Help CenterFOXBORO P0916PH / P0916JS Terminal Block Module – Reliable Field Wiring Interface for I/A Series FBMs
Related Products
-
FOXBORO P0916XT Contact Sense Input Module – Reliable Dry-contact Monitoring for Foxboro DCSUS$ 2560.00MOQ: 1 Blade -
Foxboro P0917MF Control Processor – Reliable CPU Module for I/A Series (200 Series) Distributed ControlUS$ 2560.00MOQ: 1 Blade
-
Foxboro P0917XV Compression Termination Assembly – Clean, Reliable Field Wiring for I/A Series FBM I/OUS$ 2560.00MOQ: 1 Blade
-
Foxboro P0924JH Compact Power Supply – Stable Backplane Power for Foxboro Compact/200 Series I/OUS$ 2560.00MOQ: 1 Blade
-
Foxboro P0926GH Communication Terminal – Reliable Field Termination for Foxboro DCS Serial CommunicationsUS$ 2560.00MOQ: 1 Blade
Warranty: 365 days
Delivery: 1 week for in-stock items; no more than one month at the latest
Payment: 50% advance payment; full payment prior to delivery
Express options: FedEx, UPS, DHL
I/A Series compatibility: Purpose-built termination for FOXBORO FBM I/O, helping keep channel mapping consistent with project documentation.
Passive, no-power design: There’s no active electronics in many cases, which typically means low failure rates and easier troubleshooting.
Field signal versatility: Suited for common analog (4–20 mA, mV) and discrete I/O when paired with the appropriate FBM type.
Front-access terminals: Clear labeling and easy access for commissioning, loop checks, and periodic maintenance.
Shield and grounding provisions: Practical shield termination points help reduce noise in sensitive analog loops.
Cabinet-friendly footprint: Compact format that fits neatly into DCS marshalling panels and reduces wiring congestion.
Stable connections: Robust terminal design that holds up well under vibration commonly found in process environments.
| Brand / Model | FOXBORO P0916PH / P0916JS Terminal Block Module |
| HS Code | 8538.90 (Parts suitable for use with electrical control apparatus) |
| Power Requirements | Not powered (passive termination) |
| Operating Temperature | Typically 0 to 60°C when installed in a ventilated control cabinet |
| Signal Input/Output Types | Field termination for analog (e.g., 4–20 mA, mV) and discrete signals, depending on paired FBM |
| Communication Interfaces | N/A – passive terminal block |
| Installation Method | Cabinet mounting for DCS marshalling; front-access terminal wiring |
| Dimensions & Weight | Compact FBM-aligned footprint suitable for dense panel layouts |
Note: Channel count and wiring details vary by FBM type; select the variant that matches your specific FBM and signal mix.
These terminal blocks are used wherever FOXBORO I/A Series FBMs are installed—chemical and petrochemical units, oil & gas gathering and refining, power generation, water & wastewater plants, pharmaceuticals, and pulp & paper. One thing I appreciate is how they simplify brownfield work: you can refresh a cabinet, preserve channel numbering, and bring loops back online without re-engineering the entire rack.
Advantages & ValueReliability: Passive design means fewer failure points and easier diagnostics in many cases.
Compatibility: Fits established I/A Series marshalling practices, reducing risk and avoiding custom adapters.
Cost control: Keeps replacement scope focused on terminal infrastructure instead of full I/O module swaps.
Faster turnaround: Quick installation helps during turnarounds and unplanned maintenance.
Traceable supply: We source with serial traceability where available and function-test prior to shipment.
Cabinet environment: Install in a clean, ventilated control cabinet (IEC 60204/UL 508A practices). Keep ambient within the system’s rated range and avoid direct heat sources.
Wiring: Use properly sized conductors; separate low-level analog from inductive loads; maintain shield continuity with designated grounding points. Torque terminals per typical control-panel practice.
Channel mapping: Follow the I/O list and FBM-specific wiring diagrams. You might notice some variants include jumpers or fusing—set these per the FBM manual.
Routine checks: Periodically re-torque terminals, inspect for insulation wear, and clean dust using dry air. Label updates are worth the few minutes they take.
No firmware: As a passive termination product, there’s no firmware to update, which keeps maintenance simple.
ESD care: Handle in accordance with plant ESD procedures when working near active FBMs and I/O harnessing.
Compliance: Typically supplied to CE and RoHS requirements for industrial control components; UL recognition is common for Foxboro panel hardware.
Manufacturing quality: Produced under ISO 9001 quality systems in most cases.
Warranty: 365-day warranty from us; manufacturer’s original standards apply where applicable.
You might notice that plants standardize on a single terminal block variant to simplify spares, but in mixed I/O cabinets it often pays to match P0916PH or P0916JS to the exact FBM type. If you share the FBM models you’re pairing with, we’ll verify the variant so channel allocation, shield terminations, and loop polarity line up correctly the first time.
