HST-RMM300 Electric Heating Two Roll Mixing Mill for Plastic Rubber
Scope Of Application:
Lab Scale Two Roll Mill For Rubber And Plastic is suitable for polymers such as rubber and plastic industry
mixing process PVC, masterbatch and other chemical raw materials. As the raw material and mixed with the
agent, and to achieve the desired color and quality. The machine uses special heating the mold, the roller
surface temperature uniformity, never delamination, sample thickness adjustable and attached machine safetydevices, lightweight and easy to use.
Parameters:
|
Model |
Lab Scale Two Roll Mill For Rubber And Plastic |
|
Mixed capacity |
0.5-1kgs / 2-3kgs / 5-7 kgs |
|
Temperature |
room temperature ~ 300 ℃ |
|
Temperature control |
LED display, buttons to set the input and display output value |
|
Temperature control |
P.I.D controlled |
|
Heater |
cylindrical mold is heated |
|
Warm-up time |
room temperature ~ 150 ℃ about 20min |
|
Temperature accuracy |
± 3 ℃ |
|
Roller dimensions |
diameter 3.9 "× L13.7" |
|
Drum revolutions ratio |
Standard revolutions ratio 1:1.25 |
|
Roller hardness |
HRC 50 ~ 60 |
|
Power |
about 2800W |
|
Protection device is attached state of emergency |
Security |
|
Volume |
960*550*1150 (W* D* H) mm |
|
Power source |
AC380V, 15A |
|
Weight |
about 380kg |
Main Feature:
1.The roll is made of chilled cast iron ,including hollow roll and drilled roll in structure .The inner cavity of hollow roll is machined .The hollow roll surface is smooth and grooved .The grooved roll includes full grooved roll and half grooved roll etc
2.The base is divided into integrated base and separated base .The driving mode includes open driving ,half open driving and enclosed driving .
3.The roll is supported with roller bearing ,so the energy is saved ,and the noise is reduced and is durable .
4.Lubricating mode includes grease lubrication and oil lubrication .
5.Roll nip adjustment includs manual adjustment ,power adjustment and hydraulic adjustment . hydraulic adjustment can be automatically controlled ,having better safety protection preformance .
6. It can be equipped with pressure sensor system to directly display the working pressure to control the feed .In case of over load ,it can automatically stop at once ,and store and print the peak value .
7. This produce is accordance with nation safety standard (this standard is equivalent to the Europe standard )
8. User can select the stock blender according to the processing requirements .
|
|
|
|
|
