Home > Electrical & Electronics > Optical Fiber, Cable & Wire > Electric Wire & Cable > Insulated Winding Enamel Wire Manufacturers Aluminium Wire for Ceiling Fan Motor and Transformer AWG4-32 Egypt
Insulated Winding Enamel Wire Manufacturers Aluminium Wire for Ceiling Fan Motor and Transformer AWG4-32 Egypt
US$ 4.36
500 - 4999 Kilograms
US$ 3.96
≥5000 Kilograms
Key Specifications
Get Latest Price
Type:
Insulated
Insulation Material:
polyester-imide,polyamide-imide
Conductor Material:
Aluminum
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Top Grade Insulated Winding Wire Enamel Aluminum Ceiling Fan Electrical Wires IEC-60317 With UL Certification EgyptUS$ 4.08 - 4.49MOQ: 500 Kilograms -
Factory Direct Supply AWG/SWG 200/220 Grade Aluminum Enameled Wire Insulated Winding Electrical Wires ThailandUS$ 3.85 - 4.30MOQ: 500 Kilograms
-
Hot Sales Insulated Winding Wire Enameled Aluminum Wire SWG 21 22 23 for Transformer and Fan Motor GermanyUS$ 4.05 - 4.35MOQ: 500 Kilograms
-
Manufacturer Price AWG4-32 Electric Motor Winding Wire Aluminium Insulated Winding Wires IEC-60317 NEMA Standard GermanyUS$ 3.99 - 4.38MOQ: 500 Kilograms
-
IEC-60317 Standard AWG6-32 Enameled Aluminum Round Wire for Transformer UL ISO9001 Certification GermanyUS$ 3.88 - 4.18MOQ: 500 Kilograms
Type
Insulated
Conductor Material
Aluminum
Conductor Type
Solid
Model Number
EI/AIW-220
Brand Name
YONGDONG
Place of Origin
Shandong, China(Mainland)
Diameter:
AWG/SWG
Style:
Enameled Aluminum Wire
Shape:
Round
Heat-resisting class:
C class
Insulation Material:
polyester-imide, Polyamide imide
Production Range:
0.20mm-5.00mm
Certification:
ROHS REACH ISO9001
Bobbin:
PT25 PT30 PT60 PT200 PT270
Standard
IEC NEMA GB JIS
Conductor
Aluminum
Product Description
Round Wire Diameter: 0.6mm-5.00mm (4awg-32awg) Magnetic wire swg
Product Name: 2020 PT200 spool EI/AIW 200 class enameled aluminum wire for transformer
SWG AWG Gauge Class 130-220 Enameled Aluminum Round Wire Price for Rewinding of Motors
Product Details
Advantage
Techinical Data
Product Name |
QZ(G)-155 |
QZ-180 |
Q(ZY/XY)-200 |
Q(ZY/XY)-220 |
Thermal Class |
155, class F |
180, class H |
200, class C |
220, class N |
Coating Material |
PEW(G) |
EIW |
EI/AIW |
EI/AIW |
Cross Section Range (mm) |
0.60-5.00 |
0.60-5.00 |
0.60-5.00 |
0.60-5.00 |
Insulation Thickness (IEC) |
Grade 1
Grade 2
Grade 3
|
Grade 1
Grade 2
Grade 3
|
Grade 1 Grade 2 Grade 3 |
Grade 1 Grade 2 Grade 3 |
Standard |
GB/T6109.2
GB/T23312.4
IEC60317-3
|
GB/T6109.5
GB/T23312.5
IEC60317-8
NW30
|
GB/T6109.20
GB/T23312.7
IEC60317-13
NW35
|
GB/T6109.22
IEC60317-46
NW16
|
