Home > Tools & Hardware > Hydraulic Parts > Hydraulic Cylinder > Hydraulic Cylinder for Bidirectional Lifting, Small-sized 40mm, Custom-made, Single-directional Oil Cylinder With 2-ton Pressure, Ear Ring Type,

Hydraulic Cylinder for Bidirectional Lifting, Small-sized 40mm, Custom-made, Single-directional Oil Cylinder With 2-ton Pressure, Ear Ring Type,

Hydraulic Cylinder for Bidirectional Lifting, Small-sized 40mm, Custom-made, Single-directional Oil Cylinder With 2-ton Pressure, Ear Ring Type, photo-1

US$ 300 ≥1 Piece

Key Specifications

Get Latest Price

Material:

Cast Iron

Certification:

GS, ROHS, CE, ISO9001, Other

Structure:

Piston Type

Contact Supplier Request Quote Chat Now

Wuhan Hongda Hydraulic And Pneumatic Equipment Manufacturing Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Material Cast Iron

Certification GS, ROHS, CE, ISO9001, Other

Structure Piston Type

Work Temperature Normal Temperature

Adjusted Form Regulated Type

Acting Way Double Acting

Working Method Straight Trip

Pressure Medium Pressure

Transport Package Wooden box

Specification HD-HSG-160x90x545

Trademark hongda

Origin china

Product title	Tie-Rod Hydraulic Cylinder Balance Hydraulic Cylinder
Product Description	In engineering applications, tie-rod hydraulic cylinders serve as essential components for generating controlled linear force and motion. Comprising a cylindrical barrel, piston, and tie rods that secure both ends, these cylinders are versatile and widely employed in various engineering systems.
Product Name	Double Rod End Double Acting Hydraulic Cylinder
Brand	HongDa Hydraulics
Model Number	HD-HSG-160x90x545
Weight	151Kg
Dimension	1143x234x194
Core Component	piston rod, cylinder barrel, end cap, earrings
Applicable Industries	Engineering Machinery Hydraulic Cylinder
Bore Dia	160 mm/6 in
Rod Dia	90 mm/3.543 in
Stroke	545 mm/21 in
Operating Temperature	-20°~50°
Maximum Working Pressure	28Mpa
Mounting Style	Earrings
Paint	customization acceptable
Working Medium	hydraulic oil

When pressurized hydraulic fluid acts on the piston, it induces linear motion, facilitating tasks such as lifting, pushing, or pulling heavy loads. The tie-rod design allows for straightforward assembly, disassembly, and maintenance, as individual components can be easily replaced. This type of hydraulic cylinder is commonly utilized in engineering equipment, manufacturing machinery, and other systems requiring reliable and precise linear force, contributing to the efficiency and functionality of diverse engineering processes.

Product Tags: hydraulic cylinder , oil cylinder , bidirectional lifting
