Help CenterHoneywell CC-TUIO31: Your Universal I/O Workhorse for Tough Industrial Environments
Related Products
-
Honeywell FC-TSGAS-1624P: Your Reliable Field Termination Hub for Process ControlUS$ 3456.00MOQ: 1 Blade -
HONEYWELL TC-0AV081: Rock-Solid Analog Output for Process Control StabilityUS$ 3456.00MOQ: 1 Blade
-
HONEYWELL XFR824A – 24 Vac Control Transformer for Reliable Panel PowerUS$ 3456.00MOQ: 1 Blade
-
Honeywell CC-PFB402 Bus Interface ModuleUS$ 10000 - 15000MOQ: 1 Set
-
Honeywell CC-PAIM01 Low-level Analog Input ModuleUS$ 10000 - 15000MOQ: 1 Set
• 8 universal inputs that auto-detect signal types—meaning you can connect legacy pressure sensors alongside new digital transmitters without configuration headaches
• IP66-rated housing that shrugs off coolant splashes in machine tool environments (I’ve seen these survive 3 years in automotive paint shops with zero corrosion)
• HART communication support—pull diagnostic data during runtime instead of taking production lines offline for sensor checks
• Hot-swap capability that avoids full system shutdowns; one plant manager told me this feature alone paid for the module during their last unplanned maintenance window
| Specification | Details |
|---|---|
| Brand/Model | Honeywell CC-TUIO31 |
| HS Code | 8537.10.90 (Programmable controllers) |
| Power Requirements | 24V DC ±15%, 1.2A max (typically draws 0.8A during peak comms) |
| Dimensions & Weight | 120 x 100 x 75mm / 420g (fits standard 35mm DIN rails) |
| Operating Temperature | -20°C to +70°C (derate above 55°C ambient) |
| Signal I/O Types | 8 universal analog inputs (±10V, 0-20mA, J/K/T thermocouples, Pt100), 4 relay outputs |
| Communication | Modbus RTU over RS-485, HART 7 protocol support |
You'll typically find these in chemical processing plants monitoring reactor temperatures with mixed sensor types, or in food manufacturing lines where washdown environments demand sealed electronics. Last month, a customer in Wisconsin used them to retrofit an aging bottling line—they connected legacy flow meters and new pressure transducers without replacing any field wiring. In pulp mills, the vibration resistance matters more than specs suggest; I’ve heard multiple reports of these outlasting cheaper modules near centrifugal pumps.
Look, if you're comparing sticker prices alone, there are cheaper options. But factor in the 365-day warranty (most competitors offer 180 days) and the fact that Honeywell’s firmware updates prevent obsolescence—this pays off when your control system lives 10+ years. Compatibility is rarely an issue; we’ve integrated these with Siemens PLCs and legacy Allen-Bradley systems without custom gateways. And about ordering: 50% upfront gets it shipped in 1 week if in stock (FedEx/UPS/DHL), with full payment before delivery. No nasty surprises.
Keep It Running SmoothlyMount it in a NEMA 12 cabinet with at least 50mm clearance on all sides—those relay outputs generate more heat than the datasheet admits during continuous switching. Always torque terminal screws to 0.6 Nm; under-tightening causes intermittent faults that drive engineers crazy. For maintenance, clean vents quarterly in dusty environments (a shop vac works fine), and check HART diagnostics monthly. Firmware updates? Only when Honeywell pushes critical fixes—no need to chase every minor revision. One caveat: avoid daisy-chaining more than 32 modules on RS-485 networks; signal degradation becomes noticeable beyond that.
Certified for Real-World UseCarries CE, UL 61010-1, and RoHS certifications—no customs headaches in most regions. The 3-year limited warranty covers field failures (excluding lightning strikes, which happen more often than you’d think in Midwest grain facilities). Oh, and ISO 9001 manufacturing means batch consistency; I’ve never seen channel-to-channel variance exceed 0.1% across multiple production runs.
