Xihua Crystal Oscillator XTL721-S999-328 SMD Clock Crystal Oscillator

Package Dimensions: 3215/2012/1610

Common Frequency Points: 32.768KHz

Temperature Range: -40℃~85℃/-40℃~105℃/-40℃~125℃

Typical Applications: Laptops, Mobile Phones, Wearable Devices, Smart Meters, etc.

Product Features: Ultra-small Size, Low Standby Power Consumption, High Precision

Production Equipment: German Imported Lithography Machine

Product Features and Applications: Small Size, High Stability and Reliability, Low Equivalent Resistance, Can be Widely Used in Industrial Electronic Equipment and Instruments. The sales team of Hefei Minghua Shang Electronics Co., Ltd. has been deeply involved in the crystal oscillator industry for more than twenty years, providing comprehensive solutions and technical support for crystal oscillators. At the same time, it provides frequency compensation solutions (such as adjusting the load capacitance or frequency center value) to adapt to different application scenarios.

The core principle of the 32.768K crystal oscillator is based on the piezoelectric effect of the quartz crystal. When an electric field is applied, the quartz crystal generates mechanical vibration, and vice versa. This two-way conversion enables the crystal to oscillate stably at a specific frequency.‌

Its frequency is determined by the cutting direction and size of the crystal. The 32.768kHz crystal oscillator usually adopts a tuning fork structure, and low-frequency oscillation is achieved through the vibration of the fork teeth.‌

 This frequency value is exactly 2 to the 15th power (32768Hz). After 15 times of frequency division by two, a 1Hz second pulse signal can be accurately generated. Therefore, it is widely used in timing devices such as clocks and real-time clocks (RTC).


Product Tags: XiHua Crystal Oscillator , XiHua Crystal , Clock Crystal Oscillator , Tuning Fork Crystal Oscillator , SIWARD XiHua Crystal Oscillator
