Help CenterEmerson KJ3001X1-CA1 I/O Terminal Block – Reliable Field Wiring for DeltaV S-series I/O
Related Products
-
Emerson KJ3001X1-CB1 Discrete Output Module – Reliable 24 VDC Digital Outputs for DeltaV M-seriesUS$ 2216.00MOQ: 1 Blade -
Emerson KJ3002X1-BC1 (12P0681X092) – HART Analog Input Module for DeltaV M‑series Process ControlUS$ 2216.00MOQ: 1 Blade
-
Emerson KJ3003X1-EA1 Interface Terminal Block – Clean, Dependable Field Wiring to DeltaV I/OUS$ 2216.00MOQ: 1 Blade
-
Emerson KJ3222X1-BA1 Analog Input HART Module – Reliable HART-enabled 4–20 mA Input for DeltaV Process SignalsUS$ 2216.00MOQ: 1 Blade
-
Emerson KJ3242X1-BA1 Fieldbus H1 Series 2 Module – Reliable FOUNDATION Fieldbus Connectivity for DeltaV SystemsUS$ 2216.00MOQ: 1 Blade
Warranty: 365 days
Lead time: 1 week when in stock; no more than 1 month at the latest
Payment: 50% advance payment; balance before delivery
Express options: FedEx, UPS, DHL
Plug‑in design – Installs directly on the DeltaV S‑series I/O carrier, allowing quick swap without rewiring the carrier.
Secure screw‑clamp terminations – Tight, vibration‑resistant connections that hold up well in cabinet environments.
Supports analog and discrete signals – Typically used for 4–20 mA/0–10 V analog and 24 VDC digital I/O, depending on the installed I/O card.
Shield and 2/3‑wire layouts – Makes landing shielded instrumentation cables straightforward and tidy.
Service-friendly labeling – Clear channel identification reduces mistakes during commissioning and troubleshooting.
Cabinet-ready form factor – Purpose-built for standard control panels with proper spacing and access for test probes.
| Parameter | Details |
|---|---|
| Brand / Model | Emerson KJ3001X1-CA1 (I/O Terminal Block) |
| HS Code | 853690 (Electrical terminals/connectors for circuits) |
| Power Requirements | Not applicable (passive terminal block) |
| Dimensions & Weight | S‑series plug‑in form factor; compact, panel‑friendly; weight approx. 0.1 kg |
| Operating Temperature | 0 to 55 °C (typical control cabinet environment) |
| Signal Input/Output Types | Field wiring for analog (e.g., 4–20 mA, 0–10 V) and discrete 24 VDC signals; shield termination supported (module‑dependent) |
| Communication Interfaces | None (mechanical terminal only; signals pass through to the I/O card) |
| Installation Method | Plug‑in to DeltaV S‑series I/O carrier; screw‑clamp field connections; cabinet/DIN‑rail via carrier |
| Typical Wire Size | Up to 2.5 mm² (14 AWG) stranded or solid (follow Emerson guidance) |
You’ll see the KJ3001X1-CA1 in process automation cabinets across oil & gas, refining, chemicals, power generation, water/wastewater, food & beverage, and pharmaceuticals. One thing I appreciate is how it simplifies mixed-signal panels: a single block style that works cleanly with AI, AO, DI, and DO modules in the same rack, which seems to be a common real-world requirement.
Instrumented skids with 4–20 mA transmitters and 24 VDC solenoids
Power plant balance-of-plant panels with mixed analog feedback and digital status
Water treatment MCC interface panels where shield management matters
Reliability – Stable screw terminations and a rugged plug‑in interface reduce nuisance downtime from intermittent connections.
Compatibility – Purpose-built for DeltaV S‑series carriers; fits existing cabinets with no layout surprises.
Maintenance savings – Fast module or block swaps without disturbing field wiring cut Mean Time to Repair in many cases.
Lifecycle support – Emerson spares strategy and documentation make long-term management predictable.
A controls engineer at a petrochemical site told us they keep two spare KJ3001X1‑CA1 blocks on the shelf; when a channel needed inspection, they swapped the block in minutes and traced the issue without taking the whole carrier offline.
Installation & MaintenanceCabinet environment – Install on DeltaV S‑series carriers within a clean, ventilated enclosure (0–55 °C; non‑condensing humidity).
Wiring practices – Use ferrules on stranded conductors; segregate analog vs. discrete and route shields per site grounding policy.
Tightening torque – Secure terminals evenly and avoid over‑torque; follow Emerson’s torque guidelines for the terminal type.
Safety – De‑energize affected circuits before removing the terminal block to prevent arcing and device damage.
Routine checks – Periodically re‑verify terminal tightness, clean dust with a dry lint‑free cloth, and confirm channel labeling matches the I/O database.
Spares & updates – Keep at least one spare per cabinet row; firmware updates are not applicable to this passive component.
CE compliant for EMC/Low Voltage directives (typical for DeltaV I/O accessories)
UL/CSA recognition for control equipment components (model‑dependent)
RoHS compliant materials
Manufactured under ISO 9001 quality systems
Manufacturer’s warranty support; channel count and signal use depend on the paired I/O module
