Home > Products > Zklf3080-2RS-PE Superior Quality Machined Brass Cage Single Row Angular Contact Ball Bearing
Zklf3080-2RS-PE Superior Quality Machined Brass Cage Single Row Angular Contact Ball Bearing
≥10 Pieces
- shanghai
- T/T L/C PayPal D/P Western Union Other
- 30 days
You May Like
-
7307A5hu9 Low Temperature Submersible Pump Cryogenic Bearing
-
B7006-C-T-P4s Ultra High Speed Spuer Precision Ball Bearing for Spindle Machine Tool
-
7307A5hu9 Cryogenic High-Speed Low Temperature Bearing Used for Turbo Expanders and Rocket Turbopumps
-
HR33012P6 Super Precision Tapered Roller Bearings High Precision High Speed High Rigidity
-
CRBT505A Crossed Roller Bearing Servo Harmonic Drive Reduction Gearbox Reducer Cross Roller Bearing Actuator
Product Details
Material | PTEF | Rows Number | Single | |
Aligning | Non-Aligning Bearing | Separated | Unseparated | |
Contact Angle | 60° | Load Direction | Radial Bearing | |
Transport Package | Single Box | Specification | 30*80*28*46mm | |
Trademark | MONTON | Origin | Luoyang |
Product Description
High Speed Spuer Precision Ball Bearing for Spindle Machine Tool
Name | Axial Angular Contact Ball Bearings |
Seires | ZKLF series |
Brand | MONTON |
Model | ZKLF3080-2RS-PE |
D | 30 |
D | 80 |
D | 28 |
D1 | 46 |
Ring Material | Gcr15/Special materail |
Cage Material | Nylon cage |
r | 0.3 |
Load rating Cdyn | 29000N |
Load rating Costat | 64000N |
Limiting speed | 5000 |
Sealed | as customer requested |
Weight | 0.78KG |
Bearing Arrangement | PE/2AP |
Design Structure | Angular contact |
Precision | P4or as customer requested |
Vibration | ZV1, ZV2, ZV3, or as customer requested |
Clearance | C0, C2, C3, or as customer requested |
Quality standard | ISO9001: 2000/SGS |
Package | single box |
Original | Luoyang |
Service | OEM |
Delivery date | Accordingly |
Application | Spindle,machine ,ball screw,rotary tables and linear guidance units |
Designation | Dimensions | Pitch n×t | Basic load ratings axial | Limiting speed | Required locknut force axial N | Mass | ||||||
d -0,005 | D -0,01 | B -0,25 | d1 | r min. | r1 min. | dyn. Ca N | stat. C0a N | nG grease min-1 | m = kg | |||
ZKLF1255-2RS | 12 | 55 | 25 | 25 | 0,3 | 0,6 | 3×120° | 18,600 | 24,700 | 9,200 | 5,307 | 0.37 |
ZKLF1255-2Z | 12 | 55 | 25 | 25 | 0,3 | 0,6 | 3×120° | 18,600 | 24,700 | 12,000 | 5,307 | 0,37 |
ZKLF1560-2RS | 15 | 60 | 25 | 28 | 0.3 | 0.6 | 3×120° | 19,600 | 28,000 | 8,200 | 5,484 | 0,43 |
ZKLF1560-2Z | 15 | 60 | 25 | 28 | 0.3 | 0.6 | 3×120° | 19,600 | 28,000 | 10,800 | 5,484 | 0.43 |
ZKLF1762-2RS | 17 | 62 | 25 | 30 | 0.3 | 0.6 | 6×60° | 20,700 | 31,000 | 7,600 | 7,514 | 0.45 |
ZKLF1762-2Z | 17 | 62 | 25 | 30 | 0.3 | 0.6 | 6×60° | 20,700 | 31,000 | 10,100 | 7,514 | 0.45 |
ZKLF2068-2RS | 20 | 68 | 28 | 34.5 | 0.3 | 0.6 | 8×45° | 28,500 | 47,000 | 6,600 | 8,258 | 0.61 |
ZKLF2068-2Z | 20 | 68 | 28 | 34.5 | 0.3 | 0.6 | 8×45° | 28,500 | 47,000 | 8,700 | 8,258 | 0.61 |
ZKLF2575-2RS | 25 | 75 | 28 | 40.5 | 0.3 | 0.6 | 8×45° | 30500 | 55000 | 5700 | 9123 | 0.72 |
ZKLF2575-2Z | 25 | 75 | 28 | 40.5 | 0.3 | 0.6 | 8×45° | 30500 | 55000 | 7500 | 9123 | 0.72 |
ZKLF3080-2RS | 30 | 80 | 28 | 45.5 | 0.3 | 0.6 | 12×30° | 32000 | 64000 | 5000 | 9947 | 0.78 |
ZKLF3080-2Z | 30 | 80 | 28 | 45.5 | 0.3 | 0.6 | 12×30° | 32000 | 64000 | 6700 | 9947 | 0.78 |
ZKLF30100-2RS | 30 | 100 | 38 | 51 | 0.3 | 0.6 | 8×45° | 65000 | 108000 | 4500 | 19509 | 1.63 |
ZKLF30100-2Z | 30 | 100 | 38 | 51 | 0.3 | 0.6 | 8×45° | 65000 | 108000 | 5600 | 19509 | 1.63 |
