Help CenterABB PIO800K02 – Accessory Kit for PIO800 Interface in System 800xA/S800 I/O
Related Products
-
ABB PM564-RP-ETH – Compact AC500-eCo CPU With Integrated Ethernet for Machine and Process ControlUS$ 2560.00MOQ: 1 Blade -
ABB PM583-ETH – Mid-range AC500 CPU With Integrated Ethernet for Reliable Machine and Plant ControlUS$ 2560.00MOQ: 1 Blade
-
ABB PM595-4ETH-F – High‑performance AC500 CPU With Quad Ethernet for Fast, Connected ControlUS$ 2560.00MOQ: 1 Blade
-
ABB 3BSE010537R1 – S800 I/O Spare for AC 800M DCS Expansion and MaintenanceUS$ 2560.00MOQ: 1 Blade
-
ABB 3BDS005799R1 – OEM Control Board for ABB DCS/800xA Platforms, Like‑for‑Like ReplacementUS$ 2560.00MOQ: 1 Blade
Company's Order Placement Process and Guarantees
- Warranty: 365 days from delivery
- Lead time: 1 week if in stock; no more than one month at the latest
- Payment terms: 50% advance payment; full payment prior to delivery
- Express options: FedEx, UPS, DHL
Key Features
Purpose-built for ABB PIO800 interface – Ensures the right mechanical fit and connector accessories for fast, error‑free installation.
Speeds panel integration – Predefined mounting and coding parts typically cut installation time and reduce rework.
Consistent with ABB cabinet practices – Hardware aligns with standard S800 I/O rail/base layouts used in System 800xA.
Passive, no additional power – The kit contains mechanical/connection items only, so there’s nothing to power or configure.
Helps maintain long-term reliability – Correct fasteners and coding keys prevent loose seating and wiring mistakes in many cases.
Supports retrofit and expansions – Handy when you’re extending an existing 800xA node or replacing a PIO800 during maintenance.
Technical Specifications
| Brand / Model | ABB PIO800K02 |
| Product Type | Accessory/installation kit for PIO800 interface module within System 800xA / S800 I/O |
| Compatibility | PIO800 interface hardware; typically used in ABB S800 I/O stations and 800xA nodes |
| HS Code | 8538.90 |
| Power Requirements | None (passive kit; host PIO800 module powered separately) |
| Operating Temperature | Follows host system rating; suitable for standard industrial control cabinets |
| Signal Input/Output | Not applicable (no active I/O channels; interfaces are provided by the PIO800 module) |
| Communication Interfaces | Not applicable to kit; communication handled by the host PIO800 interface |
| Installation Method | Supports DIN-rail/S800 I/O base mounting; follows ABB 800xA cabinet wiring practices |
| Typical Kit Contents | Mounting hardware and coding/connection accessories for PIO800; refer to ABB packing list for K02 contents |
Related or Supporting Products
ABB PIO800 – The host interface module this kit supports; provides the actual field/network connectivity.
ABB S800 I/O base units (e.g., TU810/TU812/TU814) – Common base units used to mount and connect S800 modules in 800xA cabinets.
ABB CI854A – PROFIBUS DP-V1 communication interface often paired with S800 I/O in System 800xA architectures.
ABB AC 800M controllers (e.g., PM861/PM865) – Main controller platform that supervises S800 I/O nodes.
Installation & Maintenance
Cabinet environment – Install within a clean, ventilated control cabinet. You might notice that keeping ambient within the host module’s rating typically improves long‑term reliability.
Mounting – Follow ABB S800 I/O rail/base layout. Ensure all fasteners are snug (hand‑tight, no over‑torque) and that coding keys are inserted as instructed to prevent mis‑slotting.
Wiring – Separate signal and power cabling; maintain shield terminations and grounding consistent with ABB 800xA grounding practice. Avoid running I/O signals parallel to high‑voltage feeders.
Safety – De‑energize the cabinet before installing hardware. Verify ESD protection when handling modules and accessories.
Routine checks – Inspect mechanical tightness during scheduled outages. For dust‑prone sites, a gentle clean (dry, non‑abrasive) helps. No firmware applies to this kit, but keep the host PIO800 firmware current when recommended by ABB.
Quality & Certifications
CE conformity for use within ABB System 800xA assemblies
RoHS and REACH compliant materials, in most cases for ABB accessory kits
UL recognition at the assembly level when integrated per ABB instructions
Manufactured under ISO 9001 quality systems
Manufacturer’s warranty: 12 months (365 days)
One thing I appreciate is how these ABB accessory kits remove uncertainty during commissioning—less time hunting for the “right” mounting bits and more time bringing the node online. If you’re matching an existing 800xA footprint, this K02 kit is, in many cases, the pragmatic choice.
