BNC Female to F Female Adapter for Signal Transmission Systems
≥1 Acres
- 2
- T/T L/C Money Gram PayPal D/P Western Union Other
- 2 days
You May Like
-
BNC Male Compression Connector With RG59/U RG6/U Compatibility
-
Robust Bridge Tractor Featuring Quick-Release Upper Transmission for Easy Cable Placement and Retrieval
-
Heavy Duty Bamboo Winch 54KN Max Pulling Capacity 2020x1570x1170mm Dimensions for Forestry Use
-
Professional Bamboo Winch for Concentrated Collection Points in Hilly/Mountainous Applications
-
Dual-Control Bamboo Winch With Manual and Remote Operation for Efficient Bamboo Harvesting
-
Industrial Bamboo Winch With 12mm Wire Diameter and Safety Emergency Stop Features
Product Details
| Application | Other, CCTV, Broadcast Equipment, Test Instruments | Connector Type | BNC Female to F Female | |
| Interface Standard | IEC 169-2 | Impedance | 50 Ohm / 75 Ohm | |
| Frequency Range | 0-4 GHz | Body Material | Brass with Nickel Plating | |
| Dielectric Material | PTFE | Operating Temperature | -40°C to +85°C | |
| VSWR | 1.3 max |
Product Description
The BNC Female to F Female Adapter delivers uncompromising signal integrity for professional RF systems. Engineered for precision connectivity, this adapter enables seamless transitions between BNC and F-type interfaces in critical signal transmission applications.
With its corrosion-resistant nickel-plated brass body and low-loss PTFE dielectric, this adapter maintains stable impedance matching across a broad frequency spectrum up to 4 GHz. The double-female configuration allows flexible integration with existing cable assemblies while minimizing signal reflections.
Key Technical Specifications:
| Parameter | Specification |
|---|---|
| Insertion Loss | ≤0.3 dB @ 3 GHz |
| VSWR | 1.3:1 max |
| Durability | 500+ mating cycles |
| Thread Engagement | Full 360° continuous |
Performance Advantages:
- ⚡ Phase-Stable Design: Minimizes group delay variation for time-sensitive applications
- 🔧 Tool-Free Installation: Bayonet locking mechanism ensures rapid deployment
- 🌧️ Environmental Sealing: IP67-rated variants available upon request
- 📡 Cross-Platform Compatibility: Bridges SDI, composite video, and RF test equipment
Industry-Specific Applications:
- Broadcast studios converting legacy F-type satellite feeds to BNC-based routing systems
- Security installations integrating analog cameras with modern digital recorders
- Field technicians maintaining cellular tower monitoring equipment
FAQ Section
Q: Does this adapter support HD-SDI signal transmission?
A: Yes, the 75Ω version meets SMPTE 292M specifications for 1.485 Gb/s signals.
Q: Can I use this for antenna impedance matching?
A: The 50Ω variant is suitable for VHF/UHF applications up to 500 MHz.
Q: Are torque specifications provided for installation?
A: Recommended tightening torque is 7-10 in-lbs for optimal RF performance.
Q: How does temperature affect performance?
A: Our temperature-compensated design maintains ≤0.1 dB insertion loss variation across operating range.
Q: Are custom connector configurations available?
A: Contact our engineering team for application-specific solutions.
Experience signal transparency that preserves waveform integrity from input to output. Our adapters undergo rigorous time-domain reflectometry testing to ensure consistent performance in mission-critical installations.
Request sample units for bench testing or discuss bulk pricing options with our technical sales representatives today.