ZKLF3590-2RS | 35 | 90 | 34 | 52 | 0.3 | 0.6 | 8×45° | 45000 | 89000 | 4400 | 10770 | 1.13 |
ZKLF3590-2Z | 35 | 90 | 34 | 52 | 0.3 | 0.6 | 8×45° | 45000 | 89000 | 5800 | 10770 | 1.13 |
ZKLF40100-2RS | 40 | 100 | 34 | 58 | 0.3 | 0.6 | 8×45° | 47500 | 101000 | 4000 | 13412 | 1.46 |
ZKLF40100-2Z | 40 | 100 | 34 | 58 | 0.3 | 0.6 | 8×45° | 47500 | 101000 | 5200 | 13412 | 1.46 |
ZKLF40115-2RS | 40 | 115 | 46 | 65 | 0.6 | 0.6 | 12×30° | 79000 | 149000 | 3500 | 25185 | 2.2 |
ZKLF40115-2Z | 40 | 115 | 46 | 65 | 0.6 | 0.6 | 12×30° | 79000 | 149000 | 4400 | 25815 | 2.2 |
ZKLF50115-2RS | 50 | 115 | 34 | 72 | 0.3 | 0.6 | 12×30° | 51000 | 126000 | 3200 | 16280 | 1.86 |
ZKLF50115-2Z | 50 | 115 | 34 | 72 | 0.3 | 0.6 | 12×30° | 51000 | 126000 | 4200 | 16280 | 1.86 |
ZKLF50140-2RS | 50 | 140 | 54 | 80 | 0.6 | 0.6 | 12×30° | 125000 | 250000 | 2900 | 28451 | 4.7 |
ZKLF50140-2Z | 50 | 140 | 54 | 80 | 0.6 | 0.6 | 12×30° | 125000 | 250000 | 3500 | 28451 | 4.7 |
ZKLF60145-2Z | 60 | 145 | 45 | 85 | 0.6 | 0.6 | 8×45° | 93000 | 214000 | 4000 | 16700 | 4.3 |
ZKLF70155-2Z | 70 | 155 | 45 | 95 | 0.6 | 0.6 | 8×45° | 97000 | 241000 | 3800 | 19031 | 4.9 |
ZKLF80165-2Z | 80 | 165 | 45 | 105 | 0.6 | 0.6 | 8×45° | 100000 | 265000 | 3600 | 20604 | 5.3 |
ZKLF90190-2Z | 90 | 190 | 55 | 120 | 0.6 | 0.6 | 8×45° | 149000 | 395000 | 3500 | 22731 | 8.7 |
ZKLF100200-2Z | 100 | 200 | 55 | 132 | 0.6 | 0.6 | 8×45° | 154000 | 435000 | 3300 | 25624 | 9.3 |
ZKLF100230-2Z | 100 | 230 | 85 | 146 | 0.6 | 0.6 | 12×30° | 295000 | 790000 | 2900 | 52000 | 17.6 |
ZKLF1255-2RS-PE | 12 | 55 | 25 | 25 | 0.3 | 0.6 | 3×120° | 16900 | 24700 | 9200 | 5307 | 0.37 |
ZKLF1560-2RS-PE | 15 | 60 | 25 | 28 | 0.3 | 0.6 | 3×120° | 17900 | 28000 | 8200 | 5484 | 0.43 |
ZKLF1762-2RS-PE | 17 | 62 | 25 | 30 | 0.3 | 0.6 | 6×60° | 18800 | 31000 | 7600 | 7514 | 0.45 |
ZKLF2068-2RS-PE | 20 | 68 | 28 | 34.5 | 0.3 | 0.6 | 8×45° | 26000 | 47000 | 6600 | 8258 | 0.61 |
ZKLF2575-2RS-PE | 25 | 75 | 28 | 40.5 | 0.3 | 0.6 | 8×45° | 27500 | 55000 | 5700 | 9123 | 0.72 |
ZKLF3080-2RS-PE | 30 | 80 | 28 | 45.5 | 0.3 | 0.6 | 12×30° | 29000 | 64000 | 5000 | 9947 | 0.78 |
ZKLF3590-2RS-PE | 35 | 90 | 34 | 52 | 0.3 | 0.6 | 8×45° | 41000 | 89000 | 4400 | 10770 | 1.13 |
ZKLF40100-2RS-PE | 40 | 100 | 34 | 58 | 0.3 | 0.6 | 8×45° | 43000 | 101000 | 4000 | 13412 | 1.46 |
ZKLF50115-2RS-PE | 50 | 115 | 34 | 72 | 0.3 | 0.6 | 12×30° | 46500 | 126000 | 3200 | 16280 | 1.86 |
ZKLF1762-2RS-2AP | 17 | 62 | 50 | 30 | 0.3 | 0.6 | 6×60° | 33500 | 62000 | 7600 | 7514 | 0.9 |
ZKLF2068-2RS-2AP | 20 | 68 | 56 | 34.5 | 0.3 | 0.6 | 8×45° | 46000 | 94000 | 6600 | 8258 | 1.22 |
ZKLF2575-2RS-2AP | 25 | 75 | 56 | 40.5 | 0.3 | 0.6 | 8×45° | 49000 | 111000 | 5700 | 9123 | 1.44 |
ZKLF3080-2RS-2AP | 30 | 80 | 56 | 45.5 | 0.3 | 0.6 | 12×30° | 52000 | 127000 | 5000 | 9947 | 1.56 |
ZKLF3590-2RS-2AP | 35 | 90 | 68 | 52 | 0.3 | 0.6 | 8×45° | 73000 | 177000 | 4400 | 10770 | 2.26 |
ZKLF40100-2RS-2AP | 40 | 100 | 68 | 58 | 0.3 | 0.6 | 8×45° | 77000 | 202000 | 4000 | 13412 | 2.92 |
ZKLF50115-2RS-2AP | 50 | 115 | 68 | 72 | 0.3 | 0.6 | 12×30° | 83000 | 250000 | 3200 | 16280 | 3.72 |
