US$ 78 - 260 MOQ: 1 Piece
Key Specifications
Get Latest Price
Type:
Side Window
Certification:
ECE
Warranty:
1 year after ETD
Contact Supplier Request Quote Chat Now
Anhui Maygood RV Accessories Co., Ltd
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
15 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Side Window
Certification ECE
Warranty 1 year after ETD
Function Other
Glass Composition Other, Acrylic
Main Market North America
Glass Laminated Glass
Mgnt Certification Other, ISO9001
Main Material Aluminum, acrylic, ABS
Color Black outer frame, white inner frame
Cut-out Corner Radius 4R70mm
For wall thickness 25-35mm, 32-42mm or 40-50mm, or over 50m
Certificate E13
Application For all kinds of RV, special vehicles
Transport Package Plywood case or cartons
Specification MG20RW
Trademark MAYGOOD or OEM
Origin China

Maygood MG20RW flat acrylic side-hinged RV window combines an outer frame and one inner frame. Its unique designe is the flat external window glass with a round corner cut-out hole. It is suitable for a variety types of RVs, including caravan, camper trailer, motorhome, campervan, conversion van, special vehicles, etc.


DESCRIPTIONS AND FEATURES

  • Main Components: black high quality powder coated aluminum frame, double glazing transparent gray glas, equipped with white ABS inner frame for standard window, with roller blind and flynet

  • Fitting Thickness: 25-35mm, 32-42mm, 40-50mm, over 50mm

  • Fitting Way: clamping installation

  • Outer frame and inner frame assembled separately

  • Several types inner frames for choosing

  • Different types window struts for variety opening positions.

  • Could fit for a wide range of wall thickness demand

  • Window glass could be with anti-scratch feature

  • Customized sizes are accepted

Main Functions

Open, close, ventilate, insulate, provide privacy, allow sunlight in, prevent insects and good water seal. Can act as emergency exit, when the screen and blind are unlock and window open.



Wide Applications

MG hinged side window series are designed for a variety types of RVs, including caravan, camper trailer, motorhome, campervan, conversion van, special vehicles etc.



AVAILABLE SIZES

Ser.

Product Code

Cut-out Size(W*H) (mm)

 Cut-out Corner Radius(mm)

1

20RW-500350

500*350

 4R70

2

20RW-500400

500*400

 4R70

3

20RW-500450

500*450

 4R70

4

20RW-500500

500*500

 4R70

5

20RW-600600

600*600

 4R70

6

20RW-700300

700*300

 4R70

7

20RW-700400

700*400

 4R70

8

20RW-700500

700*500

 4R70

9

20RW-700800

700*800

 4R70

10

20RW-800400

800*400

 4R70

11

20RW-800500

800*500

 4R70

12

20RW-900450

900*450

 4R70

13

20RW-900500

900*500

 4R70

14

20RW-900550

900*550

 4R70

15

20RW-900900

900*900

 4R70

16

20RW-1000400

1000*400

 4R70

17

20RW-1000500

1000*500

 4R70

18

20RW-1000600

1000*600

 4R70

19

20RW-1000800

1000*800

 4R70

20

20RW-1100450

1100*450

 4R70

21

20RW-1100550

1100*550

 4R70

22

20RW-1200350

1200*350

 4R70

23

20RW-1200500

1200*500

 4R70

24

20RW-1300600

1300*600

 4R70

25

20RW-1450550

1450*550

 4R70

26

20RW-1455605

1455*605

 4R70


W: width of the window fitting surface; H：height of the window fitting surface, unit:mm

We accept ther customized sizes, please contact us to know more details.
