Interlocking Galvanized Steel Rings Rope Mesh Debris Flow Barrier Nets Cutting Bending Customizable Size for Rockfall Prevention
US$ 9 - 45
MOQ: 1 Square Meter
Key Specifications
Get Latest Price
Material:
Galvanized Steel Wire
Type:
Rope Mesh
Model Number:
r ring-7
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
China Factory 250-3000kJ Impact Resistance Steel Rope Ring Net Plain Weave Loop Mesh for Heavy Rockfall Custom Cutting ServiceUS$ 9 - 45MOQ: 1 Square Meter -
Cost Effective Flexible Woven Rockfall Barriers Stone Falling Ring Net Barrier for Explosion Protection in the Chemical IndustryUS$ 9 - 45MOQ: 1 Square Meter
-
HT Galvanized Steel Wire Woven Rope Mesh Flexible Shallow Landslide Barriers Energy-Absorbing Ring Net Cutting for SlopesUS$ 9 - 45MOQ: 1 Square Meter
-
RXE-500 Flexible Rockfall Protection Barriers System,High Tensile Ring Net Barrier for Intercepting RockfallUS$ 5.9 - 40MOQ: 1 Square Meter
-
Circular Link Rockfall Net Welded Mesh Galvanized Steel Wire Rope Ring Network Customizable Size for Mountainous AreasUS$ 5.9 - 40MOQ: 1 Square Meter
Model Number
r ring-7
Brand Name
longen
Place of Origin
Hebei, China
Delivery Time
8 ~ 14 days
Processing Service
Decoiling, Cutting, Bending
Weave Style
PLAIN WEAVE
Product name
flexible ring net barriers
Usage
prevent
Wire diameter
3mm steel wire
application
slope protection and reduce rockfall impact
Color
sliver
System Types
VX Barrier and UX barrier
Packing
customized packing
Feature
easy install/flexible
width
10-25m customized width
height
2-6m, customized height
Product Description
Engineered for extreme durability, our 3mm high-tensile steel ring nets (minimum 1770N/mm² strength rating) deliver exceptional energy absorption capabilities from 250kJ to 3000kJ impacts. Utilizing advanced steel wire bundling technology with 5-19 strand configurations, these flexible ring networks (available in 300mm/350mm diameters) seamlessly conform to complex topography while effectively distributing concentrated loads. Ideal for slope stabilization and rockfall protection, this innovative safety solution combines military-grade material strength with intelligent geometric design for maximum environmental adaptability in challenging terrain conditions.
The rocco ring net, also known as flexible ring net barriers, and rocco high tensile steel wire ring net are linked together using rings with a high tensile strength 3mm steel wire with a strength no less than 1770N/mm2. Anywhere between 5 and 19 spirals are bundled together into a ring measuring 30 or 35 in diameter to ensure an excellent buffering performance through its deformation.
It features outstanding energy absorption properties, making it applicable for both active and passive protection systems. which between 5 and 19 spirals are bundled together into a ring measuring 30cm or 35cm in diameter. It has good buffering performance through its deformation, and it is with outstanding energy absorption properties and has a wide application for active and passive protection systems.
The rocco ring net system is composed of an SNS slope protection mesh, steel wire mesh, decompression rings, supporting rope, sewing rope, steel column, boundary rope, wire rope anchor and other installation components. The buffering, absorbing, and supporting performances are exerted to ensure an effective slope protection performance.
The rocco ring net system is composed of an SNS slope protection mesh, steel wire mesh, decompression rings, supporting rope, sewing rope, steel column, boundary rope, wire rope anchor and other installation components. The buffering, absorbing, and supporting performances are exerted to ensure an effective slope protection performance.
Rocco Ring Net Bundling Types
The rocco ring net features three types of bundling rings: ordinary pressed connection, direct winding, and spiral winding, each
with an outstanding performance based on specific applications. The wire uniformly bears loads, features a simple appearance with
no button joints, and has no broken ring failures during loading.
It features outstanding energy absorption properties, making it applicable for both active and passive protection systems. which between 5 and 19 spirals are bundled together into a ring measuring 30cm or 35cm in diameter. It has good buffering performance through its deformation, and it is with outstanding energy absorption properties and has a wide application for active and passive protection systems.
The rocco ring net system is composed of an SNS slope protection mesh, steel wire mesh, decompression rings, supporting rope, sewing rope, steel column, boundary rope, wire rope anchor and other installation components. The buffering, absorbing, and supporting performances are exerted to ensure an effective slope protection performance.
The rocco ring net system is composed of an SNS slope protection mesh, steel wire mesh, decompression rings, supporting rope, sewing rope, steel column, boundary rope, wire rope anchor and other installation components. The buffering, absorbing, and supporting performances are exerted to ensure an effective slope protection performance.
Rocco Ring Net Bundling Types
The rocco ring net features three types of bundling rings: ordinary pressed connection, direct winding, and spiral winding, each
with an outstanding performance based on specific applications. The wire uniformly bears loads, features a simple appearance with
no button joints, and has no broken ring failures during loading.
Detailed Images
Specification
Steel ring net system
Steel wire rope net
Rocco Ring Net System Types
Rocco Ring Net System VX Barrier：For narrower V-cuttings
In smaller mountain torrents, we anchor debris flow barriers to the channel flanks with no posts, instead using spiral rope
anchors or self-drilling anchors with flexible anchor heads. The ring net is then hung from upper and lower support ropes
outfitted with braking rings with the use of shackles. This structure is suitable for a width of up to 15 meters and an
installation height of up to 6 meters.
