Nanjing Mingrui ICP 700T Food and Agricultural Product Safety Detector can detect heavy metals (such as arsenic, mercury, lead) and nutritional elements (such as calcium, iron, zinc) in food (such as meat, fruits and vegetables, grains) and feed, identify potential safety hazards, and ensure food safety. It can analyze the residues of harmful elements in agricultural products (such as tea and traditional Chinese medicinal materials), meeting the requirements of national standards. Phone: 18651882886 (WeChat).
It is widely used in many production and research fields such as rare earth analysis, precious metal analysis, alloy materials, electronic products, metallurgy, geology, petroleum, chemical industry, commodity inspection, environmental protection, colleges and universities, research institutes, geological exploration, mining and mineral processing, PCB circuit boards, surface treatment, energy and environmental protection, medical and health, agriculture, food, feed, biology, fertilizers, chemistry, etc.
Food and Agricultural Product Safety Detector Specifications and Technical Indicators
*Solid-state Power Supply
Operating frequency: 27.12MHz
Frequency stability:
Matching method: Automatic matching
Output power: 800W - 1600W, continuously adjustable, power supply efficiency > 65%
Output power stability: ≤0.05%
Inner diameter of the output working coil is 25mm, with 3 turns, equipped with a quartz torch tube with an outer diameter of 20mm and three concentric layers
Outer diameter of the coaxial nebulizer is 6m; outer diameter of the double-barrel spray chamber is 35mm
Scanning Spectrometer
Optical path: Czerny turner type
Focal length: 1000mm
Grating specifications: Ion-etched holographic grating, ruling density is 3600L/mm or 2400L/mm; ruling area is (80X110)mm
Resolution: 0.008nm (3600-line grating) ≤0.015nm (2400-line grating)
Scanning wavelength range: For 3600-line grating: (190 - 500)nm; for 2400-line grating: (190 ~ 800)nm
Electronic Measurement and Control Circuit
Photomultiplier tube specifications: R212/R928
Photomultiplier tube negative high voltage: (-50 ~ -1000)V
Photomultiplier tube current measurement range: (10-12 ~ 10-4)A
Signal acquisition: VF conversion
Computer System
Host: Lenovo Brand Computer
Monitor: 17-inch LCD Monitor
Printer: Canon Inkjet Printer
Overall Machine Technical Specifications
Scanning Wavelength Range: 190 - 460nm (4320L/mm grating), 190nm - 500nm (3600L/mm grating), 190nm - 800nm (2400L/mm grating);
Measurement Range
a. Liquid content: 0.01ppm - several thousand ppm
b. Solid content: 0.001% - 70%
Repeatability: (i.e., short-term stability) Relative Standard Deviation RSD ≤ 1.5%;
Stability: Relative Standard Deviation RSD ≤ 2%;
Testing speed: 5 - 8 elements/minute
Instrument Features
More than 70 elements can be measured
Fast analysis speed, 5 - 8 elements can be measured in one minute
Simultaneous analysis of multiple elements. Customers can freely choose the number of elements and arrange the measurement sequence. Low detection limit, reaching the ppb level, and even 0.7ppb for Ba
Wide linear dynamic range, up to 6 orders of magnitude. High and low contents can be measured simultaneously
Low analysis cost. One bottle of argon can be used for 8 hours
Total Reflection Achromatic Optical System
Using a concave mirror instead of a convex lens as the optical focusing element solves the chromatic aberration problem caused by different focal points of different elements and improves the efficiency of the optical system at the same time.
Wide Wavelength Range
Selecting a 4320-line grating, the wavelength range can reach 190 - 460nm
Selecting a 3600-line grating, the wavelength range can reach 190 - 500nm
Selecting a 2400-line grating, the wavelength range can reach 190 - 800nm
Fully Automated Design
High degree of automation. Except for the power switch, all functions of the whole instrument are controlled by the computer, which is reliable, safe, and convenient.
Automatic Gas Flow Control
In the sampling system, the carrier gas, plasma gas, and auxiliary gas are all controlled by advanced Mass Flow Controllers (MFCs), which have the advantages of continuously adjustable flow and stable flow, ensuring the stability of the sampling system and providing a strong guarantee for the stability of the light source.
Advanced Sampling System
The sampling system is highly efficient and stable. It can be equipped with various domestic and international nebulizers and spray chambers, including high-salt nebulizers and hydrofluoric acid-resistant nebulizers, to meet the needs of different customers.
Stable Waste Liquid Exclusion System
The waste liquid is excluded through a peristaltic pump to ensure that the sampling volume is consistent with the waste liquid exclusion speed. Customers can adjust the speed appropriately as needed to ensure the stability of the standard injection system.
*Stable and Advanced All-Solid-State RF Power Supply
The RF power supply used in the instrument is an independently developed all-solid-state RF power supply, which has many advantages such as small size, high efficiency, stable output power, and various protection functions. It further improves the stability and safety of the instrument. *Fast and Accurate Automatic Matching Function
The load terminal adopts independently developed automatic matching technology, which has the advantages of fast matching speed and high accuracy. It ensures that the output power is maximally applied to the load, improves the utilization efficiency of the power supply, thereby improving the stability of the instrument and making the entire ignition process convenient and simple.
*One-Button Ignition
Combined with the solid-state power supply and automatic matching technology, the one-button ignition function is perfectly realized. Users only need to click the ignition button, and the instrument automatically performs many actions such as gas purging, gas flow inspection, ignition, and matching, and transmits the information to the customer in real-time, saving customers time and effort.
*Automated Observation Height Adjustment
Different elements have different observation heights. Customers can appropriately adjust the observation height of the flame through the software based on experience or comparison to obtain better measurement results at the optimal position.
Powerful Graphical Diagnosis Function
The powerful graphical diagnosis function can help customers fully understand the current working status of the instrument and observe the operating conditions of the instrument under different conditions through appropriate parameter settings to grasp the optimal measurement conditions.
Multi-Element Automatic Measurement
Select the elements to be measured, set the measurement parameters, and leave everything to the instrument. Finally, directly obtain the measurement results of all elements, which is simple and time-saving.
*Powerful Database Management
It has thousands of spectral lines. You can select appropriate spectral lines according to your needs and preferences to avoid possible interferences. It provides you with more choices and more reasonable recommendations, making the test more professional and accurate.
The software has independent intellectual property rights, is powerful, and has a user-friendly operation
The software is powerful and has an automatic Chinese-English switching function. It can perform qualitative and quantitative analysis; has a data reprocessing function; automatically calculates the element content and automatically generates test reports; has a data screening function to eliminate unwanted data; the database management is perfect, and you can freely save and delete data.
