Help CenterZKLDF100 Axial Angular Contact Ball Bearings
Related Products
-
Zkldf Series Turntable Bearings Factory ZKLDF120 Thrust Angular Contact Ball BearingsUS$ 1 - 100000MOQ: 1 Piece -
Zkldf Series Turntable Bearings in Stock ZKLDF120 ZKLDF150US$ 1 - 100000MOQ: 1 Piece
-
Zkldf Series Turntable Bearings Manufacturers China ZKLDF200 ZKLDF50US$ 1 - 100000MOQ: 1 Piece
-
ZKLDF260 Zkldf Series Turntable Bearings Price Thrust Angular Contact Ball BearingUS$ 1 - 100000MOQ: 1 Piece
-
ZKLDF325 Cheap Zkldf Series Turntable Bearings China Ball BearingUS$ 1 - 100000MOQ: 1 Piece
Features:
ZKLDF series(four point ball contact),with low frictional ,high rotate accurancy and high limit speed etc. features, can bear higher axial,radial load and with higher tilting rigity.,Main application is the area which need combined load and high precision. E.g machine tool rotary table ,grinding head and other measuring equipment.
Series model No.
ZKLDF100, ZKLDF120, ZKLDF150, ZKLDF200, ZKLDF260, ZKLDF325, ZKLDF395, ZKLDF460, ZKLDF580
Structure:
ZKLDF series parameters
| Series | Model Number |
Main dimensions (mm) | Basic load rating (Axial) |
Limiting speed (Grease) |
Bearing frictional torque |
Weight |
Model Number |
||||||||
| d | D | H | H1 | C | D1 | J | J1 | Ca KN | Coa KN | r/m | (Nm) | (Kg) | --------- | ||
| ZKLDF | ZKLDF100 | 100 | 185 | 38 | 25 | 160 | 136 | 112 | 170 | 71 | 265 | 2800 | 1.6 | 4.5 | ZKLDF100 |
| ZKLDF120 | 120 | 210 | 40 | 26 | 184 | 159 | 135 | 195 | 76 | 315 | 2400 | 2 | 6 | ZKLDF120 | |
| ZKLDF150 | 150 | 240 | 40 | 26 | 214 | 188 | 165 | 225 | 81 | 380 | 2000 | 3 | 7.5 | ZKLDF150 | |
| ZKLDF200 | 200 | 300 | 45 | 30 | 274 | 243 | 215 | 285 | 112 | 610 | 1600 | 4.5 | 11 | ZKLDF200 | |
| ZKLDF260 | 260 | 385 | 55 | 36.5 | 345 | 313 | 280 | 365 | 162 | 920 | 1200 | 7.5 | 22 | ZKLDF260 | |
| ZKLDF325 | 325 | 450 | 60 | 40 | 415 | 380 | 342 | 430 | 172 | 1110 | 1000 | 11 | 28 | ZKLDF325 | |
| ZKLDF395 | 395 | 525 | 65 | 42.5 | 486 | 450 | 415 | 505 | 241 | 1580 | 800 | 16 | 39 | ZKLDF395 | |
| ZKLDF460 | 460 | 600 | 70 | 46 | 560 | 520 | 482 | 580 | 255 | 1860 | 700 | 21 | 5 | ||
Applications :
•Industrial Robotic arm,Reducer drive
•precision Turntable,NC rotary table
•Rotation part of Machine tools
•Inspection instrument,Medical equipment
• Aviation equipment,Military radar etc
More products production line
1.YRT rotary table bearings
2.Crossed Roller Bearings
3.Crossed Tapered Roller Bearings
4.Thrust cylindrical Roller bearings
5.Deep Groove Ball Bearings
6.Angular contact ball bearings
7.Ceramic bearings
8.Harmonic Drive special bearings
9.Custom made bearings OEM,ODM available
Pls send us inquiry if need,or call us directly, your questions will be replyed within 24 hours