Monton bearing was established in 2001 seated in Luoyang--"Ancient Imperial Capital and Peony Flower City",we focusing on the bearing field for more than 20 years and we specializing in the development of "High-tech, High precision, Advanced, Non-standard" bearings.Monton's mission has been and will continue to be to provide customers with complete integrated solutions, including design and development, manufacturing, testing and evaluation, and second-to-none after-sales service. Monton bearing is mainly engaged in the production of the angular contact ball bearing,High precision crossed roller bearing,Thrust bearing stacks and TC radial bearings,Low temperature,The section ball bearing,Cylindrical roller bearing,Spherical roller bearing,Thrust roller ball bearings and harmonic drives bearing and the customized non-standard bearings. We made outstanding contributions to the important scientific research projects of many well-known universities such as Zhejiang University, Harbin University of technology, Beijing University of science and technology, Beijing Jiaotong University and China University of petroleum and won high praise from users. We have batch production on high-grade bearing products and components with an inner diameter of 0.6mm to an outer diameter of 5m. Our products have been widely used in Machine tools,Weapons,Oil drilling,Cryogenic pumps, Mining, Metallurgy,Port machinery, Medical treatment,Extruder gearboxes,Cement,Textiles,Industrial robots, Harmonic drives, Paper machinery, Concrete mixers, Rolling mill and national defense industry field. With advanced production equipment and perfect testing technology, MONTON can guarantee the quality and accuracy of the products we produced. Our technical department can efficiently complete the bearing design according to customer needs, and customers who need non-standard bearings can also enjoy customized services. Our quality system regularly monitors various production facilities and complies with strict quality requirements. All material certificates and certification reports are kept in files. Products are traceable and can be provided on request. Therefore, we are confident to provide the best solutions for global customers. We are innovative, motivated and courageous to provide our customers with necessary solutions. Our management and employees are always ready to provide professional and personalized services to our customers. In the future, MONTON will adhere to the brand development strategy, strengthen the research and development of high-end products, strive to build a digital factory, and join hands with more partners to work together for a better future! Company spirit: Honesty, Trustworthiness and Mutual benefit; Company policy: Quality-oriented; Company Business philosophy:Honesty; Company principle: Solve customers problems and maximize customer benefits! |
FAQ
1.Q:Are you a factory or trading company?
A:MONTON Bearing is specialized in manufacturing and exporting bearings.
MONTON Bearing have our own factory and warehouse.
2.Q:Can I get some samples and do you offer the sample free?
A:Yes, sure, we are honored to offer you samples.
3.Q:What is the payment?
A: 30% T/T In Advance, 70% T/T Against Copy Of B/L
B: 100% L/C At Sight
4.Q:What is the MOQ for bearing?
A: MOQ is 1 pc.
5.Q:What kind of service you can offer?
A:Technology support;Installation guidance;OEM ect.
6.Q: How long is your delivery time?
A: Generally it is 4-5 days if the goods are in stock. or it is 45 days if the goods are not in
stock, Also it is according to quantity.
7.Q: Can you provide special customization according to the working conditions?
A: Sure, we can design and produce the slewing bearings for different working conditions.
