DIN cast iron globe valve range:
Size DN50~DN250
Pressure:PN10/PN16
DIN cast iron globe valve standard:
Design Standard:DIN 3356
Face to Face:DIN3202-F1
Flange Standard:DIN2532/DIN2533
Testing Standard:ISO 5208
Material of parts:
Body:Cast Iorn/Ductile Iron
Stem:2Cr13/SS304/SS316/Carbon Steel
Disc:A105+2Cr13,2Cr13
Seat:Brass
DIN Standard Compliant Globe Valve for Flange Systems, Size Range DN50 to DN2501. Product Overview
Our DIN standard compliant globe valve is a high - performance solution designed specifically for flange systems. With a size range spanning from DN50 to DN250, it caters to a wide variety of industrial applications. Manufactured by Chengxin Valve Co., Ltd., a reputable manufacturer established in 1993, this valve is built to the highest quality standards.
2. Compliance with DIN Standard
The valve strictly adheres to the DIN standard, which is well - recognized and respected in the international market. This compliance ensures that the valve meets the precise dimensional, material, and performance requirements set by the DIN specifications. It guarantees seamless integration into existing systems that follow the DIN standard, providing users with a reliable and compatible solution. Whether it is for replacement parts or new installations in regions where DIN standards are prevalent, such as parts of Europe, this valve is an ideal choice.
3. Sealing Form: Bellows Globe Valve
This valve features a bellows globe valve sealing form. The bellows design offers several advantages. Firstly, it provides excellent sealing performance, effectively preventing leakage of the medium flowing through the valve. This is crucial in applications where the medium may be hazardous, expensive, or environmentally sensitive. Secondly, the bellows act as a barrier, protecting the valve stem from the process fluid, which helps to extend the service life of the valve. It also reduces the risk of external contamination and corrosion, ensuring the long - term reliability of the valve.
4. Size Range and Versatility
The size range from DN50 to DN250 makes this valve highly versatile. The smaller DN50 size is suitable for applications with lower flow rates, such as in small - scale industrial processes or in some residential and commercial plumbing systems. On the other hand, the larger DN250 size can handle high - volume flow, making it appropriate for large - scale industrial plants, power generation facilities, and water treatment plants. This wide size range allows customers to select the most suitable valve size according to their specific flow requirements, ensuring optimal performance and efficiency.
5. High - Quality Manufacturing and Certifications
Chengxin Valve Co., Ltd. has a long - standing reputation for manufacturing high - quality valves. The company holds important production certifications such as ISO9001, ISO14000, and OHSAS18001. The ISO9001 certification indicates that the manufacturing process is well - controlled and meets international quality management standards. ISO14000 certification shows that the company is committed to environmental protection in its production processes. OHSAS18001 certification ensures that the working environment and safety measures in the production are up to international standards. These certifications give customers confidence in the quality, safety, and environmental friendliness of the valve.
6. Market Reach and Export
With an established overseas office, Chengxin Valve Co., Ltd. has a significant presence in the international market. The company's export share ranges from US$1 Million - US$1.5 Million, and its main markets include South America, Eastern Europe, Africa, and the Mid - East. This wide market reach demonstrates the valve's adaptability to different regional requirements and its acceptance in diverse industrial environments. Whether it is for the harsh conditions in African industries or the high - tech requirements in Eastern European plants, this valve has proven its reliability and performance.
7. Professional Service Team
The company has a team of 1 - 10 professional sales representatives. These experienced salespeople can provide customers with comprehensive pre - sales and after - sales services. They can offer technical advice on valve selection, installation, and maintenance. In case of any issues, they can quickly respond and provide solutions, ensuring that customers have a smooth experience from the moment they consider purchasing the valve to its long - term use.
In conclusion, our DIN standard compliant globe valve with a size range of DN50 to DN250 is a top - notch product that combines high - quality manufacturing, excellent sealing performance, wide versatility, and professional service. It is a reliable choice for various industrial applications around the world.
If you are interested in this product, please feel free to contact our manager, LI, via WhatsApp at +8618333988751 or by mobile phone at 86 - 13231988751. Our company is located at the industrial estate of Weizhuang Town, Longyao County, Hebei Province.
