FS-DKT5-Freesor-current Sensor New Energy Current Sensors

US$ 17.5 ≥96 Units

Key Specifications

Material:

Metal

Certification:

Accuracy Grade:

1.0G

Shanghai Freesor Sensor Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

14 days

Material Metal

Certification CE

Accuracy Grade 1.0G

Output Signal Type Analog Output

Production Process SemiConductor Integrated

Customized Customized

Application Switching Power Supply

Trademark Freesor

Origin China

Type		IpNRated inputcurrent		IPM Measuringcurrentrange
Type		CH1	CH2	CH1	CH2
FS20DKT5/600		20	600	20	600
FS20DKT5/500		20	500	20	500
FS30DKT5/150		30	-350/150	30	-350/150
FS30DKT5/350		30	350	30	350
FS60DKT5/600		60	600	60	600
FS75DKT5/500		75	500	75	500

Vcc	Supplyvoltage	@DC+5V±5%			V
Icc	Currentconsumption	@IpN			mA
Ris	Galvanicisolation	@500VDC>1000			MΩ
VouT	Ratedoutputvoltage	@RL=4.7K/25℃1/2Vcc±2			V
RouT	0utputinternaresistance	9			Ω
RL	Loadresistance	≥4.7			KΩ
DynamicCharacteristics
XG	Accuracy	@IpN,T=25℃			%
ƐL	Linearity	@IpN,T=25℃			%
VoE	VoEZerooffsetvoltage	@Ip=0,T=25℃1/2Vcc±0.01			V
VoM	Magneticoffsetvoltage	@IpN→0,T=25℃≤±10			mV
TCVOE	VoETemperaturevariationofVoE	@-40℃~125℃≤±0.5			mV/℃
TCVOUT	TemperaturevariationofVouT	@-40℃~125℃≤±0.5			mV/℃
di/dt	accuratelyfollowed	>100			A/us
Tr	Responsetime	@90%IPN			us
BW	-3dBCL=1nF25℃Bandwidth	DC～120			KHz
Generalcharacteristics
TA	0peratingtemperature	-40～+125			℃
Ts	Storagetemperature	-45～+125			℃
m	Mass(approx)	≈100			g
Insulationcoordination
Vd	Galvanicisolation	@50HZ,1min3.0			KV
