Help CenterFSM050NPTR
Related Products
Electricalcharacteristics | ||||||
Tpye |
FSM006NPTR |
FSM015NPTR |
FSM025NPTR |
FSM050NPTR |
||
IPN |
Primarynominalinput current |
6 |
15 |
25 |
50 |
A |
IP |
Measuringrangeof primarycurrent |
0～±18 |
0～±45 |
0～±75 |
0～±150 |
A |
RM |
Samplingresistance |
25±0.1% |
10±0.1% |
6±0.1% |
3±0.1% |
Ω |
VSN |
Nominaloutputvoltage |
0.625±0.5% |
0.625±0.5% |
0.625±0.5% |
0.625±0.5% |
V |
KN |
Turnsratio |
1:960 |
1:960 |
1:960 |
1:960 |
|
Vc |
Supplyvoltage |
+5(±5%) |
V |
Ic |
Staticpower consumption |
IP=0 |
mA |
Vd |
Insulationvoltage |
3KVRMS/50Hz/1minbetweenprimaryandsecondarysidecircuits |
|
εL |
Linearity |
%FS |
|
VO |
OffsetOutputvoltage |
2.5±0.5% |
V |
VO |
Referencevoltageoutput |
2.5±0.5% |
V |
RM |
Vref |
200 |
Ω |
VO |
Vref |
2.0-2.8 |
V |
X |
precision |
TA=25℃±0.5 |
% |
ƐL |
Linearity |
T=25℃±0.1 |
% |
VO |
Offsetvoltage |
IPN=0TA=25℃20±1% |
mV |
VOT |
ThermaldriftofV0 |
IP=0TA=-25～+85℃ |
mV/℃ |
TR |
Responsetime |
μs |
|
di/dt |
Followingaccuracy |
>50 |
A/μs |
f |
FrequencyBandwidth (-3dB) |
DC～150 |
kHz |
TA |
Ambientoperating temperature |
-40～+85 |
℃ |
TS |
Ambientstorage temperature |
-40～+125 |
℃ |
