Engineered for demanding industrial environments, our ANSI Thread Ball Valve delivers reliable flow control in oil and gas pipeline applications. Featuring robust construction compliant with American National Standards Institute specifications, this valve ensures leak-proof performance under high-pressure conditions. Manufactured by Chengxin Valve with over 30 years of industry expertise, it combines durability with operational efficiency to minimize maintenance downtime in critical infrastructure.
Core Technical Advantages:
Corrosion-resistant construction suitable for hydrocarbon media
Full-port design minimizes pressure drop across the valve
Fire-safe design with secondary metal sealing capability
Blow-out proof stem prevents seal failure under pressure surges
Technical Specifications:
| Body Material | A105 Carbon Steel (Standard) | SS316 Optional |
| Thread Standard | ANSI B1.20.1 NPT | BSPP Available |
| Max Working Pressure | Class 150: 285 PSI | Class 300: 740 PSI |
Installation & Maintenance Benefits:
Quarter-turn operation enables rapid shutoff during emergencies
Integral stem backstop prevents over-rotation damage
Standard wrench flats accommodate installation in confined spaces
Optimize your pipeline integrity with valves manufactured in our 75,000㎡ ISO-certified facility. All products undergo rigorous hydrostatic testing at 1.5 times working pressure before shipment. Contact our technical team for custom configurations including extended stems, locking devices, or pneumatic actuation options.
Frequently Asked Questions
Q: What pipeline fluids are compatible with this valve?
A: Designed specifically for crude oil, natural gas, refined petroleum products, and non-corrosive process fluids. Chemical compatibility charts available upon request.
Q: Are certification documents provided?
A: All valves include material test reports and ISO 9001 manufacturing certificates. Pressure test records provided for specific orders.
Q: What is the lead time for customized orders?
A: Standard configurations ship in 15-20 days. Customized orders typically require 30-45 days production time.
Q: Can this valve handle sour gas applications?
A: NACE MR0175 compliant versions available for H₂S-containing environments. Specify sour service requirements when ordering.
Q: What maintenance is required?
A: Periodic lubrication of stem assembly recommended. Seat replacement possible without removing valve from pipeline.
Q: How do I determine the correct size?
A: Provide pipe schedule, fluid type, temperature, and pressure parameters. Our engineers will recommend appropriate sizing.
