IC698CHS009 9-slot I/O Rack

Guizhou Yuanmiao Automation Equipment Co., Ltd.

1Yr

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Material:

Other, Global universal model

Condition:

Other, Global universal model

Task:

Other, Global universal model

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Material Other, Global universal model

Condition Other, Global universal model

Task Other, Global universal model

Mathematical Model Other, Global universal model

Signal Other, Global universal model

Customized Non-Customized

Structure Other, Global universal model

Operating temperature -40℃~+85℃

Humidity 5%~95% (non-condensing)

Many products are not on the shelves yet, please contact us for more models.

IC698CHS009 is a 9-slot I/O rack belonging to the GE Fanuc RX7i series. Here are its detailed specifications:

Compatibility: Compatible with all Rx7i CPUs and I/O devices, 90-70 series I/O, and VME modules.
Slot Characteristics:

Slot Size: Slots 1-8 are 20mm wide, designed for single-width modules; Slot 9 is 40.6mm wide, intended for double-width modules.
Slot Sensing Function: Equipped with slot sensing functionality, supporting software configuration, eliminating the need for DIP switches or jumpers for I/O addressing.

Communication Capability: Built-in Ethernet communication, supporting SRTP and Modbus TCP/IP application protocols, providing real-time links for connected systems.
Other Features:

Can automatically daisy-chain interrupt acknowledgment and bus grant signals.
Equipped with a J2 connector, capable of speeds up to 64 bits per cycle.
Compatible with Rx7i power supplies. Cooling fans are required for the installation of some modules, such as IC698CPE020, IC698CRE020, and IC698PSA350. Optional cooling fan assemblies include IC697ACC621 (for 120VAC), IC697ACC624 (for 240VAC), or IC697ACC644 (for 24VDC).

Function and Application: As an I/O rack, it can receive, process, and forward various input and output signals, thereby realizing monitoring and control of equipment and systems. It is widely used in fields such as industrial automation, intelligent buildings, power industry, transportation, and medical industry.