Rocco Ring Net System UX Barrier: For wider, U-shaped Channels
The debris flows barrier for large mountain torrents is preferably supported by two posts in the river bed as well as with spiral rope anchors or flexible anchor heads. This structure is suitable for widths of about 25 meters and an installation height of up to 6 meters.
Rocco Ring Net System VX Barrier：For narrower V-cuttings
In smaller mountain torrents, we anchor debris flow barriers to the channel flanks with no posts, instead using spiral rope
anchors or self-drilling anchors with flexible anchor heads. The ring net is then hung from upper and lower support ropes
outfitted with braking rings with the use of shackles. This structure is suitable for a width of up to 15 meters and an
installation height of up to 6 meters.
Rocco Ring Net System UX Barrier: For wider, U-shaped Channels
The debris flows barrier for large mountain torrents is preferably supported by two posts in the river bed as well as with spiral rope anchors or flexible anchor heads. This structure is suitable for widths of about 25 meters and an installation height of up to 6 meters.
Debris Flow Barriers without posts Type |
VX060L-H4 |
VX080-H4 |
VX140-H4 |
VX100-H4 |
VX160-H4 |
Installation height |
2-4m |
2-4m |
2-4m |
5-6m |
5-6m |
Span width |
up to 10m |
up to 15m |
up to 15m |
up to 15m |
up to 15m |
Debris Flow Barriers with posts Type |
UX100-H4 |
UX160-H4 |
UX120-H6 |
UX180-H6 |
Installation height |
2-4m |
2-4m |
5-6m |
5-6m |
Span width |
up to 25m |
up to 25m |
up to 25m |
up to 25m |
Company Profile
Hebei Longen Wire Mesh – Your Trusted Partner for High-Quality Steel ring net
Located in Anping County, China (the "Hometown of Chinese Wire Mesh"), Hebei Longen Wire Mesh Products Co., Ltd. is a leading manufacturer specializing in slope protection mesh, gabion boxes/baskets, noise barriers, and Hexsteel Mesh. With years of expertise in design, production, and global export, we provide durable, cost-effective solutions for civil engineering, construction, and erosion control projects.
Why Choose Hebei Longen Wire Mesh?
1 Factory-Direct Pricing – Competitive rates with no middlemen
Why Choose Hebei Longen Wire Mesh?
1 Factory-Direct Pricing – Competitive rates with no middlemen
2 Premium Quality – Strict quality control for long-lasting performance
3 Free Samples Available – Test our products before bulk orders
4.Global Export Experience – Reliable shipping to 30+ countries (Southeast Asia, Australia, Europe, Americas, and more)
3 Free Samples Available – Test our products before bulk orders
4.Global Export Experience – Reliable shipping to 30+ countries (Southeast Asia, Australia, Europe, Americas, and more)
5.OEM/ODM Support – Customized solutions for your specific needs
Our Best-Selling Products:
Our Best-Selling Products:
Steel ring net-reduce and block the rockfalls and stones
Gabion Boxes/Baskets – Heavy-duty wire mesh for riverbank & coastal protection
Slope Protection Mesh – Reinforces soil and prevents landslides
Noise Barriers – Effective sound reduction for highways & urban areas
Hexsteel Mesh – Versatile wire mesh for construction & fencing
Get Your Quote Today!
Gabion Boxes/Baskets – Heavy-duty wire mesh for riverbank & coastal protection
Slope Protection Mesh – Reinforces soil and prevents landslides
Noise Barriers – Effective sound reduction for highways & urban areas
Hexsteel Mesh – Versatile wire mesh for construction & fencing
Get Your Quote Today!
FAQ
Q1: What are your payment terms?
A1: We accept wire transfer (T/T), Letter of Credit (L/C), Western Union, or payments via Alibaba. Terms: 30% deposit upfront, with the remaining 70% due before shipment. We provide photos and packaging details for your approval before final payment.
Q2: Do you offer after-sales support?
A2: Quality and service are our top priorities. Complimentary after-sales assistance is provided to ensure long-term satisfaction.
Q3: Can you produce custom-designed products?
A3: Yes, we specialize in bespoke manufacturing based on your designs, specifications, or technical drawings.
Q4: How do you justify your pricing?
A4: Our quotations include transparent cost breakdowns to demonstrate competitive and fair pricing.
Q5: Do you accept client-provided designs?
A5: Absolutely. We work closely with your designs to deliver tailored solutions.
A1: We accept wire transfer (T/T), Letter of Credit (L/C), Western Union, or payments via Alibaba. Terms: 30% deposit upfront, with the remaining 70% due before shipment. We provide photos and packaging details for your approval before final payment.
Q2: Do you offer after-sales support?
A2: Quality and service are our top priorities. Complimentary after-sales assistance is provided to ensure long-term satisfaction.
Q3: Can you produce custom-designed products?
A3: Yes, we specialize in bespoke manufacturing based on your designs, specifications, or technical drawings.
Q4: How do you justify your pricing?
A4: Our quotations include transparent cost breakdowns to demonstrate competitive and fair pricing.
Q5: Do you accept client-provided designs?
A5: Absolutely. We work closely with your designs to deliver tailored solutions.
