Honeywell RK-MIC remote call station Fire Broadcast Microphone
Features:
• Microphone interface for connecting to a gooseneck microphone or handheld microphone for manual voice broadcasting;
• Built-in speakers to monitor the sound source being played by the system;
• It has a temporary recording function, which is convenient for users to record and play voice directly.
• It has a line input interface, which is convenient for connecting external audio source equipment for background music broadcasting;
• Microphone input, line input, and speaker volume can be adjusted via the rear knob;
• With 8 programmable buttons, the default corresponds to 8 partitions of the main control unit, which can be configured through software;
• The key module RK-K4/RK-K8 can be expanded as needed;
• Detects microphone and communication line faults;
• Main control unit connected by twisted pair cable at a distance of up to 600 meters;
• Can be powered by the main control unit or external power adapter;
• The system can connect up to 6 remote call stations.
Technical indicators
Parameter value
Supply voltage DC 24V
Power rating 10 W
Microphone input
Input sensitivity 5mV
Input impedance 600Ω
Frequency response 100 Hz -10KHz
Signal-to-noise ratio 77dB, A-weighted
Distortion 90dB, A weighting
Distortion
Audio output
Output signal 2V
Output impedance 200Ω
Other indicators
Monitor speaker 2W/8Ω
Working conditions
Ambient humidity 95%, no condensation
Operating Temperature -10 C~+55 C (14 F to +131 F)
Storage temperature -40 C~+70 C (-40 F to +158 F)
Specifications:
Product Dimensions (W×H×D) 200mm × 46.5mm × 200mm
Box size (W×H×D) 403mm × 133mm × 268mm
Net weight 1.4Kg
Gross weight 2.5Kg
