Qycg-R01 Economical ABS Plastic Tipping Bucket Rain Gauge Sensor
US$ 80
≥1 Unit
Key Specifications
Get Latest Price
Warranty:
1
Trademark:
qingyi
Origin:
china
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days
Related Products
-
Qycg-L Illuminance SensorUS$ 150MOQ: 1 Unit -
Tipping Bucket Rainfall Sensor Long Standby Timerainfall Recorder Low Power Rainfall RecorderUS$ 500 - 703MOQ: 1 Unit
-
Integrated Meteorological Station Ultrasonic Integrated Weather Station, c, Automatic Weather StationUS$ 2813MOQ: 1 Combo
-
Soil Temperature and Humidity Speed Measuring Instrument ,Soil Moisture AnalyzerUS$ 300 - 700MOQ: 1 Combo
-
QS-Fs Wind Speed SensorUS$ 60MOQ: 1 Unit
Warranty
1
Trademark
qingyi
Origin
china
Product Description
QYCG-R01 Economical Tipping Bucket Rainfall Sensor is a hydrology, meteorological instrument used to measure the nature of rainfall, and it converts the precipitation into a pulse signal output. Designed with insect-proof nets, free blocking nozzle and built-in leveller. The model can be used in meteorology, hydrology, agriculture, forestry, field monitoring stations and other industries .Combined with rainfall recorder can be used to measure measure precipitation, precipitation intensity, precipitation time.
FEATURES
* Compact size for easy use
* High accuracy, good stability
* Mesh in the funnel preventing debris such as leaves and insects from entering the working of rain sensor
* Well made tipping bucket with low resistance
* The main body made of high strength ABS
* Horizontal Bubble in the bottom
APPLICATIONS
* Meteorological monitoring
* Hydrologic monitoring
* Natural disaster monitoring
* Agrometeorological research
* Climate research
SPECIFICATIONS
WORKING PROCESS
Rainfall is captured in the 200mm diameter collector funnel and is directed through a delivery pipe to fill a divided ABS injection molded tipping bucket device.The bucket is pivoted through its center and has a preset calibration to tip for 0.2 mm of rainfall. When the bucket is "full", it pivots and empties - this action magnetically closes and opens a reed switch, sending a pulse signal to the data logger or electronic counter. Through this tipping "seesaw" action, the other side of the bucket is aligned to receive the flow from the delivery pipe. This recording and tipping cycle continues with rainfall.
DIMENSION & MOUNTING
Adjust the balance foot screws to ensure that it is in a horizontal position.Using three fastening screws to fix this three support legs at the platform to keep the entire apparatus at an optimum level , which ensure the accuracy of rainfall data.
FEATURES
* Compact size for easy use
* High accuracy, good stability
* Mesh in the funnel preventing debris such as leaves and insects from entering the working of rain sensor
* Well made tipping bucket with low resistance
* The main body made of high strength ABS
* Horizontal Bubble in the bottom
APPLICATIONS
* Meteorological monitoring
* Hydrologic monitoring
* Natural disaster monitoring
* Agrometeorological research
* Climate research
SPECIFICATIONS
| Item | Specification |
| Collector | diameter :φ200mm, height: 271mm |
| Measuring range | ≤ 4mm/min |
| Resolution | 0.2mm |
| Accuracy | ±2% |
| Maximum load voltage | 30VDC(pulse output) |
| Maximum load current | 20mA |
| Output | Pulses(@10kΩ&0.01uF),RS485(12-24VDC supply) |
| Operating temperature | -20-80ºC |
| Main material | ABS |
| Weight(unpacked) | 1kg |
WORKING PROCESS
Rainfall is captured in the 200mm diameter collector funnel and is directed through a delivery pipe to fill a divided ABS injection molded tipping bucket device.The bucket is pivoted through its center and has a preset calibration to tip for 0.2 mm of rainfall. When the bucket is "full", it pivots and empties - this action magnetically closes and opens a reed switch, sending a pulse signal to the data logger or electronic counter. Through this tipping "seesaw" action, the other side of the bucket is aligned to receive the flow from the delivery pipe. This recording and tipping cycle continues with rainfall.
DIMENSION & MOUNTING
Adjust the balance foot screws to ensure that it is in a horizontal position.Using three fastening screws to fix this three support legs at the platform to keep the entire apparatus at an optimum level , which ensure the accuracy of rainfall data.
