IS230PCAAH1A GE Core Processor Module

IS230PCAAH1A GE Core Processor Module thumbnail-1
IS230PCAAH1A GE Core Processor Module thumbnail-2
IS230PCAAH1A GE Core Processor Module thumbnail-3
IS230PCAAH1A GE Core Processor Module photo-1
IS230PCAAH1A GE Core Processor Module photo-2
IS230PCAAH1A GE Core Processor Module photo-3
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Material:
Other, Global universal model
Condition:
Other, Global universal model
Task:
Other, Global universal model
Contact Supplier Request Quote Chat Now
Guizhou Yuanmiao Automation Equipment Co., Ltd.
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Material Other, Global universal model
Condition Other, Global universal model
Task Other, Global universal model
Mathematical Model Other, Global universal model
Signal Other, Global universal model
Customized Non-Customized
Structure Other, Global universal model
Operating temperature -40℃~+85℃
Humidity 5%~95% (non-condensing)




Many products are not on the shelves yet, please contact us for more models.




IS230PCAAH1A is a high-performance Primary Control Processor (PCA) module designed by General Electric (GE) for its Mark VIe control system. As a core component of the Mark VIe series, it is responsible for system data processing, control algorithm execution, and inter-device communication. It is widely used in the automated control of large industrial equipment such as gas turbines, steam turbines, and compressors. Here are its detailed specifications:
Basic Parameters
  • Brand and Series

    • Manufacturer: General Electric (GE)

    • Product Series: Mark VIe

    • Model: IS230PCAAH1A

  • Physical Specifications

    • Dimensions: Standard 19-inch rack module size, compatible with GE control system enclosures.

    • Weight: Approximately 1.5kg.

    • Operating Temperature: -40°C to +70°C (industrial-grade standard, suitable for harsh environments).

  • Power Requirements

    • Input Voltage: 24VDC (with redundant power supply support to ensure reliability).

    • Power Consumption: ≤25W.

IS230SNIDH1A (2)


Functional Features
  1. High-Performance Processing Capability

  • Adopts a multi-core processor architecture with a main frequency of up to 1.2GHz, enabling simultaneous processing of massive control logic, algorithm calculations, and data communication tasks.

  • Supports a real-time operating system (RTOS), ensuring a control command response time of ≤1ms, which meets the control requirements of high-speed equipment such as turbines.

  • Rich Communication Interfaces

    • Ethernet: 4 independent 10/100/1000Mbps Ethernet ports, supporting protocols like Ethernet/IP and Modbus TCP, enabling seamless connection with upper-level computers, PLCs, and SCADA systems.

    • Serial Interfaces: 2 RS-232/485 ports for communication with legacy devices or local configuration.

    • Dedicated Communication: Built-in high-speed backplane bus for real-time data exchange with I/O modules (e.g., IS220 series).

  • Redundancy and Fault-Tolerance Design

    • Supports dual-machine hot standby (redundant configuration), with an automatic switchover time of

    • Equipped with built-in watchdog timers, memory protection, and error detection mechanisms to promptly identify and handle hardware faults.

  • Flexible Programming and Configuration

    • Supports IEC 61131-3 standard programming languages (Ladder Diagram LD, Function Block Diagram FBD, Structured Text ST, etc.).

    • Configurable via GE’s Proficy* Machine Edition software, allowing remote program downloading, parameter monitoring, and fault diagnosis.

  • Safety Certifications

    • Complies with international standards such as UL, CSA, and CE, and is suitable for hazardous areas (Class I, Div 2 certification).

    • Supports password protection and access control to prevent unauthorized modification of system configurations.

      IS230SRTDH2A (1)




    Related products:

    IC697CPX928

    F650BFGF1G1HIE

    IS220UCSAH1A

    IS420UCSBH4A

    IS430SNUAH1A

    SR489-P5-HI-A20

    04220GL21204A

    151X1235DB15SA01EX2100





    Product Tags: IS230PCAAH1A , Core processor module
