Marine Fresh Water Generator FWG | Seawater Desalination System for Ships
Our Marine Fresh Water Generator FWG utilizes globally advanced Reverse Osmosis Membrane Technology to efficiently transform seawater into clean, odor-free, and bacteria-safe drinking water that complies with the National Drinking Water Standard (GB5749-2006).
Ideal for fishing vessels, steamships, and coastal installations where freshwater scarcity is a challenge, this system effectively removes minerals, microorganisms, bacteria, and other impurities. It delivers high-purity freshwater suitable for drinking, cooking, and sanitary use onboard.
The system is equipped with a fully automatic pre-filtration unit featuring advanced multiport valves, enabling efficient large-flow backwashing and rinsing without manual intervention. All piping and the main body are constructed with corrosion-resistant materials, ensuring long service life and reliable performance in marine environments.
The reverse osmosis unit incorporates high-quality membrane elements and energy-saving design principles, significantly reducing power consumption while maintaining high output. An intelligent monitoring system provides real-time operational data, ensuring stable and safe performance under various conditions.
Key components such as flow and pressure controllers, atmospheric valves, and blow-down piping are installed to enhance system durability and user convenience.
FWG Main Components & Introduction
Feed Pump
Qty: 1
Flow Rate: 4m³/h
Head: 30m
Power: 0.75KW
Provides backwashing and rinsing for multi-media and precision filters.
Multi-Media Filter
Qty: 1
Dimensions: Ø350×1410mm
Output: >3m³/hr
Pressure: 0.4MPa
Effectively removes algae, suspended solids, minerals, and large particles. Includes manual rinsing and backwashing functions to prevent clogging.
Precision Filter
Equipped with 10μm and 5μm filter cartridges to prevent leakage and protect RO membranes from particles larger than 5μm.
High-Pressure Pump
Provides necessary pressure to overcome osmotic resistance and ensure designed productivity.
Reverse Osmosis Unit
Qty: 1 set
Core desalination component that removes soluble salts, colloids, organics, and microbes. Includes automatic valves and monitoring instruments for long-term stable operation.
Cleaning System
Qty: 1 set
Periodically cleans the RO membrane using chemical agents to remove accumulated contaminants and restore performance.
Control System
Schneider electrical components with PLC control module. Features an on-site spray-coated steel control cabinet with user-friendly interface.
Technical Parameters
Raw Water
Source: ≤36,000 mg/L
Temperature: 5–45°C
Inlet Flow: 4.47 m³/hProduct Water
Daily Output: 30 m³/D
Recovery Rate: 28%
Desalination Rate: ≥99.5%
Output TDS: ≤500 mg/L
Operating Pressure:Power
Voltage: 380V/50Hz/3-phase
Total Power: 12.1 KW
Protection Level: IP54Operating Environment
Temperature: 0–45°C
Humidity: 20–90%
Certification
Approved by major marine classification societies including ABS, BV, DNV, GL, KR, RINA, NK, LR, and CCS.
The description/sizes may be different with goods, please check with us when order.
