Industrial Automatic EPS Foam Cold Press Machine Polystyrene Foam Compactor Foam Block Recycling Machinery
US$ 2196 - 3296
MOQ: 1 Set
Key Specifications
Get Latest Price
place of origin:
Henan, China
brand name:
Panqi
voltage:
380 V
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
EPE EPS Plastic Foam Cold Pressing Crushing Recycling CompactorUS$ 2196 - 3850MOQ: 1 Set -
Waste Foam Balers Efficient Briquetting Machine for Recycling Foam WasteUS$ 2500.00 - 3000.00MOQ: 1 Set
-
Waste Foam Balers Efficient Briquetting Machine for Recycling Foam WasteUS$ 2500.00 - 3000.00MOQ: 1 Set
-
New Polystyrene Recycling Machine EPS Foam Recycling EquipmentUS$ 2500.00 - 3000.00MOQ: 1 Set
-
2024 Factory Direct Sales of Popular Efficient Foam Block Forming MachinesUS$ 2500.00 - 3000.00MOQ: 1 Set
place of origin
Henan, China
brand name
Panqi
voltage
380 V
dimension(l*w*h)
4200*1000*1500
Foam Product
Polyethylene Foam, Polystyrene Foam, Polypropylene Foam
power (kw)
22
weight (kg)
700
warranty
1 Year
key selling points
Automatic, High-Accuracy, High Safety Level
machinery test report
Provided
video outgoing-inspection
Provided
core components
Engine, Motor, Gearbox
Product Overview:
Foam cold press is also called waste foam cold press, foam compactor, foam briquetting machine, foam compressor, foam extruder, foam volume reduction machine, etc. It is a kind of equipment that first crushes the waste foam and then uses spiral extrusion to form it.
Working Principle
Foam cold press machine is a foam machine that first crushes the foam and then extrudes it into shape according to the spiral rotation. It can effectively reduce the volume of the foam by multiples and increase the density. It is convenient for the transportation and recycling of waste foam.
Product Model
Model |
Output(Kg/h) |
Specification(mm) |
power(Kw) |
Power Input |
Vertical300 |
100-150 |
3200*1000*1500 |
15 |
380V |
Vertical350 |
150-200 |
3700*1000*1500 |
18.5 |
380V |
Vertical400 |
200-250 |
4200*1000*1500 |
22 |
380V |
Horizontal300 |
150-200 |
3800*1300*800 |
15 |
380V |
Horizontal400 |
300-400 |
4200*1500*1000 |
22 |
380V |
There are many product specifications and models
The foam cold press has a wide variety of product specifications. Different specifications are mainly reflected in core parameters such as processing capacity, power, body size, compression ratio, and feeding method to adapt to the needs of different scenarios
1. Horizontal: large processing capacity (100-500kg per hour) focuses on "high efficiency and batch processing", strong continuous operation stability, suitable for large recycling plants, logistics warehouses and other centralized processing scenarios, and can be connected to the back-end transportation/storage system.
2. Vertical: medium processing capacity (30-150kg per hour) focuses on "space saving, flexibility and convenience", suitable for small and medium-sized recycling stations and stores, mainly intermittent operations, and more manual intervention.
3. The mobile vehicle-mounted type has a small processing capacity (20-100kg per hour), which is limited by the vehicle power and is suitable for decentralized recycling (such as communities and exhibition sites). It is compressed as it is collected to avoid foam occupying transportation space.
Foam cold pressing machine structure composition
1. Power system: The motor (or hydraulic device) provides power to drive the compression components.
2. Compression system: The screw propeller (commonly used for horizontal) or the vertical pressure rod (commonly used for vertical) squeezes the foam through mechanical pressure to achieve volume reduction.
3. Feeding device: Top (vertical) or side (horizontal) feeding port, some are equipped with crushers to pre-crush large foam blocks.
