Cathodic Protection Anode Zinc Block, Welded Zinc Anode for Ocean Engineering





The sacrificial anode of the zinc-aluminum-cadmium system (ZAC system) is cast from high-purity zinc alloyed with aluminum and cadmium.

This product is approved by the China Classification Society (CCS). The quality standard complies with the GB/T4950 - 2002 standard, and the chemical composition of the zinc anode complies with the US MIL - A - 18001H and ASTM - B418 Type 1) standards. The anodes used for pipelines also comply with SY/T0019 - 97 "Design Specification for Sacrificial Anode Cathodic Protection of Buried Steel Pipelines".

Zinc Anodes for Buried Pipelines



Model

Specification/mm

Iron Foot Size/mm

Net Weight/kg

Gross Weight/kg




Ax (B1 + B2)xC

D

E

F

G




ZP - 1

1000x(78 + 88)x85

700

100

16

30

49.0

50.0

ZP - 2

1000(65 + 75)x65

700

100

16

25

32.0

33.0

ZP - 3

800x(60 + 80)x65

600

100

12

25

24.5

25.0

ZP - 4

800x(55 + 64)x60

500

100

12

20

21.5

22.0

ZP - 5

650x(58 + 64)x60

400

100

12

20

17.6

18.0

ZP - 6

550x（58+64）x60

400

100

12

20

14.6

22.0

ZP-7

600x（52+56）x54

460

100

12

15

12.0

12.5

ZP-8

600x（40+48）x45

360

100

12

15

8.7

9.0

Zinc anodes for port and marine engineering facilities

Model

Specification/mm

Size of threaded steel foot/mm

Size of flat steel foot/mm

Net weight/kg

Gross weight/kg






A×（B1＋B2）×C

D

F

G

E

F

G





ZT-1

1000x（115+135）x130

1250

18

45

1250

40

8

45

111.6

115.0

ZT-2

750x（115+135）x130

1000

16

45

1000

40

8

445

83.0

85.0

ZT-3

500x（115+135）x130

750

16

45

750

40

6

45

55.0

56.0

ZT-4

500x（105+135）x100

750

16

35

750

40

6

35

38.6

40.0

Long strip zinc anode for seawater cooling water system

Model

Specification/mm

Iron foot size/mm

Net weight/kg

Gross weight/kg




Ax（B1+B2）xC

D

E

F

G




ZE-1

500x（115+135）x130

620

50

6

8~10

54.5

56.0

ZE-2

1000（80+100）x80

1200

30

6

6~8

49.0

50.0

ZE-3

500x（105+135）x100

620

40

6

8~10

39.2

40.0

ZE-4

500x（80+100）x80

620

30

6

6~8

24.4

25.0

ZE-5

400x（110+120）x50

500

35

4

5~6

15.4

16.0

ZE-6

300x（140+160）x40

360

60

4

5~6

12.0

12.5

ZE-7

200x（90+110）x40

250

30

3

5~6

5.3

5.5

Disc-shaped sacrificial anode for seawater cooling water system

Model

Specification/mm

Iron foot size/mm

Net weight/kg

Gross weight/kg






AxB

C

D

E

F

H

G




ZE-8

300x60

40

80

50

12

6~8

6

29.8

30.0

ZE-9

360x40

50

100

70

14

5~6

6

28.3

28.5

ZE-10

300x40

40

80

50

12

5~6

6

19.8

20.0

ZE-11

200x50

35

75

45

10

5~6

4

10.3

10.5

ZE-12

180x50

35

75

45

10

5~6

4

8.3

8.5

ZE-12

120x100

30

75

45

10

8~10

4

7.3

7.5

Welded Zinc Anode for Hull (Single Iron Foot)

Model

Specification/mm

Iron Foot Size/mm

Net Weight/kg

Gross Weight/kg




AxBxC

D

E

F

G




ZH-1

800x140X60

900

45

5~6

8~10

45.4

47.0

ZH-2

800x140X50

900

45

5~6

6~8

37.4

39.0

ZH-3

800x140X40

900

45

5~6

5~6

29.5

31.0

ZH-4

600x120X50

700

40

5~6

6~8

24.0

25.0

ZH-5

400x120X50

470

35

4~5

6~8

15.3

16.0

ZH-6

500x100X40

580

40

4~5

5~6

12.7

13.6

ZH-7

400x100X40

460

30

4~5

5~6

10.6

11.0

ZH-8

300x100X40

360

30

3~4

5~6

7.2

7.5

ZH-9

250x100X40

310

30

3~4

5~6

6.2

6.5

ZH-10

180x70X40

230

25

3~4

5~6

3.3

3.5


Product Tags: Price of zinc alloy sacrificial anodes , Zinc alloy anodes for seaports , Zinc anodes for condensers , Zinc anode blocks for ships , Block-shaped zinc anodes
