Product Name:
5T Gasoline Winch (Shaft Drive)
Keywords:
Gasoline Winch, Shaft Drive System, Heavy-Duty Pulling, Multi-Speed Gears, 50KN Traction, Portable Winch, Off-Road Recovery
Product Description:
1. Overview
The 5T Gasoline Winch (Shaft Drive) is a heavy-duty pulling device engineered for challenging environments where reliability and power are critical. Compatible with both gasoline and diesel engines, it delivers a rated pulling force of 50KN, making it ideal for construction, recovery operations, and off-road applications.
2. Core Features
Dual Fuel Compatibility: Operates with gasoline or diesel engines for flexibility in fuel-dependent environments.
Multi-Speed Gear System: Four forward gears and two reverse gears provide precise control over traction force and speed.
Shaft Drive Design: High-strength coupling and torque output ensure structural integrity and consistent performance under heavy loads.
Portable yet Robust: Compact dimensions (112×57×58 cm) and a weight of approximately 155 kg balance portability with durability.
3. Performance Specifications
Rated Pulling Force: 50KN
Gear Performance:
Gear 1: 50KN traction at 4.5 m/min
Gear 2: 26KN traction at 8.5 m/min
Gear 3: 20KN traction at 11 m/min
Gear 4: 10KN traction at 23 m/min
Reverse Gears: Two gears with speeds of 3.5 m/min and 9 m/min (traction force optimized for light-load operations).
4. Applications
Heavy-load recovery in off-road and industrial settings.
Cable laying and infrastructure construction projects.
Mining, forestry, and other remote operations where electrical power is unavailable.
5. Note
Lab-tested data provided. Actual performance may vary due to operational conditions, improper use, or environmental factors such as terrain and slippage.
