1.00mm-5.0mm Normal Diameter and Aluminum Wire With Coating Film Grade 1 2 3 Pakistan
US$ 4.00
500 - 4999 Kilograms
US$ 3.80
5000 - 17999 Kilograms
US$ 3.70
≥18000 Kilograms
Key Specifications
Get Latest Price
Type:
Insulated
Insulation Material:
EI/AIW
Conductor Material:
Aluminum
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Huilong A Grade and Electric Appliance 0.25 mm Enameled Copper Aluminum WireUS$ 3.70 - 4.00MOQ: 500 Kilograms -
ISO/UL Certificated Insulated Magnet Wire Enameled Aluminum Wire HuiLongUS$ 3.52 - 3.80MOQ: 500 Kilograms
-
200 Grade Microwave Transformer Coil Insulated Enameled Wire Electromagnetic CoilUS$ 3.75 - 4.00MOQ: 500 Kilograms
-
200 and 220 Class Enameled Aluminum Wire for Transformer QatarUS$ 3.75 - 4.00MOQ: 500 Kilograms
-
Enamlled Aluminium Winding Wire PakistanUS$ 3.75 - 4.00MOQ: 500 Kilograms
Type
Insulated
Conductor Material
Aluminum
Conductor Type
Solid
Model Number
Q(ZY/XY)-200
Brand Name
YONGDONG
Place of Origin
Shandong, China(Mainland)
Style:
Enameled Aluminum Wire
Shape:
Round
Insulation Material:
polyester-imide, Polyamide imide
Production Range:
0.20mm-5.0mm
Bobbin:
PT25-PT270
Product Description
Round Wire Diameter: 0.50mm Min. Diameter
Scope: 5awg-32awg/7swg-35swg
Product Name: 1.00mm-2.99mm normal diameter and aluminum wire with coating film Grade 1 2 3
Product Name |
QZ(G)-155 |
QZY-180 |
Q(ZY/XY)-200 |
Q(ZY/XY)-220 |
Thermal Class |
155, class F |
180, class H |
200, class C |
220, class N |
Coating Material |
PEW(G) |
EIW |
EI/AIW |
EI/AIW |
Cross Section Range (mm) |
0.5-6.0 |
0.5-6.0 |
0.5-6.0 |
0.5-6.0 |
Insulation Thickness (IEC) |
Grade 1
Grade 2
Grade 3
|
Grade 1
Grade 2
Grade 3
|
Grade 1 Grade 2 Grade 3 |
Grade 1 Grade 2 Grade 3 |
Standard |
GB/T6109.2
GB/T23312.4
IEC60317-3
|
GB/T6109.5
GB/T23312.5
IEC60317-8
|
GB/T6109.20
GB/T23312.7
IEC60317-13
|
GB/T6109.22
IEC60317-46
|
Product Details
Advantage
Techinical Data
Why do enamelled aluminium wires fail to bond properly?
During the use of enameled aluminum wire, cracking, patent leather or cracking may occur, it collectively referred to as adhesion problems for the following reasons:
1. The first coat of paint is too thin
2. The thickness of the paint is not uniform, one side is thick, the other side is thin.
3. Paint film thickness uneven at different courses.
4. The speed of the machine is not suitable, resulting in insufficient curing or over curing
5. The material problem of the insulating paint itself.
6.The diameter of enameled aluminum wire is not round.
That is all the reasons we often meet with the unqualified adhesion of enameled aluminum wire.
