Water Chiller Cw3000/5000/5200/6000 Co2 Laser Tube for Laser Cutting/engraving Machine

US$ 105 - 700 MOQ: 1 Unit

Key Specifications

Standard Component:

Standard Component

Customized:

Non-Customized

Type:

Other, water chiller

Nantong ShunPing Intelligent Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

7 days

Standard Component Standard Component

Customized Non-Customized

Type Other, water chiller

Features：
1.Energy saving,compact size,long working life and simple operation;
2.Applicable to different applied occasion,with various setting and display function;
3.Alarm functions:water flow alarm and over high/low temperature alarm,compressor time-delay protection,compressor over current protection.
Technical parameters:
Model	CW3000	CW5000	CW5200	CW6000	CW6100	CW6200
Voltage	AC 1P 220V/110V	AC 1P 220V/110V	AC 1P 220V/110V	AC 1P 220V/110V	AC 1P 220V	AC 1P 220V
Frequency	50/60HZ	50/60HZ	50/60HZ	50/60HZ	50/60HZ	50/60HZ
Current	0.45-0.5A 220V;	1-2.1A 220V;	2.4-3.3A 220V;	1-6A 220V;	1-8.5A 220V	1-9A 220V
	0.9-1.0A 110V	3.5-5.6A 110V	4.5-6.5A 110V	1-11A 110V
Temperature control range	/	5-35℃	5-35℃	5-35℃	5-35℃	5-35℃
Temperature precision	/	±0.3℃	±0.3℃	±0.5℃	±0.5℃	±0.5℃
Support dual temperature control	/	/	/	support	support	support
Refrigeration capacity	50W/℃	0.692-0.879KW	1.46-1.52KW	2.785-3.015KW	4.13-4.24KW	5.13-5.17KW
Options of refrigerant	/	R22/R134a	R22/R134a/R410a	R22/R410a/407c	R22/R410a/407c	R22/R410a/407c
Flow rate	2-13L/min	10-16L/min	10-16L/min	13-70L/min	13-70L/min	13-70L/min
Pump power	/	0.03-0.1KW	0.03-0.1KW	0.05-0.75KW	0.05-0.75KW	0.05-0.75KW
Pressure	10-70M	10-25M	10-25M	12-53M	12-53M	12-53M
Cooling type	air cooing	compressor refrigeration	compressor refrigeration	compressor refrigeration	compressor refrigeration	compressor refrigeration
