Honeywell X-DA2250S Digital Power Amplifier, 2x250 Watts
Features
• Rated output power 2 × 250W (supports dynamic distribution)
• This product meets CCC, CE certification standards
• Direct drive design, 100V or 70V optional output
• Built-in 170Hz~20KHz high-pass filter
• Delayed start-up, 15 gears are optional
• Supports full audio frequency response with a bandwidth of 20Hz~20KHz ±0.8dB
• Supports audio balanced input or unbalanced input mode
• 1U chassis design, space-saving and allowing the cabinet to accommodate more equipment
• Dual power supply design, main power supply 220V mains, backup power 220V (UPS)
• Temperature control fan, forced air cooling and heat dissipation
Product model X DA2250S
Mains ~ 220V 50/60Hz +10% 15%
Backup Power ~ 220V 50/60Hz +10% 15%
Power consumption <700W
Fuse T10 AL 250V
Number of channels 2
Rated power 2 × 250 W or 1 × 500 W (at this point the other channel is not loaded)
Rated voltage limit 100V/70V (default 100V)
Frequency response 20Hz ~ 20KHz (±0.8dB) High-pass filtering is turned off
170Hz ~ 20KHz (±2dB) with high-pass filtering on (default)
Input sensitivity balance: 1.414VRMS, 0.775VRMS (default is 1.414VRMS)
Input impedance 20k ohm
SN 100dB (A-weighted)
Total harmonic distortion THD 0.1% @1kHz, 3dB power rating
Indicator light: power indicator, main power fault, backup power fault, protection, peak shaving, signal indicator 1 each
Operating Humidity 95%
Operating temperature 5 C~+55 C
