US$ 4999 - 5899 MOQ: 1 Set
Key Specifications
Get Latest Price
Type:
Mechanical Tensile Testing Machine
Display:
Digital display
Maximum Compressive Space:
600 mm
Contact Supplier Request Quote Chat Now
Hst Group Co.,ltd.
Gold Verified Supplier
1Yr
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Maximum Compressive Space 600 mm
Maximum Tensile Space 650 mm
Brand Name HST OR OEM
Place of Origin Shandong, China
Crossbeam Displacement Accuracy ±0.01 mm
Power Supply 220 V
Product name Universal Double-Column Tensile Strength Testing Machine
Load accuracy 1 class
Displacement Resolution 0.04um
Test speed 1-500mm/min
Measuring range 2%-100%
Function tensile compression bending shear test
Power supply AC 220V 60/50Hz (Customized)
Power Electronic
Voltage 220V

WDW-200E Microcomputer controlled Electronic universal Testing Machine

Product Description

 20kn Utm Electric Universal Testing Machine Electronic Test Bench Tensile Peel Tear Strength Machine Tensile Testing Machines20kn Utm Electric Universal Testing Machine Electronic Test Bench Tensile Peel Tear Strength Machine Tensile Testing Machines20kn Utm Electric Universal Testing Machine Electronic Test Bench Tensile Peel Tear Strength Machine Tensile Testing Machines20kn Utm Electric Universal Testing Machine Electronic Test Bench Tensile Peel Tear Strength Machine Tensile Testing Machines20kn Utm Electric Universal Testing Machine Electronic Test Bench Tensile Peel Tear Strength Machine Tensile Testing Machines

Main configuration



1. Application:

It is applicable for wide range of material for tension, compression, bending, shearing and low cycle test. Suitable for metal, rubber, plastic, spring, textile, and components testing. It is widely used in the corresponding industries, research and development, test institutes and training centers etc.



2.Standard:

ASTM, ISO, DIN, GB and other international standards.



3.Main Technical Parameters:



Model

WDW-10kN

WDW-20kN

WDW-50kN

WDW-100kN

WDW-200kN

WDW-300kN

Max. Load(kN)

10

20

50

100

300

Crosshead-Table distance

1140









Tensile space(mm)

800

800

700

700

550

Compression space(mm)

800

800

700

700

550

Effective test width(mm)

400

400

500

550

600

Ambient temperature

+10 ... +35 °C

Conformity

ISO 9000 and CE

Force transducer

Load accuracy

Standard

Class 1, Conforms to EN 10002-2 Grade1, ISO75001-1 Class 1, BS 1610 Class 1, ASTM E4, and JIS B7721 Class 1

High-Precision

Class 0.5, Conforms to EN 10002-2 Grade0.5, ISO75001-1 Class 0.5, BS 1610 Class 0.5, ASTM E4, and JIS B7721 Class 0.5

Load range

2%~100%F·S/ 0.2%~100%F·S

Load resolution

1/500000

Displacement transducer

Resolution of deformation

0.04um

Accuracy of displacement

Within±0.5%of indicating load

Resolution of displacement

0.01mm


20kn Utm Electric Universal Testing Machine Electronic Test Bench Tensile Peel Tear Strength Machine Tensile Testing Machines

20kn Utm Electric Universal Testing Machine Electronic Test Bench Tensile Peel Tear Strength Machine Tensile Testing Machines20kn Utm Electric Universal Testing Machine Electronic Test Bench Tensile Peel Tear Strength Machine Tensile Testing Machines

More Information

We have digital model and computer control models for choice:



20kn Utm Electric Universal Testing Machine Electronic Test Bench Tensile Peel Tear Strength Machine Tensile Testing Machines20kn Utm Electric Universal Testing Machine Electronic Test Bench Tensile Peel Tear Strength Machine Tensile Testing Machines20kn Utm Electric Universal Testing Machine Electronic Test Bench Tensile Peel Tear Strength Machine Tensile Testing Machines 20kn Utm Electric Universal Testing Machine Electronic Test Bench Tensile Peel Tear Strength Machine Tensile Testing Machines 20kn Utm Electric Universal Testing Machine Electronic Test Bench Tensile Peel Tear Strength Machine Tensile Testing Machines 20kn Utm Electric Universal Testing Machine Electronic Test Bench Tensile Peel Tear Strength Machine Tensile Testing Machines
