Sch5 to Sch160 Stainless Steel Pipe Fitting SS304 316 Butt-Welded/Welding 90 Degree Elbows
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Material:
Stainless Steel
Type:
Other
Certification:
ISO, CE
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGBO/SHANGHAI/TIANJIN/XIAMEN
Delivery Detail:
15 days
Related Products
-
Stainless Steel Butt Welded Pipe Fitting Sch60 Elbow 6 InchNegotiableMOQ: 1 Piece -
ASTM SA403 304h Stainless Steel Ss 45 Degree Butt-Welded ElbowsNegotiableMOQ: 1 Piece
-
Sch 40 1-1/4" Butt Weld Ss Long Radius 45 Degree ElbowNegotiableMOQ: 1 Piece
-
304 Stainless Steel Coil 1219mm Width BA Surface Cold RolledUS$ 1050MOQ: 1 Kilogram
-
304 Stainless Steel Sheet No.4 Brushed Finish 4x8 Feet 16 GaugeUS$ 1050MOQ: 1 Kilogram
Material
Stainless Steel
Type
Other
Certification
ISO, CE
Technics
Casting
Connection
Welding
Wall Thickness
Other
Finish
Other
Standard
Other, ASME、ANSI、DIN、JIS、GS、API
Application
Petroleum, Natural Gas, Water Dispose et
Transport Package
Wooden Cases, Pallets, Nylon Bags
Specification
customizable
Origin
China
Butt weld pipe fittings allow for changing the direction of flow, reducing pipe sizes and attaching auxiliary equipment.
A common example using welded pipe fitting is a pipe reduced by concentric reducer, welded to a weld neck flange and connected to an equipment.
* Welded connection offers a more robust connection
* Continuous metal structure adds to the strength of the piping system
* Buttweld fittings with matching pipe schedules, offers seamless flow inside the pipe. A full penetration weld and properly fitted LR 90 Elbow, Reducer, Concentric reducer etc. offers gradual transition via welded pipe fitting.
* Option of various turn radius using Short Radius (SR), Long Radius (LR) or 3R Elbows
* Cost effective compared to their expensive threaded or socket weld counter parts.
* Stainless Steel Welded Fittings are also available in SCH 10, allowing a more thinner wall option.
* Stainless Steel Butt Weld Fittings are more common in SCH 10 and SCH 40 configuration.
All butt weld fittings have beveled ends as per ASME B16.25 standard. This helps create full penetration weld without any extra preparation needed for the butt weld fitting.
Butt weld pipe fittings are most commonly available in carbon steel, stainless steel, nickel alloy, aluminum and high yield material. High yield butt weld carbon steel pipe fittings are available in A234-WPB, A234-WPC, A420-WPL6, Y-52, Y-60, Y-65, Y-70.All WPL6 pipe fittings are annealed and are NACE MR0157 and NACE MR0103 compatible.
1. Types:
Long Radius, Short Radius; 3D, 5D, 90°, 45°, 180°, 30°
2. Sizes:
1/2" ~ 24" (DN15~DN600), Seamless Elbow
26" ~ 72" (DN650 ~ DN1800), Welded Elbow
3. Wall Thickness:
ASME: SCH10, SCH20, SCH30, STD, SCH40, SCH60, SCH XS, SCH80, SCH100
SCH120, SCH140, SCH160, SCH XXS, SCH10S, SCH20S, SCH40S, SCH80S
JIS: SGP
DIN: acc. to DIN2605 schedule list
GOST: acc. to GOST 17375 schedule list
4. Material:
Carbon Steel: ASTM A234 WPB/WPC, WP1, WP12, WP11, WP22, WP5, WP9
Stainless Steel: SS 304/304L, SS 316/316L, SS317/317L, SS 310s, SS 321
Alloy Steel: ASTM A335 P12, P11, P3b, P22, P21, P5 to P9.
Non-Ferrous Alloy: Aluminum Alloys, Nickel Alloys, Copper Alloys
5. Standards:
ASME B 16.9, ASME B 16.25, EN10253, GOST 17375, DIN 2605-1, DIN 2605-2, JIS B 2311/2312/2313
Long Radius, Short Radius; 3D, 5D, 90°, 45°, 180°, 30°
2. Sizes:
1/2" ~ 24" (DN15~DN600), Seamless Elbow
26" ~ 72" (DN650 ~ DN1800), Welded Elbow
3. Wall Thickness:
ASME: SCH10, SCH20, SCH30, STD, SCH40, SCH60, SCH XS, SCH80, SCH100
SCH120, SCH140, SCH160, SCH XXS, SCH10S, SCH20S, SCH40S, SCH80S
JIS: SGP
DIN: acc. to DIN2605 schedule list
GOST: acc. to GOST 17375 schedule list
4. Material:
Carbon Steel: ASTM A234 WPB/WPC, WP1, WP12, WP11, WP22, WP5, WP9
Stainless Steel: SS 304/304L, SS 316/316L, SS317/317L, SS 310s, SS 321
Alloy Steel: ASTM A335 P12, P11, P3b, P22, P21, P5 to P9.
Non-Ferrous Alloy: Aluminum Alloys, Nickel Alloys, Copper Alloys
5. Standards:
ASME B 16.9, ASME B 16.25, EN10253, GOST 17375, DIN 2605-1, DIN 2605-2, JIS B 2311/2312/2313
Materials & Specifications
Material |
Grade |
Carbon Steel |
WPB, WPC, WPL6 |
Chrome Moly |
WP5, WP9, WP11, WP12, WP22 |
Stainless Steel |
304/304L, 316/316L, 304H, 316H, 309, 310S, 317L, 321/321H, 347/347H, 904L, DUPLEX 2205 / SUPER DUPLEX 2507 |
High Yield Carbon Steel |
WPHY42, WPHY52, WPHY65 |
Nickel Alloys |
Alloy 20, 200, 201, 400, 600, 625, 800H/HT, 825, 254SMO, AL6XN, C276, C22, B3, HAST-X |
* Standard Grades: Carbon, Stainless, Chrome Moly, High Yield, Low Temperature, Aluminum
* Types: Elbows, Tees, Reducers, Caps, Stub Ends, Crosses, Laterals, Olets, Return Bends
* Sizes: Standard 1/2" to 48" (special order larger O.D. fittings)
* Wall Sizes: Schedule 20 thru XXH, and Special Wall Sizes
* Specialty Items: 3D & 5D Bends, Galvanizing, 100% X-ray Testing
Forged Steel buttweld fittings are manufactured in accordance with ANSI / ASME B16.9.
Manufacturing Standards of Welded Fittings
* Types: Elbows, Tees, Reducers, Caps, Stub Ends, Crosses, Laterals, Olets, Return Bends
* Sizes: Standard 1/2" to 48" (special order larger O.D. fittings)
* Wall Sizes: Schedule 20 thru XXH, and Special Wall Sizes
* Specialty Items: 3D & 5D Bends, Galvanizing, 100% X-ray Testing
