Help Center304 304L 316 316L Stainless Steel Food Grade Sanitary Tube Welding Water Supply Tube Pipe2b, Ba, Hl, No.1, No.4, Mirror, 8K Golden
Related Products
-
Customized Size 201 304 304L 316 316L Stainless Steel Pipe Tube Factory Outlet WholesaleNegotiableMOQ: 1 Ton -
Tp 304 304L 316 316L Sanitary Round Ss Seamless Stainless Steel Pipe TubeUS$ 2 - 50MOQ: 1 Kilogram
-
Stainless Steel Sanitary Tube ASTM 304 321 316 Polished Surface Ap/BaUS$ 2 - 50MOQ: 1 Kilogram
-
Seamless Stainless Steel Round Tube Factory Outlet WholesaleNegotiableMOQ: 1 Ton
-
Discounts China Manufacturer Sanitary 304 316 Stainless Steel Welded Ss Pipe Tube PriceUS$ 2 - 50MOQ: 1 Kilogram
Top quality stainless steel/Nickel alloy,Titanium alloy tube ,Centrifugal casting Tube, seamless or welded pipe produce and supply random length
Ruiyang company is an audited supplier by SGS,BV,honest supplier aim to long terms win win business
Detailed pipes we could supply:
| seamless pipe | Round pipe | Out diameter: | 1/8"-24"(6mm-630mm). |
| Wall thickness: | ANSI 5S-160S (0.9mm-100mm) | ||
| Square pipe | 20x20x-200x200:thickness2-50mm | ||
| rectangular pipe | 10x20-150x100,thickness:2-50mm | ||
| Hex pipe | Out hex or Round Inside bore or hex |
Flat to flat 16-70mm, thickness:3-10mm With drawing |
|
| Oval tube | With drawing | ||
| Welded type | Round pipe | Out diameter: | OD6-2500MM |
| Wall thickness: | Thickness:1-50mm | ||
| Square pipe | 10x10-200x200,thickness1-3mm | ||
| Rectangular pipe | 10x20-150x100,thickness:1-3mm | ||
| Oval tube | As drawings | ||
| Manufacture Standard: | ASTMA213/312/269/511/789/790, GOST9940/9941,DIN17456/17458/EN10206/17440 JIS3459/3463,GB13296/14976/9948/5310/8142/8143 |
||
| stainless steel | TP304,304L,304H,304N,316,316L,316Ti,317L,310S,321,321H,347H,S31803, S32750,347,330,825,904L, 12X18H9,08X18H10,03X18H11,08X18H10T,20X25H20C2,08X17H13M2T,08X18H12E 1.4301, 1.4306, 1.4401, 1.4404, 1.4435, 1.4541, 1.4571, 1.4563, 1.4462, 1.4845, SUS304, SUS304L, SUS316, SUS316L, SUS321, SUS310S etc. |
||
| Nickel alloy |
Hastelloy: UNS N10001, N10665, N10675, N06455, N06022, N10276, N06200, N06035, N06030, N06635, N10003, N06002, R30188, N06230, R30556 Inconel: UNS N06600, N06601, N06617, N06625, N07718, N07750, N08800, N08810, N08811, N08825, N09925, N08926 Monel: UNS N04400, N05500 Precipitation-hardening Steels: 254SMO/S31254, 17-4PH, 17-7PH, 15-7PH Nickel: N4/UNS N02201, N6/UNS N02200 |
||
| Titanium and titanium alloy | GR1,GR2,GR5,GR7,GR9,GR12 | ||
| Centrifugal casting tube | 57-1200mm OD | ||
| Cobalt alloy pipe | customed sizes | ||
| Process methods: | cold drawn, cold rolling,welded | ||
| Surface & Delivery condition: | Solution annealed and pickled, grey white (polished),with plain ends/bevel edges ends,Hairline | ||
| Length: | Max25 meters | ||
| Packing: | in seaworthy wooden cases or in bundles | ||
| Min order quantity: | 0.5 ton each size for common steel. | ||
| Delivery date: | soonest or discussible | ||
| Certificates: | ISO9001:2000 quality system and Mill test Certificate supplied | ||
Our Products Rang:
Steel pipe,Stainless Steel bars, Pipes & Tubes - Welded, Seamless Duplex Steel Pipe And Fittings
Fasteners
Wire rope and rope fittings
Nickel Alloy Steel Pipe And Fittings
Titanium Pipe and Titanium Bars,Flanges, Fitting
Centrifugal casting tube
Stainless Steels - 304, 304H, 304L, 316, 316H, 316L, 321, 321H, 347, 310, 410, 410S, 904L etc
Duplex Steel - UNS 31803 (Duplex), UNS 32750 / UNS 32760 (Super Duplex)/2205 etc
Nickel Alloy Steel- Alloy B/ N10001, Alloy B2/N10665, Alloy B3/N10675, Alloy C4/N06455, Alloy C22/N06022, Alloy C276/N10276, Alloy C2000/N06200, Alloy G35/N06035, Alloy G30/N06030, Alloy S/N06635, Alloy N/N10003, Alloy X/N06002, Alloy 188/R30188, Alloy 230/N06230, Alloy 556/R30556 Alloy 600/ N06600, Alloy 601/N06601, Alloy 617/N06617, Alloy 625/N06625, Alloy 718/N07718, Alloy X750/N07750, Alloy 800/N08800, Alloy 800H/N08810, Alloy 800HT/N08811, Alloy 825/N08825, Alloy 925/N09925, Alloy 926/N08926/Alloy 400/ N04400, Alloy K500/N05500
Precipitation-hardening Steels- 254SMO/S31254, 17-4PH, 17-7PH, 15-7PH
Nickel: N4/UNS N02201, N6/UNS N02200
Titanium :TA1 TA2 TC4, ASTM B337,ASTM B338,ASTM B861,ASTM B862
Cobalt alloy:umco50
Centrifugal casting pipes,reformer tube,radiant tube,heat resistant steel etc
