Help CenterABB EI812F (3BDH000021R1) – Ethernet Interface Module for Freelance AC 800F Control Systems
Related Products
-
ABB EST125-975 + DCC2382A – Motor Feedback and Control Interface for ABB Drive SystemsUS$ 2360.00MOQ: 1 Combo -
ABB G3ESa (HENF318736R1) – Original Spare Module for ABB Automation CabinetsUS$ 4360.00MOQ: 1 Combo
-
ABB GCC960C103 (3BHE033067R0103 / 3BHE033068P106) – Gate Control Card for ABB Medium-Voltage Drive Gate UnitsUS$ 2360.00MOQ: 1 Combo
-
ABB GCD207B101 (3BHE024642R0101) – Gate Control/Driver Board for ABB High-Power Drive SystemsUS$ 2360.00MOQ: 1 Combo
-
ABB GCC960C102 (3BHE033067E0102) With 3BHE033068P106 – Generator/Excitation Control Module for Reliable AVR SystemsUS$ 4360.00MOQ: 1 Combo
Warranty: 365 days
Delivery: In-stock items typically ship within 1 week; no more than 1 month at the latest
Payment: 50% advance payment; full balance prior to delivery
Express Options: FedEx, UPS, DHL
Purpose-built for ABB Freelance AC 800F: Designed to integrate cleanly with AC 800F controllers for stable TCP/IP networking in distributed control setups.
Industrial Ethernet connectivity: Provides 10/100Base‑TX over RJ45 for controller networking, engineering access, and SCADA/HMI communication.
Backplane-powered simplicity: Power is supplied via the system backplane, so wiring stays tidy and commissioning is quicker.
Status diagnostics: Front-panel LEDs make it easy to verify link, activity and module status during FAT or onsite troubleshooting.
Cabinet-friendly design: Compact module footprint that fits standard AC 800F baseplate installations and typical 600/800 mm control cabinets.
Lifecycle stability: In many cases, the EI812F is chosen for its predictable behavior with stable firmware and broad ABB ecosystem compatibility.
| Brand / Model | ABB EI812F (Part No. 3BDH000021R1) |
| HS Code | 8537.10 (Programmable controllers / control panels – indicative for PLC communication modules) |
| Power Requirements | 24 V DC nominal via system backplane (typical for AC 800F modules) |
| Operating Temperature | 0 to +55 °C (typical control cabinet environment) |
| Signal I/O Types | Industrial Ethernet 10/100Base‑TX over RJ45 |
| Communication Interfaces | TCP/IP for AC 800F system/engineering connectivity; protocol use (e.g., SCADA/HMI access) depends on Freelance configuration |
| Installation Method | Mounted on AC 800F baseplate in a grounded control cabinet; front-access RJ45 |
You might notice the EI812F used wherever an ABB Freelance AC 800F controller needs a dependable Ethernet gateway:
Process industries: chemicals, pharmaceuticals, food & beverage – controller-to-SCADA links and historian access
Power & utilities: balance-of-plant networking, turbine auxiliary systems, water treatment skids
Oil & gas: packaged skids and compressor stations needing secure engineering connectivity
Metals, pulp & paper: line control, machine sections, and integration into site networks
Reliability: Stable behavior with ABB Freelance makes factory acceptance and site commissioning more predictable.
Compatibility: Works within the AC 800F ecosystem, reducing integration risk and avoiding one-off gateways.
Cost control: Backplane power and straightforward wiring typically cut installation time and spare-parts overhead.
Supportability: Access to ABB documentation and global service channels; firmware alignment with common Freelance versions.
Customer feedback (real-world use): “After swapping in the EI812F, our engineering tool connected first time and HMI tags came online without rework. We’ve left it untouched since—just routine checks.”
Installation & MaintenanceCabinet & grounding: Install in a clean, dry control cabinet with proper PE bonding. Maintain ventilation and keep ambient below 55 °C.
Wiring: Use shielded CAT5e/CAT6 for RJ45 runs; separate from high-voltage or VFD cables. Observe minimum bend radius and label both ends.
Network design: Assign fixed IPs per site standards; segregate control and office traffic (VLANs) where applicable. Avoid unmanaged daisy chains.
Firmware alignment: Match module firmware with your Freelance/AC 800F version. From my experience, upgrading controller first then I/O/comm modules reduces downtime.
ESD & handling: Observe ESD precautions when inserting/removing from the baseplate. Power down according to site MOC procedures.
Routine maintenance: Quarterly check link/activity LEDs, inspect RJ45 connectors, clean dust with dry air, and review system event logs. Keep one spare module on hand for critical loops.
Certifications: CE and RoHS compliance are typical for this series; some batches may carry UL/cUL. Verify the exact markings on the nameplate for your unit.
Manufacturer warranty: Standard ABB manufacturer terms apply; our supply warranty is 365 days.
ABB AC 800F controller main module (PM-series for Freelance)
AC 800F baseplate and power module
S800 I/O modules for field signals (AI, AO, DI, DO) where required
Industrial Ethernet switches (managed), patch panels, cabinet accessories
