Help CenterSchneider Electric TSXDST1612: Your Compact Workhorse for Machine Control Outputs
Related Products
-
Kongsberg WCC600 Wireless Call Panel: Keep Critical Shipboard Communications FlowingUS$ 3216.00MOQ: 1 Blade -
VMIC VMIVME-7740-850: Rugged Single-Board Computer for Demanding VME SystemsUS$ 1300.00MOQ: 1 Blade
-
VMICPCI-7806: Keeping Your Legacy VME Systems Running SmoothlyUS$ 1300.00MOQ: 1 Blade
-
GE VMIPCI-5565-110000: Real-Time Data Sharing That Actually MattersUS$ 1300.00MOQ: 1 Blade
-
GE VMIVME-2128: Rock-Solid Digital Output for Demanding Industrial ControlUS$ 1300.00MOQ: 1 Blade
16 dry-contact relays – Switches AC/DC loads up to 2A without worrying about polarity. You might notice this flexibility matters when retrofitting older equipment with mixed signal types.
Hot-swap capable – Replace it without killing power to the whole rack. Worth noting that you'll still want to de-energize the specific output circuit first for safety.
Nano-series footprint – Fits where larger modules won't. Typically slides into 75mm-wide DIN rail spaces, which seems perfect for compact OEM machinery.
LED per channel – No more guessing if that solenoid valve actually fired. In many cases, this alone cuts debugging time by half during commissioning.
| Specification | Details |
|---|---|
| Brand/Model | Schneider Electric TSXDST1612 |
| HS Code | 8538.90.91 (Verify with customs for your region) |
| Power Requirements | 24V DC (20.4-26.4V) @ 300mA max – runs off standard control power |
| Outputs | 16 Form C relays (250V AC / 30V DC, 2A per channel) |
| Dimensions & Weight | 90 x 70 x 58mm / 220g – slides into tight panels |
| Operating Temp | -25°C to +70°C – survives factory floor extremes |
I've seen this module deployed in everything from bakery conveyor interlocks to water treatment valve controls. It's particularly handy for small injection molding machines where space constraints rule out larger I/O blocks. One customer recently told me it solved their bottle-filling line stoppage issues – turns out the old mechanical relays were failing under humidity, but the TSXDST1612's sealed contacts handled the washdown environment just fine.
Let's be real – you're probably comparing this against generic relay modules. The real value? Compatibility with Modicon Nano PLCs means no protocol headaches during integration. We've had clients save weeks on commissioning because it auto-configures in Unity Pro software. Also, that 365-day warranty matters when you're debugging at 2AM – Schneider's local tech support actually answers the phone. It's not the cheapest option out there, but in my experience, the reduced downtime pays for itself fast.
Keep It Running SmoothlyMount it on standard 35mm DIN rail with at least 10mm clearance on both sides – those relays need airflow. Avoid placing near VFDs without shielding; I've seen EMI cause phantom triggers in poorly laid-out cabinets. For maintenance? Give the vents a quick blow-out during quarterly checks, and verify contact resistance yearly if switching high-current loads. Firmware updates are rare but critical – check Schneider's site before major overhauls.
Built to Standards That MatterCE, UL 61010-1, and RoHS certified – no compliance surprises during factory audits. The 365-day warranty covers both parts and labor, which feels increasingly rare these days. One plant manager mentioned how this gave his team peace of mind during a recent FDA audit for their pharmaceutical mixing station.
Getting It to Your BenchWe keep these in stock for quick turnarounds – typically ships within a week via your choice of FedEx, UPS, or DHL. Payment's straightforward: 50% upfront to lock the order, balance when it's ready to ship. For urgent projects, I've had clients get replacements the next day when they called before noon EST. Just remember to confirm your HS code with customs – that one detail has delayed more shipments than I care to admit.
