Help CenterABB PE1315A – Procontrol P13 I/O Interface Module for Reliable Binary Signal Handling
Related Products
-
ABB PFTL201C-10kN Pressductor Strip Force Transducer – Reliable, Drift‑resistant Tension Measurement for Rolling and Processing LinesUS$ 2560.00MOQ: 1 Blade -
ABB PFTL101A-0.5KN Pressductor Load Cell for Precise Web Tension on Narrow RollsUS$ 2560.00MOQ: 1 Blade
-
ABB PFXA 401F – Force/Tension Measurement Electronics for Pressductor-based SystemsUS$ 2560.00MOQ: 1 Blade
-
ABB PIO800K02 – Accessory Kit for PIO800 Interface in System 800xA/S800 I/OUS$ 2560.00MOQ: 1 Blade
-
ABB PM564-RP-ETH – Compact AC500-eCo CPU With Integrated Ethernet for Machine and Process ControlUS$ 2560.00MOQ: 1 Blade
Company's Order Placement Process and Guarantees
- Warranty period: 365 days
- Delivery time: 1 week for in-stock; no more than one month at the latest
- Payment: 50% advance payment; full payment prior to delivery
- Express delivery methods: FedEx, UPS, DHL
One thing I appreciate is the straightforward swap procedure—most teams can replace the module in minutes, then verify signals at the front test points and terminal unit without disrupting adjacent cards.
Key Features
Procontrol P13 rack compatibility – Designed for the P13 system backplane, enabling quick plug-in replacement and fast commissioning.
Binary signal interfacing – Typically used for on/off (discrete) field signals common in power plant protection and interlock schemes.
Stable power via backplane – Module power is supplied from the P13 rack; no local power brick to manage in most cases.
Service-friendly diagnostics – You might notice front indicators and test points that make loop checks and troubleshooting straightforward.
Rugged build for legacy fleets – Suited for high-availability environments; typically handles the 0–55°C cabinet range found in utilities and heavy industry.
Predictable lifecycle behavior – Proven component set, which in many cases translates to fewer nuisance trips and easier MRO planning.
Technical Specifications
| Brand / Model | ABB PE1315A (Procontrol P13 series) |
| HS Code | 8538.90 |
| Power Requirements | Supplied via Procontrol P13 backplane; typical consumption <5 W |
| Dimensions & Weight | Standard P13 6U plug-in module; approx. 220 mm depth; weight typically <0.6 kg |
| Operating Temperature | 0 to +55 °C (cabinet ambient; typical for P13 modules) |
| Signal Input/Output Types | Binary field signals via terminal unit; commonly 24 VDC variants exist (exact channel type depends on sub-variant) |
| Communication Interfaces | Procontrol P13 system bus via backplane; no user serial/Ethernet on the front panel |
| Installation Method | Plug-in module for P13 rack; field wiring through associated terminal units; front-panel retention with standard P13 hardware |
Note: Channel count and exact input/output rating can vary by sub-variant within the PE13xx family. If you share the cabinet tag or slot assignment, we can match the precise signal type before shipment.
Related or Supporting Products
ABB PE1320A / PE1321A – Closely related P13 binary I/O modules. Typically differ by channel direction (input vs. output) and field voltage options.
ABB PE1325A / PE133xA series – Alternative PE13xx modules used where different channel counts or isolation schemes are needed.
P13 Terminal Units – Matching terminal bases for field wiring. Using the correct terminal unit avoids nuisance faults and makes FAT/SAT faster.
P13 Rack & Power Supply – Standard P13 subrack and power modules; ensure adequate backplane power margin when adding or swapping cards.
A utilities customer recently swapped a PE13xx card in a condenser vacuum interlock chain; they mentioned the like-for-like fit and quick status verification cut their outage task time in half. That’s fairly typical with P13 spares when the cabinet is well-documented.
Installation & Maintenance
Environment – Install in a clean, dry P13 cabinet with stable ventilation. Keep ambient within 0–55 °C and avoid direct hot air from blowers on the card face.
Wiring – De-energize the circuit before handling. Land field wires on the designated terminal unit; maintain shield continuity and segregate DI/DO wiring from high-noise power cables.
Slotting – Insert into the assigned rack position. You might notice the backplane connector seats positively; tighten the front retaining screws to avoid vibration-related intermittency.
Commissioning – Perform loop checks and verify front indicators (where provided). For safety loops, simulate signals with a controlled source rather than live process states.
Routine care – Quarterly dust removal with dry air, visual inspection for contact wear, and torque check on terminal screws. Binary cards typically don’t need calibration; just schedule functional checks.
Spares strategy – Keep at least one identical hardware revision per cabinet section. In most cases, firmware on these legacy modules isn’t field-upgradable, so matching HW/REV makes replacements seamless.
Quality & Certifications
Manufactured by ABB under ISO 9001 quality systems.
CE conformity applicable to the Procontrol P13 family where certified; RoHS may not apply to legacy modules.
Each unit is functionally tested prior to dispatch, with a 365-day warranty.
Need help verifying the exact PE1315A variant?
Share the cabinet drawing, rack position, and field voltage (e.g., 24 VDC or 48 VDC). We’ll match the correct hardware so your swap is smooth on the first attempt.
