Hydraulic Outrigger Cylinder For Boom Crane Leg Cylinder
US$ 300
≥1 Piece
Key Specifications
Get Latest Price
Material:
Cast Iron
Certification:
GS, ROHS, CE, ISO9001
Structure:
Piston Type
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
30 days
Related Products
-
The Hydraulic Cylinder of the Truck Crane Tilts and Shifts Laterally, Rotates Left and Right, and Dislocates the Oil Seal.US$ 300MOQ: 1 Piece -
Hydraulic Cylinder for Bidirectional Lifting, Small-sized 40mm, Custom-made, Single-directional Oil Cylinder With 2-ton Pressure, Ear Ring Type,US$ 300MOQ: 1 Piece
-
Lift Hydraulic Cylinder for Steel Coil Flatbed TruckUS$ 300MOQ: 1 Piece
-
Customized Power Steering Cylinder ShaftUS$ 300MOQ: 1 Piece
-
Stomized Rear Hydraulic Jack Legs Hydraulic Cylinder With Adjustable Latch SystemUS$ 300MOQ: 1 Piece
Material
Cast Iron
Certification
GS, ROHS, CE, ISO9001
Structure
Piston Type
Work Temperature
Normal Temperature
Adjusted Form
Regulated Type
Acting Way
Double Acting
Working Method
Straight Trip
Pressure
Medium Pressure
Transport Package
Wooden box
Specification
280/200-300
Trademark
hongda
Origin
china
| Product title | Lateral Hydraulic Cylinder |
| Product Description | A lateral hydraulic cylinder serves a pivotal role in various mechanical systems by providing controlled side-to-side movement. This specialized hydraulic component converts hydraulic fluid pressure into linear force, enabling precise and efficient lateral motion within a mechanical setup. |
| Product Name | Hydraulic Cylinder |
| Brand | HongDa Hydraulics |
| Model Number | W140-63/35-450 |
| Weight | 20Kg |
| Dimension | 700X115X115 |
| Core Component | piston rod, cylinder barrel, end cap |
| Applicable Industries | General Equipment Hydraulic Cylinder |
| Bore Dia | 63 mm/5 in |
| Rod Dia | 35 mm/3.543 in |
| Stroke | 450 mm/39 in |
| Operating Temperature | -20°~50° |
| Maximum Working Pressure | 14Mpa |
| Mounting Style | earrings |
| Paint | customization acceptable |
| Working Medium | hydraulic oil |
| Certification |
Commonly used in industrial applications such as manufacturing machinery, material handling systems, and agricultural equipment, the lateral hydraulic cylinder allows for accurate positioning, pushing, or pulling actions. Its design, incorporating a durable cylinder, piston, and rod, ensures robust performance, while integration into hydraulic systems facilitates the controlled application of pressure, allowing for versatile and precise lateral movements. Regular maintenance is essential to uphold the cylinder's reliability, making it a fundamental component in systems that require controlled horizontal motion.
