon request).
| Size (DN) | Dimensions (mm) | Weight (g) | Clamp Size |
|---|---|---|---|
| 15 | Ø35.1 x 76H | 220 | 1" |
| 25 | Ø42.4 x 89H | 380 | 1.5" |
| 50 | Ø69.9 x 130H | 1050 | 3" |
| 100 | Ø114.3 x 180H | 2850 | 6" |
Operational Benefits:
- Hygienic Design: Exceeds EHEDG guidelines with continuous internal surfaces and 100% drainability
- Cost Efficiency: 50% longer service life than 304SS fittings in chloride-rich dairy environments
- Compliance Ready: Documentation package includes material certificates and traceability data
As an ISO 9001-certified manufacturer (certificate available upon request), Shanghai Quanbao leverages Shanghai’s advanced manufacturing infrastructure to deliver consistent quality. Our fittings undergo 3-stage quality verification: material spectrometry, dimensional laser scanning, and pressure testing – ensuring every tee meets pharmaceutical-grade requirements. Partner with us for technical support including system layout optimization and validation documentation assistance.
FAQ Section:
-
Q: Are these fittings suitable for ultra-high-temperature (UHT) milk processing?
A: Yes, the 316L construction maintains integrity during 140°C sterilization cycles common in UHT operations. -
Q: Can I integrate these with existing DIN 32676 clamps?
A: Absolutely. Our ISO 2852 tees are dimensionally compatible with DIN and SMS clamp systems. -
Q: What documentation accompanies shipments?
A: Each batch includes material test reports (MTRs), certificate of conformity, and surface roughness certification. -
Q: Do you provide custom orientations for branch connections?
A: Yes, 45° and 22.5° angled tees can be manufactured with 4-week lead time. -
Q: How do these compare to polymer tees for caustic cleaning?
A: 316L offers superior resistance to NaOH solutions exceeding 5% concentration at 80°C. -
Q: What gasket material is recommended for dairy applications?
A: We recommend FDA-grade EPDM or silicone gaskets for optimal sealing performance.
