Home > Electrical & Electronics > Optical Fiber, Cable & Wire > Electric Wire & Cable > Wire Aluminum 200 Class Enameled Winding for Motor and Transformer With RoHS UL REACH Certifications India
Wire Aluminum 200 Class Enameled Winding for Motor and Transformer With RoHS UL REACH Certifications India
US$ 3.95
500 - 4999 Kilograms
US$ 3.61
≥5000 Kilograms
Key Specifications
Get Latest Price
Type:
Insulated
Insulation Material:
polyester-imide, Polyamide imide
Conductor Material:
Aluminum
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Wire Aluminum China's Electrical Supplies High Specification 220 Class Enameled Winding Wire IndiaUS$ 3.50 - 3.90MOQ: 500 Kilograms -
Wire Aluminum Conductor Class 200 Enameled Round Wire SWG6-32 IEC-60317 Standard IndiaUS$ 3.54 - 3.84MOQ: 500 Kilograms
-
Wire Aluminum Winding Heat Resistance 200 Class AWG 4-32 Round Aluminum Enameled Wire for Motor and Transformer IndiaUS$ 3.51 - 3.90MOQ: 500 Kilograms
-
Wire Aluminum Winding Motor Capacitor Starter AWG4-32 IEC-60317 Enameled Magnet Wire ISO UL REACH ROHS CertificationUS$ 3.60 - 3.90MOQ: 500 Kilograms
-
Wire Aluminum Winding UL ISO9001 Certification Enameled Insulation Polyamideimide Composite Polyester Enamel IndiaUS$ 3.85 - 4.15MOQ: 5 Kilograms
Type
Insulated
Conductor Material
Aluminum
Conductor Type
Solid
Model Number
Q(ZY/XY)-200
Brand Name
YONGDONG
Place of Origin
Shandong, China(Mainland)
Diameter:
AWG/SWG
Style:
Enameled Aluminum Wire
Shape:
Round
Heat-resisting class:
C class
Insulation Material:
polyester-imide, Polyamide imide
Production Range:
0.20mm-5.00mm
Certification:
ULE234565 ROHS REACH
Bobbin:
PT25 PT30 PT60 PT200 PT270
Color
Brown
Conductor
Aluminum
Product Description
Round Wire Diameter: 0.2mm-5.00mm (4awg-32awg/6swg-35swg) Magnetic wire swg
Product Name: 200 class enameled aluminum wire for transformer cleaning machine
SWG AWG Gauge Class 130-220 Enameled Aluminum Round Wire Price for Rewinding of Motors
Product Name | QZ(G)-155 | QZ-180 | Q(ZY/XY)-200 | Q(ZY/XY)-220 |
Thermal Class | 155, class F | 180, class H | 200, class C | 220, class N |
Coating Material | PEW(G) | EIW | EI/AIW | EI/AIW |
Cross Section Range (mm) | 0.20-5.00 | 0.20-5.00 | 0.20-5.00 | 0.20-5.00 |
Insulation Thickness (IEC) | Grade 1 Grade 2 Grade 3 | Grade 1 Grade 2 Grade 3 | Grade 1 Grade 2 Grade 3 | Grade 1 Grade 2 Grade 3 |
Standard | GB/T6109.2 GB/T23312.4 IEC60317-3 | GB/T6109.5 GB/T23312.5 IEC60317-8 NW30 | GB/T6109.20 GB/T23312.7 IEC60317-13 NW35 | GB/T6109.22 IEC60317-46 NW16 |
PT200 spool | 410*410*660 mm 65-75KG | 410*410*660 mm 65-75KG | 410*410*660 mm 65-75KG | 410*410*660 mm 65-75KG |
