Emerson Thermodisc Tf104c Thermal Fuse | G4a00104c Model Thermal Fuse at 240°c

Emerson Thermodisc Tf104c Thermal Fuse | G4a00104c Model Thermal Fuse at 240°c thumbnail-1
Emerson Thermodisc Tf104c Thermal Fuse | G4a00104c Model Thermal Fuse at 240°c photo-1
Key Specifications
Get Latest Price
Main Markets:
North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe, Central America, Northern Europe, Southern Europe, South Asia, Domestic Market
Location:
Jining, Shandong, China
Contact Supplier Request Quote Chat Now
Jining Donglin Electronics Technology Co., Ltd.
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us

(1) Product Overview

Thermodisc (Emerson) MICROTEMP Thermal Fuses (also known as thermal cutoffs or temperature fuses) are one-time overheat protection safety components. They precisely sense the abnormal high temperatures generated by electrical and electronic products (such as small household appliances, transformers, charging devices, etc.) during abnormal operation, and instantaneously and permanently cut off the current circuit, thereby effectively preventing the occurrence of fires and safeguarding life and property safety.

(2) Detailed Parameter Comparison of Products in Each Series

Key Parameter Comparison Table of Thermodisc MICROTEMP Series

Parameter Items

G4 Series

G5 Series

G6 Series

G8 Series

Z6 Series

Rated Load

10A / 250VAC

20A / 250VAC

16A / 250VAC

20A / 277VAC

16A / 250VAC

Safety Certifications (Example)

UL, CSA, VDE, CCC, PSE, KC

UL, CSA, VDE, CCC, PSE, KC

UL, CSA, VDE, CCC, PSE

UL, CSA, VDE, CCC, PSE

UL, CSA, VDE, CCC

Representative Models

G4A00104C, G4A01104C, etc.

G5A00104C, G5A01104C, etc.

G6A00104C, G6A01104C, etc.

G8A00104C, G8A01104C, etc.

Z6A00104C, Z6A01104C

Lead Length (Corresponding Model)

63.8mm (G4A0104C)
82.9mm (G4A1104C)

63.8mm (G5A0104C)
82.9mm (G5A1104C)

63.8mm (G6A0104C)
82.9mm (G6A1104C)

63.8mm (G8A0104C) (G8A1104C)

63.8mm (Z6A0104C)
82.9mm (Z6A1104C)

Rated opening temperature (Tf)

104°C

104°C

104°C

104°C

104°C

Temperature tolerance

+0/-5°C

+0/-5°C

+0/-5°C

+0/-5°C

+0/-5°C

Holding temperature (Th)

89°C

89°C

89°C

89°C

89°C

Maximum temperature (Tm)

200°C

225°C

200°C

225°C

260°C

Series features

Standard 10A load, widely used

High load 20A, used for high-current devices

16A balanced load

Supports high voltage of 277V

Ultra-high maximum temperature, good high-temperature resistance

(3) Explanation of model naming rules

MICROTEMP models contain key information such as series, load, certification, and length. For example, G4A00104C:

G4: Represents the G4 series.

A: Represents specific electrical load and certification standards.

0 (the 6th digit from the end): Represents standard-length leads (e.g., 63.8mm), while 1 represents long leads (e.g., 82.9mm).

104: Represents the rated operating temperature of 104°C.

C: Represents other specific design features.

(4) Selection and application suggestions

G4 series: Suitable for most small household appliances below 10A, such as rice cookers, hair dryers, electric kettles, etc. It is an economical and general-purpose choice.

G5/G8 series: Suitable for high-power devices such as coffee makers and heaters. The G8 series is particularly suitable for industrial applications with higher voltage requirements.

Z6 series: Due to its maximum temperature of up to 260°C, it is suitable for use inside devices with high operating environment temperatures, providing a higher safety margin.




Product Tags: Thermodisc G4A00104C , Thermodisc G4A01104C , Emerson G4A00104C , TOD G4A00TF104C , Emerson G4A01104C
