Nitronic 50 Stainless Steel Round Bar XM - 19 Bright Round Bar Dia.50

1. Product Overview

The Nitronic 50 Stainless Steel Round Bar, also known as XM - 19 Bright Round Bar with a diameter of 50mm, is a high - performance alloy product designed to meet the demanding needs of various industries. This round bar is crafted from Nitronic 50 stainless steel, a nitrogen - strengthened austenitic stainless steel that offers a unique combination of strength, corrosion resistance, and excellent mechanical properties.

2. Chemical Composition

The chemical composition of Nitronic 50 stainless steel is a key factor contributing to its outstanding performance. It contains approximately 21% chromium, which provides excellent resistance to oxidation and corrosion. The addition of 12% nickel enhances the material's toughness and ductility. Nitrogen, typically around 0.2 - 0.4%, is added to strengthen the steel, increasing its yield and tensile strength. Small amounts of manganese, silicon, and other elements are also present to optimize the alloy's properties. This well - balanced chemical composition makes the round bar suitable for use in harsh environments.

3. Mechanical Properties

Tensile Strength

The Nitronic 50 round bar has a high tensile strength, typically in the range of 860 - 1030 MPa. This high strength allows it to withstand significant loads without deformation, making it ideal for applications where structural integrity is crucial.

Yield Strength

With a yield strength of around 550 - 760 MPa, the round bar can resist plastic deformation under normal working conditions. This property ensures that the bar maintains its shape and performance over long - term use.

Elongation

It has an elongation of approximately 35 - 50%. This high elongation indicates good ductility, which means the bar can be easily formed, machined, or welded without cracking.

4. Corrosion Resistance

One of the most remarkable features of the Nitronic 50 Stainless Steel Round Bar is its excellent corrosion resistance. It is highly resistant to general corrosion, pitting, and crevice corrosion in a wide range of environments, including marine, chemical, and industrial settings. The high chromium content forms a passive oxide layer on the surface of the bar, protecting it from further corrosion. Additionally, the nitrogen in the alloy enhances the resistance to pitting and crevice corrosion, making it suitable for use in applications where exposure to corrosive substances is common.

5. Applications

Aviation Industry

In the aviation industry, the high strength - to - weight ratio and corrosion resistance of the Nitronic 50 round bar make it an ideal choice for aircraft components such as landing gear parts, fasteners, and structural elements. These components need to withstand high stresses and harsh environmental conditions during flight.

Electronics Industry

The round bar can be used in the electronics industry for manufacturing connectors, springs, and other precision components. Its good electrical conductivity and corrosion resistance ensure reliable performance in electronic devices.

Industrial Applications

In general industrial applications, the bar can be used for shafts, valves, and pump components. Its high strength and corrosion resistance make it suitable for use in machinery that operates in aggressive industrial environments.

Medical Industry

In the medical field, the Nitronic 50 round bar can be used for surgical instruments and medical implants. Its biocompatibility, combined with its corrosion resistance and strength, makes it a reliable material for medical applications.

Chemical Industry

In the chemical industry, the bar is used for equipment such as reactors, pipes, and storage tanks. Its resistance to a wide range of chemicals makes it suitable for handling corrosive substances.

6. Manufacturing and Quality Assurance

The Nitronic 50 Stainless Steel Round Bar is manufactured using advanced production techniques to ensure consistent quality. The production process includes melting, forging, rolling, and heat treatment. Each step is carefully controlled to meet strict quality standards. The bars are inspected using non - destructive testing methods such as ultrasonic testing and magnetic particle inspection to detect any internal defects. Additionally, chemical analysis and mechanical property testing are conducted to ensure that the bars meet the specified chemical composition and mechanical properties.

7. Packaging and Shipping

The round bars are carefully packaged to prevent damage during transportation. They are typically wrapped in protective materials and placed in sturdy wooden crates or steel containers. The packaging is designed to withstand the rigors of long - distance shipping and various environmental conditions. We offer worldwide shipping, ensuring that our products can reach customers in North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe, Central America, Northern Europe, Southern Europe, South Asia, and other regions in a timely and safe manner.
