Under Tile Electrical Flooring Heat Trace Cable Underfloor Heating Cable 12v 24v 36b
US$ 3.51
≥100 Meters
Key Specifications
Get Latest Price
Application:
Underground
Insulation Material:
XLPO
Conductor Material:
Steel
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Heating Cable 220v Underfloor Gutter Downspout Heating Cable 110v Outdoor Flat HeatingUS$ 3.51MOQ: 100 Meters -
Household Heating Electric Heating Cable Household Heating CableUS$ 5.61MOQ: 50 Meters
-
12~380V Pipe Electric Heating Cable Self Regulating Heating CableUS$ 3.51MOQ: 100 Meters
-
Livestock Breeding and Cultivation Underfloor Heating Dual-conducting Heating Cable for PipeUS$ 0.5 - 1MOQ: 1 Meter
-
220V Floor Heating Cable Frost-protection of Pipework Underfloor Underground Heating Tracing Cable With ThermostatUS$ 6.24MOQ: 1000 Meters
Application
Underground
Jacket
XLPE
Number of Conductors
Single
Brand Name
youyu
Place of Origin
Anhui, China
Length
1 m
color
customized
Product name
self-regulating heating cable
Certifications
ROHS
Voltage
110-220V
SUMMARY
Heating cable using alloy resistance wire for electric heating to achieve heating effect.The heating cable is divided into single conductor heating cable and twin conductor heating cable
ADVANTAGES
1.Comfortable,healthy clean long life and no maintenance
2.Spacious simple warm damp proof and mildew proof
3.Safety efficiency environmental protection energy saving and low cost
There is no leakage and short circuit in heating by heating cable and there is no danger
The temperature of each room can be shut down and adjusted separately
Heating cable using alloy resistance wire for electric heating to achieve heating effect.The heating cable is divided into single conductor heating cable and twin conductor heating cable
ADVANTAGES
1.Comfortable,healthy clean long life and no maintenance
2.Spacious simple warm damp proof and mildew proof
3.Safety efficiency environmental protection energy saving and low cost
There is no leakage and short circuit in heating by heating cable and there is no danger
The temperature of each room can be shut down and adjusted separately
Data Sheet of 13W/M Underfloor Heating Cable |
||||||||||
Catalog Number |
Rated Voltage |
W/M |
Length(M) |
Output Power
(W)
|
Heating Area
(Square Meter)
|
|||||
FTC-150-13-2 |
110/220 |
13 |
11.5 |
150 |
1SQM |
|||||
FTC-225-13-2 |
110/220 |
13 |
17.3 |
225 |
1.5SQM |
|||||
FTC-300-13-2 |
110/220 |
13 |
23.1 |
300 |
2SQM |
|||||
FTC-375-13-2 |
110/220 |
13 |
28.8 |
375 |
2.5SQM |
|||||
FTC-450-13-2 |
110/220 |
13 |
34.6 |
450 |
3SQM |
|||||
FTC-525-13-2 |
110/220 |
13 |
40.4 |
525 |
3.5SQM |
|||||
FTC-600-13-2 |
110/220 |
13 |
46.2 |
600 |
4SQM |
|||||
FTC-675-13-2 |
110/220 |
13 |
51.9 |
675 |
4.5SQM |
|||||
FTC-750-13-2 |
110/220 |
13 |
57.7 |
750 |
5SQM |
|||||
FTC-900-13-2 |
110/220 |
13 |
69.2 |
900 |
6SQM |
|||||
FTC-1050-13-2 |
220 |
13 |
80.8 |
1050 |
7SQM |
|||||
FTC-1200-13-2 |
220 |
13 |
92.3 |
1200 |
8SQM |
|||||
FTC-1350-13-2 |
220 |
13 |
103.8 |
1350 |
9SQM |
|||||
FTC-1500-13-2 |
220 |
13 |
115.4 |
1500 |
10SQM |
|||||
FTC-1650-13-2 |
220 |
13 |
126.9 |
1650 |
11SQM |
|||||
FTC-1800-13-2 |
220 |
13 |
138.5 |
1800 |
12SQM |
|||||
Data Sheet of 17W/M Double Conductor Heating Cable |
||||||||
Catalog Number |
Rated Voltage |
W/M |
Length(M) |
Output Power(W) |
||||
FTC-300-17-2 |
110/220 |
17 |
17 |
300 |
||||
FTC-400-17-2 |
110/220 |
17 |
23 |
400 |
||||
FTC-500-17-2 |
110/220 |
17 |
29 |
500 |
||||
FTC-600-17-2 |