4. Discharge port: discharge high-density compressed blocks, mostly in the shape of columns or blocks.
5. Frame and shell: support the main structure, protect the internal components, and some models have moving wheels (small machines).
6. Control system: adjust parameters such as speed and pressure to achieve automatic or manual operation.
Features of Foam Cold Press
1: Foam cold press is non-toxic, odorless, and environmentally friendly
2: The foam cold press can be operated on the car, which is convenient and efficient
3: The foam cold press type EPS briquetting machine directly pushes and squeezes EPS foam, refrigerator liner, and PU foam without heating
4: The foam cold press has a large compression ratio and can reduce the volume by 50 times at most. The foam volume is reduced by 8 times
5: The foam cold press saves storage space and transportation and warehousing costs
6: The EPS material compressed by the foam cold press is easy to recycle.
7: The large-scale foam cold press can be operated synchronously with the conveyor belt to improve production efficiency.
Application fields of foam cold press
1. Foam recycling field: processing of domestic/industrial waste foam (such as packaging foam, scraps), which is convenient for transportation and recycling after volume reduction.
2. Logistics e-commerce warehousing: compressing foam waste after unpacking, reducing storage space and transportation costs, and helping recycling and cashing out.
3. Manufacturing waste treatment: compressing foam scraps and defective products in the production process to achieve internal recycling or recycled raw materials.
4. Environmental protection and solid waste treatment: used for foam volume reduction in garbage transfer stations, improving the utilization rate of recyclables, and building a "recycling-regeneration" closed loop.
5. Special scenarios: on-site compression of foam waste in the fields of shipping, aviation, agriculture, etc., saving space and reducing pollution.
Application effect of foam cold press
1. Substantially reduce volume and reduce costs
It can compress the volume of loose foam to 1/30-1/50 of the original volume, significantly reduce the demand for transportation and storage space, reduce logistics and storage costs, and is especially suitable for recycling and waste treatment scenarios.
Promote resource regeneration and improve efficiency. The compressed foam blocks can be directly used as recycled raw materials for downstream enterprises to process into particles, plates, etc., to achieve "waste into treasure" and create economic value for the recycling industry chain.
2. Simplify the processing process and improve efficiency
No heating is required, it can be quickly compressed at room temperature, easy to operate, and can be adapted to the instant treatment of foam waste in multiple scenarios such as life, industry, and logistics, and improve the efficiency of recycling and solid waste treatment.
3. Help environmental protection and reduce pollution
Reduce the environmental problems caused by the random discarding or incineration of foam, promote the "reduction and resource utilization" of foam plastics, and meet the requirements of circular economy and environmental protection.
FAQ
Q:1.Are you a manufacturer, trading company or a third party?A:We are a manufacturer, located in Located at Miaowang Road, Xingyang, Zhengzhou,Henan, China. Warmly welcome to
visit our company.
Q:2. What is your minimum order quantity, can you send me samples?
A:Our minimum quantity is 1 set, as our product is machinery equipment, it's difficult to send you samples, if you have any questions about the products, please feel free to contact us for more detail, we are glad to provide you more information such as specifications, video, etc.
Q:3. How does your factory do regarding quality controlling?
A:(1) All raw material we used are thickening.
(2) Skillful workers care every details in handling the producing and packing process.
(3) Quality control department are specially responsible for quality in each process.
We have been kept providing high quality products by introducing advanced technologies for over 10 years, and our products are also widely exported to many different countries including Russia, the Middle East, Africa, Southeast Asia, EU, etc, which earned us a high reputation among the customers.
Q:4.What is the delivery time of your machine?
A:In general, the delivery time of our machine is about 30 days, customized machine will be delivered as the negotiation with our clients.
Q:5.How about the after-sale service?
A:(1)TM online for 24 hours, also contact by email, skype, MSN, whatsapp, etc.
(2)To solve the problems with videos/pictures.
(3)One year warranty for spare parts change.
