As a leading manufacturer with ISO9001 and ISO14000 certifications, Shanxi Pano Building Materials leverages our 30,000-50,000 sqm production facility to deliver premium calcium silicate solutions. Our medium-density ceiling boards combine exceptional acoustic performance with structural reliability—engineered for architects and contractors seeking noise-controlled environments without compromising durability.
Core Technical Advantages:
Acoustic Excellence - Micro-porous structure absorbs 70-85% of ambient noise (tested per ASTM C423)
Precision Engineering - Density optimized at 650-750kg/m³ for balanced strength and weight
Environmental Resilience - Withstands 95% relative humidity and temperatures from -20°C to 600°C
Performance Specifications:
| Parameter | Standard Value | Custom Options |
|---|---|---|
| Thickness | 12mm, 15mm, 20mm | 8-25mm upon request |
| Panel Size | 595x595mm, 603x603mm | Max. 1200x2400mm |
| NRC Rating | 0.75-0.90 | Up to 0.95 achievable |
| Thermal Conductivity | 0.065 W/(m·K) | N/A |
Installation & Maintenance Benefits:
Seamless integration with standard T-grid systems (exposed/concealed)
Pre-drilled edge details reduce on-site labor by 30% versus conventional boards
Non-combustible composition meets ASTM E84 Class A fire standards
Mold-resistant surface accepts all latex paints for touch-ups
With over US$2.5 million annual exports to 40+ countries including North America and Western Europe, our factory’s 200+ technicians ensure batch-to-batch consistency. Each shipment undergoes triple quality checks before leaving Tianjin/Qingdao ports. Partner with us for LEED-contributing solutions that transform airports, hospitals, and educational facilities into acoustically optimized spaces. Request third-party test reports to verify performance claims.
FAQ Section:
Q: Can these boards be used in food processing plants?
A: Yes, the non-organic composition resists bacterial growth and meets FDA CFR 21 compliance for incidental contact.Q: What suspension systems do they support?
A: Compatible with Armstrong, USG, and standard 15/16" T-grids. Clip-on installation available.Q: How do they compare to mineral fiber ceilings?
A: Higher impact resistance (8J vs 3J) and 30% better moisture tolerance while matching acoustic performance.Q: Are custom edge profiles available?
A: Square, tegular, or beveled edges can be factory-cut. Provide CAD drawings for special shapes.Q: What’s the lead time for 2,000 sqm orders?
A: Standard items ship in 15 days. Custom projects require 25-30 days production.Q: Do you provide acoustic test data?
A: Yes, NRC and SAC reports from CNAS-accredited labs are available digitally.
