Help CenterBently Nevada 330104-05-11-10-02-CN – 8 mm Proximity Probe for 3300 XL Transducer Systems
Related Products
-
BENTLY 330180-91-00 Proximitor Preamplifier – Eddy-current Proximity Sensor Conditioning for Reliable Shaft Vibration and PositionUS$ 216.00MOQ: 1 Blade -
Bently Nevada 330104-11-22-10-02-CN – 3300 XL 5 mm Proximity Probe for Vibration and Shaft Position MonitoringUS$ 216.00MOQ: 1 Blade
-
Bently Nevada 330876-03-50-00-00 50 mm Proximity Probe – Long‑reach Non-contact Sensing for Critical Rotating MachineryUS$ 216.00MOQ: 1 Blade
-
Bently Nevada 3500/05-01-02-00-00-01 System Monitor – Core Control for the 3500 Condition Monitoring RackUS$ 216.00MOQ: 1 Blade
-
Bently Nevada 3500/05-01-02-00-00-00 System Rack (Framework Module) – Backplane & Housing for 3500 Machinery ProtectionUS$ 216.00MOQ: 1 Blade
Warranty: 365 days
Delivery: 1 week for in-stock; no more than one month at the latest
Payment: 50% advance payment, full payment prior to delivery
Express options: FedEx, UPS, DHL
8 mm probe tip – A mainstream size for medium-to-large machinery, providing robust dynamic signal and dependable gap measurements.
5 m integral cable (code “05”) – Typically used to assemble 5 m systems or mixed-length systems depending on the extension cable chosen.
3300 XL system compatibility – Works with 3300 XL Proximitor sensors and Bently Nevada 3500/3300 monitors for direct shaft vibration and position inputs.
Stable sensitivity – Standard 8 mm system sensitivity is typically 200 mV/mil (≈ 7.87 mV/µm) when used with matching Proximitor and extension cable.
Industrial-grade temperature capability – Probe assembly is designed for harsh environments commonly found on hot-end turbomachinery.
Threaded mounting with locknuts – Simple, repeatable installation; you might notice fewer re-gapping cycles after shutdowns when the mount is done right.
Backwards-fit with installed bases – In many cases, this model drops into existing 3300 XL setups without changing monitors or software.
| Brand / Model | Bently Nevada 330104-05-11-10-02-CN (8 mm proximity probe) |
| HS Code | 903180 (Measuring/monitoring instruments, other) |
| Power Requirements | Supplied via matching 3300 XL Proximitor sensor (–24 Vdc nominal from the monitoring system) |
| Sensitivity (system) | Typically 200 mV/mil (≈ 7.87 mV/µm) with the correct Proximitor and extension cable |
| Linear Range (system) | Typically up to 80 mils (≈ 2.0 mm) for 8 mm systems on steel targets |
| Operating Temperature | Probe: typically –35°C to +177°C; Proximitor (for reference): typically –35°C to +65°C |
| Dimensions & Weight | 8 mm tip diameter; integral cable length 5 m (code “05”). Weight varies with cable routing; contact for exact figure. |
| Signal I/O Types | Eddy-current probe input to Proximitor; gap (DC) and dynamic vibration (AC) outputs from Proximitor to monitor |
| Communication Interfaces | Not applicable (analog transducer system) |
| Installation Method | Threaded probe mount with locknuts; Proximitor typically mounted on panel or DIN rail; gapping via feeler gauges/target |
| Thread / Tip | 8 mm tip; thread per model code. This variant commonly uses a standard threaded sleeve for machine brackets. |
| System Compatibility | 3300 XL Proximitor sensors (e.g., matching 8 mm units) and Bently Nevada 3500/3300 monitoring systems |
You’ll typically see the 330104 used on:
Steam and gas turbines – radial vibration, axial position, and differential expansion points
Compressors and expanders – rotor dynamics and machine protection
Large induction motors and generators – bearing vibration and shaft position trending
Gearboxes and fans – coupling monitoring and early fault detection
Reliability – The 3300 XL family is known for long service life; fewer nuisance alarms when the system is matched correctly.
Compatibility – Seamless fit with installed Bently Nevada racks, which usually cuts commissioning time.
Lifecycle cost – Stable calibration means less frequent rework; spare parts are straightforward to stock across units.
Technical support – Clear selection between probe, extension cable, and Proximitor reduces mix-ups. We can help cross-check your cable lengths and thread options before shipment.
One thing I appreciate is how predictable the gap and dynamic response are when the system uses the correct combination: 330104 probe + matching 3300 XL Proximitor + the right-length 330130 extension cable. A maintenance lead recently shared that swapping to matched 5 m systems eliminated a persistent drift issue on a hot compressor train.
Installation & MaintenanceMounting – Install the probe in a rigid, properly threaded bracket; locknuts should be snug but not over-torqued. Maintain orthogonal orientation to the shaft target.
Gapping – Set the probe-to-target gap per system guidelines (typically mid-range of linear region). Verify gap voltage at the monitor after thermal stabilization.
Cabling – Route cables away from high-voltage conductors and VFD outputs. Avoid tight bends; use protective conduit in high-traffic areas.
Cabinet & ventilation – Mount Proximitor sensors in a clean enclosure with adequate ventilation; follow IP rating and temperature limits.
Safety – Lock out machinery during installation; confirm no contact between probe tip and rotating surfaces.
Routine maintenance – Inspect probe tip cleanliness during outages, confirm gap voltage, and check connectors. Firmware updates are not applicable to the probe, but it’s good practice to keep your monitor firmware current.
CE conformity
RoHS compliance
UL/CSA recognition (varies by subcomponent and region)
Manufacturer’s standard quality system (ISO-based)
Warranty: 365 days
Bently Nevada 330130 – 3300 XL extension cable (length to match probe for total system length)
Bently Nevada 3300 XL Proximitor Sensor – matching 8 mm unit for the 330104 probe
Bently Nevada 3500 or 3300 series monitors – machine protection and condition monitoring
Note: The code string “-05-11-10-02-CN” defines specific options (such as cable length and mechanical details). If you’re replacing an installed probe, sharing your existing code helps ensure a perfect match.
