Miniature Reducer
US$ 400
≥1 Unit
Key Specifications
Get Latest Price
Type:
Gear Reducer
Application:
Motor, Motorcycle, Machinery, Marine, Agricultural Machinery
Step:
Four-Step
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Type
Gear Reducer
Application
Motor, Motorcycle, Machinery, Marine, Agricultural Machinery
Step
Four-Step
GH series horizontal installation gear reduction motor
Strong bearing capacity, with a high-strength die-cast aluminum alloy case and gears with carbon hardness HRC62.
Low noise, exquisite design, precision manufacturing, noise below 65dB(A)
High efficiency, compared to traditional cone gears and worm gear reducers, it has a higher transmission efficiency at the same speed ratio.
No maintenance, the whole machine is compact, the reducer is lubricated with grease, maintenance-free for life
Wide application, a variety of models and installation methods are widely used in most industries
High torque, multiple speeds, wide power range
Single-phase voltage full load current value
| OUTPUT HORSEPOWER | 50HZ | 60HZ | |||||||||||
| 110V | 220V | RPM | 110V | 220V | RPM | ||||||||
| 100w | 2.4 | 1.2 | 1400 | 2.3 | 1.2 | 1690 | |||||||
| 200W | 3.6 | 1.8 | 1400 | 3.5 | 1.7 | 1690 | |||||||
| 400W | 8 | 4 | 1410 | 7.8 | 3.9 | 1700 | |||||||
| 750W | 14 | 7 | 1410 | 13.6 | 6.8 | 1700 | |||||||
| 1500W | 24 | 12 | 1420 | 23.3 | 11.6 | 1710 | |||||||
Single-phase motor capacitor specifications
| OUTPUT HORSEPOWER | Single Capacitor Type | Dual-capacitor type | |||||||||||
| Start cap | Operating capacitor | ||||||||||||
| 75W | 8μF | ||||||||||||
| 100w | 12μF-16μF | - | |||||||||||
| 200W | 14μF-20μF | ||||||||||||
| 400w | - | 200μF | 20μF | ||||||||||
| 750W | - | 300μF | 40μF | ||||||||||
| 1500w | - | 400μF | 40μF | ||||||||||
Three-phase voltage full load current value
| OUTPUT HORSEPOWER | 50HZ | 60HZ | ||||||||||||||||||||||
| 220V | 380V | 415V | 440V | RPM | 220V | 380V | 440V | 460V | RPM | |||||||||||||||
| 100W | 0.73 | 0.42 | 0.38 | 0.36 | 1320 | 0.71 | 0.41 | 0.35 | 0.34 | 1584 | ||||||||||||||
| 200W | 1.13 | 0.65 | 0.60 | 0.56 | 1348 | 1.10 | 0.63 | 0.54 | 0.52 | 1617.6 | ||||||||||||||
| 400W | 1.99 | 1.15 | 1.05 | 0.99 | 1355 | 1.93 | 1.12 | 0.96 | 0.92 | 1626 | ||||||||||||||
| 750W | 3.45 | 1.99 | 1.82 | 1.72 | 1385 | 3.35 | 1.93 | 1.67 | 1.59 | 1662 | ||||||||||||||
| 1500W | 6.3 | 3.64 | 3.33 | 3.14 | 1420 | 6.11 | 3.53 | 3.05 | 2.92 | 1704 | ||||||||||||||
| 2200W | 8.73 | 5.04 | 4.61 | 4.35 | 1425 | 8.47 | 4.89 | 4.22 | 4.04 | 1710 | ||||||||||||||
| 3700W | 13.91 | 8.03 | 7.35 | 6.94 | 1430 | 13.49 | 7.79 | 6.73 | 6.43 | 1716 | ||||||||||||||
| 5500W | 19.89 | 11.48 | 10.51 | 9.91 | 1440 | 19.29 | 11.14 | 9.62 | 9.20 | 1728 | ||||||||||||||
| 7500W | 26.52 | 15.31 | 14.02 | 13.22 | 1450 | 25.72 | 14.85 | 12.83 | 12.27 | 1740 | ||||||||||||||
