IS200TDBTH6AAA Discrete Board/accommodates 12 Passive Pulse Rate Devices
US$ 8742.00
≥1 Pallet
Key Specifications
Get Latest Price
I/O Number:
IS200TDBTH6AAA
Place of Origin:
America
Communication Interface:
Modubus
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
IS200TBCIH1CBC Contact the Contact Isolated From the Input Terminal Board/tape GroupUS$ 2571.00MOQ: 1 Pallet -
IS200TVBAH1AAA Dedicated Interface for Connecting Vibration SensorsUS$ 2571.00MOQ: 1 Pallet
-
IS200TRPAH2AFD Turbine Main Trip Terminal Board/ Input Circuit SensitivityUS$ 9425.00MOQ: 1 Pallet
-
IS200TTURH1CCC Turbine Terminal Plate/white 4-pin JackUS$ 5657.00MOQ: 1 Pallet
-
IS200SRTDH2ABB RTD Card / 18 Terminals per TerminalUS$ 5657.00MOQ: 1 Pallet
I/O Number
IS200TDBTH6AAA
Place of Origin
America
Communication Interface
Modubus
Product name
Discrete board/accommodates 12 passive pulse rate devices
Model Number
IS200TDBTH6AAA
Condition
NEW
Warranty
One Year
Package
Original Packaging
Product Description
nation | china |
Product Name | IS200TDBTH6AAA |
Material | Discrete board/accommodates 12 passive pulse rate devices |
warranty | One year |
Stock | In Stock |
Package | Original |
Welcome, thank you for your trust, The seller has more than $1526000 worth of industrial control products inventory.hope we can help you solve your problem!!!
Can transport to the world.
（Rule out special circumstances can't transport area！）
If you need, please contact customer service.
【The contact information of the service】
① 24 hours to receive mail reply (12 hours);
② EBAY customer service chat messages, reply within 3 hours.
③ Shipped to countries outside of Asia, please contact the seller.（Part of the international area, free shipping）
【Product properties】
① Type:IS200TDBTH6AAA
② Inventory quantity: 2
③ The colour：NEW
④ Freight: Different areas of freight, depending on the local freight forwarder shall prevail.
⑤ Whether containing tariffs: Do not include any taxes and fees
⑥ Packing: Use the seller safety packaging
【Friendship tip】
Ⅰ、The mode of transportation and freight:
① , Shipping company according to different regions. (If you need to specify the shipping company, please contact the seller)
② , freight, transport price (not including the national customs charges and other fees), according to the actual seller to provide shipping price shall prevail.
③ , the territory of China (including Hong Kong, Macao and Taiwan), in most of the free shipping. Please contact the staff.
Ⅱ、Payment method:
Buyer please select a payment according to the actual situation, if in doubt contact the seller!!!!!
Ⅲ、Product quality and after-sales service:
1, Consulting the seller's product quality, buy again. If you have any questions, please contact the seller.
2, During the after-sales service, according to the circumstances. If you want to delay the after-sales service, or else the seller after-sale policy shall prevail. Please contact the seller.
IS200TDBTH6AAA Discrete board/accommodates 12 passive pulse rate devices
IS200TDBTH6AAA-T Discrete Board TMR
trait
Speed sensing input: It can accommodate 12 passive pulse rate devices, four distributed in each R/S/T section. These devices are used to sense toothed wheels to accurately measure turbine speeds. Alternatively, in the TMR (Triple Modular Redundancy) section, six active pulse rate inputs are used, two for each section.
Trip coil output contacts: Two output contacts, selected by TMR ballot, are provided on the board and are specified for the main circuit breaker coil trip coil. These outputs operate at 24 V DC (H1) or 125 V DC (H2), helping the main circuit breaker coil to reliably and synchronously trip under specific conditions or trigger conditions.
Voltage detection circuit: Four voltage detection circuits are integrated into the circuit board to effectively monitor the trip string. These circuits operate in the voltage range of 24-125 V DC, continuously monitoring the trip string for any deviations or anomalies that may require intervention or corrective action.
Fail-safe ESTOP input: It has a dedicated fail-safe ESTOP (Emergency Stop) input and operates in a voltage range of 24-125 V DC. This input is essential to start the power supply of the trip relay in the event of an emergency or if the turbine needs to be shut down immediately for safety reasons.
Install
Connect to I/O terminals TB1 and TB2: Components such as TTL pulse frequency pickers, voltage detection circuits, scare-stop inputs, and circuit breaker relays are connected to I/O terminals TB1. The passive pulse frequency picker is specifically connected to the TB2. Each terminal is secured with two screws and has 24 terminals capable of accepting wires up to #12 AWG. To ensure proper grounding and minimize electrical interference, the shield end strips are connected to the chassis grounding, immediately to the left of each terminal.
Configuration of the speed input connection: The desired speed input connection must be configured according to the specific requirements. This configuration involves selecting the appropriate sector for the R segment pulse rate pickers of S and T PTUR. Jumpers JP1 and JP2 are used for this purpose. These jumpers help select the sector configuration, ensuring that the pulse rate pickers are correctly distributed between the R, S, and T sections of the PTUR according to the desired Settings.
Testing and verification: After wiring and configuration, a thorough testing and verification procedure should be performed to ensure the proper function and integration of the terminal board in the system. The test shall include verification of the correct operation of components such as speed sensing inputs, voltage detection circuits, scram functions, and circuit breaker relay operation.