110/220 |
17 |
35 |
600 |
||||
FTC-700-17-2 |
110/220 |
17 |
41 |
700 |
||||
FTC-850-17-2 |
110/220 |
17 |
50 |
850 |
||||
FTC-1000-17-2 |
110/220 |
17 |
58 |
1000 |
||||
FTC-1200-17-2 |
220 |
17 |
70 |
1200 |
||||
FTC-1400-17-2 |
220 |
17 |
82 |
1400 |
||||
FTC-1600-17-2 |
220 |
17 |
94 |
1600 |
||||
FTC-1800-17-2 |
220 |
17 |
105 |
1800 |
||||
FTC-2000-17-2 |
220 |
17 |
117 |
2000 |
||||
FTC-2200-17-2 |
220 |
17 |
129 |
2200 |
||||
FTC-2400-17-2 |
220 |
17 |
141 |
2400 |
||||
FTC-2600-17-2 |
220 |
17 |
153 |
2600 |
||||
FTC-2800-17-2 |
220 |
17 |
164 |
2800 |
||||
FTC-3000-17-2 |
220 |
17 |
176 |
3000 |
||||
FTC-3300-17-2 |
220 |
17 |
194 |
3300 |
||||
Data Sheet of 30W/M Double Conductor Heating Cable |
||||||||
Catalog Number |
Rated Voltage |
W/M |
Length(M) |
Output Power(W) |
||||
FTC-300-30-2 |
230 |
30 |
10 |
300 |
||||
FTC-450-30-2 |
230 |
30 |
15 |
450 |
||||
FTC-600-30-2 |
230 |
30 |
20 |
600 |
||||
FTC-750-30-2 |
230 |
30 |
25 |
750 |
||||
FTC-900-30-2 |
230 |
30 |
30 |
900 |
||||
FTC-1050-30-2 |
230 |
30 |
35 |
1050 |
||||
FTC-1200-30-2 |
230 |
30 |
40 |
1200 |
||||
FTC-1350-30-2 |
230 |
30 |
45 |
1350 |
||||
FTC-1500-30-2 |
230 |
30 |
50 |
1500 |
||||
FTC-1800-30-2 |
230 |
30 |
60 |
1800 |
||||
FTC-2100-30-2 |
230 |
30 |
70 |
2100 |
||||
FTC-2400-30-2 |
230 |
30 |
80 |
2400 |
||||
FTC-2700-30-2 |
230 |
30 |
90 |
2700 |
||||
FTC-3000-30-2 |
230 |
30 |
100 |
3000 |
||||
FTC-3300-30-2 |
230 |
30 |
110 |
3300 |
||||
FTC-3600-30-2 |
230 |
30 |
120 |
3600 |
||||
FTC-3900-30-2 |
230 |
30 |
130 |
3900 |
||||
FTC-4200-30-2 |
230 |
30 |
140 |
4200 |
||||
1. Are you manufacturer or trading company?
We are professional heating cable manufacturer founded in 2012, located in Wuhu city, Anhui Province, China. Welcome to visit our factory!
2. What's the Minimum Order Quantity?
There is no MOQ requirement for standard product.
And the MOQ for customized product is 10pcs
And the MOQ for customized product is 10pcs
3. What is your delivery time?
Normally within 7~15 days, The specific delivery time is determined according to the product model and quantity you ordered.
4. What's the payment term?
T/T, L/C, Western Union, Paypal, Alibaba secure payment, D/P.
5. Can you provide samples for testing before placing orders ?
Yes, we can provide samples to check quality and testing its performance.
6. What is warranty of your product?
25 years free warranty for underfloor heating cable & mat
7. Can you do OEM and ODM for us?
Yes, we can provide professional OEM and ODM services. We have an experienced R&D technical team that can provide you with standard and customized products, and can also put your logo on the heating mat.
8.If your heating cable eco-friendly?
Our heating mat is all in accordance with ROHS, you can buy and use freely.
9.Do you offer or supply room thermostat compatible to your electric underfloor heating system?
Yes, we have mechanical, LCD digital display, WIFI and other types of thermostats for your choice.
10.Which floor decoration materials are suitable for installing the underfloor heating system?
Tile, marble, wood floor, laminate, vinyl board, concrete and other floor decoration materials.
11.Does each room require its own thermostat?
We recommend that each room be equipped with a thermostat to control the temperature independently,
which will save energy and make temperature control simpler and more accurate.
which will save energy and make temperature control simpler and more accurate.