General Require of ASTMA213/M
| standard Items |
ASTM A213/A213M | |||
|
Steel grade |
TP301 TP304L TP316 TP316L TP317 TP310L TP347 TP310S TP347H△ TP310H * TP309H* TP321H△ |
|||
| Rp0.2(Mpa) | ≥170 ; ≥205 | |||
| Rm(Mpa) | ≥485 ; ≥515 | |||
| A(%) | ≥35 | |||
| Flatten experiment(mm) | H=1.09t/(0.09+t/D) | |||
| flaring test | Inside diameter 21-68% | |||
| Grain size | "*"," △ "ASTM E112/ "△ "7#or above7#"*"6#or above6# | |||
|
hydrostatic test (Mpa) |
D | Pmax |
P=220.6t/D |
|
| 7 | ||||
| 25.4- | 10 | |||
| 38.1- | 14 | |||
| 50.8- | 17 | |||
| 76.2- | 24 | |||
| ≥127 | 31 | |||
| Crystal corrosion test |
ASTM A262 | |||
| nondestructive inspection | ASTM E213 E309 E426 | |||
| Heat treatment (solid solution) | required | |||
|
Out-diameter tolerance(mm) |
OD | TOLERANCE | ||
| ±0.10 | ||||
| 25.4-≤38.1 | ±0.15 | |||
| >38.1- | ±0.20 | |||
| 50.8- | ±0.25 | |||
| 63.5- | ±0.30 | |||
| 76.2-≤101.6 | ±0.38 | |||
| >101.6-≤190.5 | ±0.38/-0.64 | |||
| >190.5-≤228.6 | ±0.38/-1.14 | |||
|
Thickness tolerance(mm) |
OD | TOLERANCE | ||
| ≤38.1 | +20%-0 | |||
| >38.1 | +22%-0 | |||
| straightness(mm/m) | REASONABLE | |||
| HARDNESS | HRB | |||
Quality assure of stainless steel pipe tube:
1)Basic guarantee:Raw material guarantee,we use the Tsingshan Brand raw material,the quality is good,adding we use the spectrum direct-reading test,our professional
workers &equipments,we could guarantee the tubes is right of the clients' needs.
2)Process control:follow the process chart + our professional workers' care
3)Inspection& Test:
Direct-reading Spectrum Instrument analytic for chemical composition, Yield Strength, Tensile Strength, Elongation, Hardness Test, Flattening Test,Flaring Test, Eddy Current Test, Ultrasonic Test, Hydrostatic Test, Corrosion Test, etc
Features of stainless steel tubes:
1)characters such as Safety, health, environmental protection
2)economy applicable, good surface
3)the resistant to corrosion
4)less weight than bars, thickness and out diameter so variously
5)easy cutting, huge deformation
6)tensile strengthen and good be flexible etc.
Applications & Usage of seamless stainless,nickel,titanium pipe:
as Line pipe, boiler pipe, mechanical structure, hydraulic prop pipe, gas pipe, geological pipe, chemical pipe
(high pressure chemical fertilizer pipe, oil cracking pipe) and tube for ships, etcdecoration,building,construction,water pipe,petroleum, chemical industry, chemical fiber, smelt, medical machinery,paper making,Heat preservation and refrigeration, mechanical equipment, food, electricity, water conservancy,architecture, aerospace, navigation shipbuilding, environmental protection and boiler heat exchanger
Product Features
High Corrosion Resistance: Our stainless steel coils are resistant to rust and corrosion, making them suitable for harsh environments.
Excellent Mechanical Properties: High strength and durability ensure long-lasting performance in various applications.
Smooth Surface: The bright finish ensures a sleek appearance and is ideal for decorative and industrial uses.
Customizable Specifications: We offer customized thickness, width, and surface finishes to meet your specific needs.
Cost-Effective: Competitive pricing and high-quality materials ensure you get the best value for your investment.
Applications
Our stainless steel coils are widely used in the following industries:
Construction: Roofing, siding, and decorative panels.
Appliance Manufacturing: Kitchen appliances, washing machines, and dryers.
Automotive Industry: Exhaust systems, decorative trim, and structural components.
Food Industry: Processing equipment, storage containers, and kitchenware.
Medical Equipment: Surgical instruments and equipment components.
Marine Industry: Marine hardware and corrosion-resistant parts.
Quality Control
Packaging & Delivery
The company has strong strength and has a professional and technical teamwith excellent technology and rich experience.The company has also introduced advanced production equipment andprocessing technology, which can provide customers with steel products ofvarious specifications and processing requirements. At the same time, thecompany has also established a complete after-sales service system to providecustomers with first-class services.
