1. Overview

The intelligent temperature and humidity controller adopts multiple high - tech technologies such as microprocessor technology, sensor technology, and communication technology to measure, comprehensively control, and alarm the temperature and humidity of the measured environment. It uses a single - chip microcomputer as the control core and has digital display and key setting functions. It is mainly used for temperature, humidity, and anti - condensation protection of power switchgear, terminal boxes, transformers, box - type substations, and other equipment to ensure the safe and reliable operation of power equipment.

2. Main Functions

It can measure and control single - channel or multi - channel temperature and humidity signals and display the data in digital form. At the same time, it can communicate with the upper - computer, transmit all monitored states to the upper - computer in real - time, and all set values can be modified through the upper - computer to achieve the purpose of remote monitoring. This product is suitable for anti - condensation protection and environmental protection of various high - and low - voltage switchgear and box - type substations.

This product adopts panel - type installation.

3. Technical Indicators

1. Display: Four - digit LED digital display, 5 light - emitting diode indicators.

2. Power supply: AC220V±15%    50Hz/60Hz

3. Operating environment: Temperature - 20℃～70℃  Relative humidity

4. Temperature measurement range: -40℃～100℃

5. Humidity measurement range: 0%RH～99%RH

6. Control accuracy: Temperature ±1℃    Humidity ±5%RH

7. Max power consumption: ≤3W

8. Load contacts: AC220V, 5A (normally open, passive)

9. Alarm indication: The alarm indicator on the panel indicates the load fault status

10. Remote transmission interface: RS485 communication/one - way 4～20mA analog transmission output (choose one)

11. Reliability and safety: Meet the requirements of GB/T14598.13, GB/T14598.14, GB/T14598.9, and GB/T14598.10.

12. Overall dimensions: 96×48×113 (mm)

13. Cut - out dimensions: 91×45 (mm)
