Help CenterNI CFP-DO-403 Digital Output Module – Reliable DC Switching for Compact FieldPoint Systems
Related Products
-
National Instruments BNC-2110 Series: Your Go-To Shielded Signal Hub for Precision Test BenchesUS$ 3216.00MOQ: 1 Blade -
National Instruments CFP-CB-1: Your FieldPoint System’s Reliable Connector BackboneUS$ 3216.00MOQ: 1 Blade
-
NI CFP-DI-304: Your No-Nonsense Digital Input Workhorse for Industrial MonitoringUS$ 3216.00MOQ: 1 Blade
-
National Instruments CFP-DO-400: Solid-State Digital Output for Harsh Industrial SwitchingUS$ 3216.00MOQ: 1 Blade
-
National Instruments GPIB-140A: Your Modern Bridge to Legacy Test EquipmentUS$ 3216.00MOQ: 1 Blade
Warranty: 365 days
Delivery: 1 week for in‑stock items; no more than one month at the latest
Payment: 50% advance payment; full payment before delivery
Express options: FedEx, UPS, DHL
Compact FieldPoint integration – Plugs into a cFP terminal base and communicates over the cFP backplane via a cFP controller or network interface.
Transistor-based digital outputs – Suited for DC load switching; stable behavior for on/off control in industrial cabinets.
Isolation between field and backplane – Reduces noise coupling and helps protect the controller side in most cabinet environments.
Per‑channel status LEDs – Quick visual verification; you can see channel states at a glance during commissioning.
Hot‑swappable module design – Typically allows quick replacement with minimal system downtime.
Watchdog/fail‑safe options (via cFP controller) – Sets safe output states on communication loss; useful for remote sites.
LabVIEW/FieldPoint software support – Works with NI‑FieldPoint APIs and LabVIEW Real‑Time on cFP controllers for fast setup.
| Brand / Model | NI (National Instruments) cFP‑DO‑403 (also seen as CFP‑DO‑403) |
| HS Code | 8537.10 (Boards/panels for electric control or distribution) |
| Power Requirements | Powered via the Compact FieldPoint backplane; field loads use an external DC supply appropriate to the output rating. |
| Dimensions & Weight | Standard Compact FieldPoint plug‑in module form factor; fits cFP terminal bases. |
| Operating Temperature | Typically −40 to +70 °C (cFP family range; confirm for installed environment) |
| Signal Output Type | Digital outputs, transistor switching (DC); field‑powered loads |
| Communication Interfaces | Via cFP backplane to a cFP network interface (e.g., cFP‑18xx) or cFP controller (cFP‑20xx); configured with NI‑FieldPoint / LabVIEW RT |
| Installation Method | Plug‑in to cFP terminal base (e.g., cFP‑CB‑1 or cFP‑CB‑3); DIN‑rail mounting via base/carrier |
From my experience, the cFP‑DO‑403 shines in distributed control where you want rugged I/O near the machine:
OEM machinery: on/off control of pneumatic valves, motor contactors, stack lights
Water & wastewater: local pump/valve actuation with remote telemetry
Power/utilities: switching of relays and interlocks in sub‑panels
Process skids: safe states and watchdog behavior during controller handovers
Packaging and material handling: actuator triggering and lane diverter control
A maintenance lead at a packaging plant told us their team liked the simple channel LEDs—during a jam they could verify outputs without booting a laptop, which typically saves minutes per event.
Reliability – Rugged cFP construction for cabinet environments; isolation reduces nuisance faults.
Compatibility – Works with existing cFP controllers and NI‑FieldPoint projects; easy drop‑in for legacy expansions.
Cost efficiency – Distributed I/O often cuts wiring runs and cabinet real estate; fewer terminations back at the main PLC.
Supportability – Clear diagnostics and stable driver support in LabVIEW RT shorten troubleshooting time.
Cabinet & mounting – Install on a DIN‑rail with the appropriate cFP base; allow airflow and keep within rated ambient temperature.
Power & wiring – Use a clean DC field supply sized for the total load; segregate signal and power wiring; tighten terminal screws to spec.
Safety – De‑energize field power before servicing; verify safe states with the controller’s watchdog during maintenance.
Routine care – Periodically check terminal torque, clean dust with dry air, and validate output actions in I/O tests after firmware or driver updates.
Supporting components you may consider: cFP‑CB‑1 or cFP‑CB‑3 terminal bases (screw/spring), a cFP‑18xx network interface or cFP‑20xx controller, and a regulated 24 VDC supply sized for your loads.
Quality & CertificationsCE marked; UL/cUL recognized (module family)
RoHS compliance typically available depending on production lot; we can verify at order time
Manufacturer quality system: ISO 9001
Standard manufacturer warranty practices apply; our sales warranty is 365 days as stated above
If you share your channel count and load details (voltage/current, inductive or resistive), we can confirm the exact output rating, terminal base options, and ship a matched kit to simplify installation.
