18650 3.7v 6.6Ah 1S3P Li Ion Rechargeable Battery Pack With JST-PH2.0 Plug(24.42Wh/6.6A),for Simplehuman Sensor Makeup Mirror ST3026 BT1080

18650 3.7v 6.6Ah 1S3P Li Ion Rechargeable Battery Pack With JST-PH2.0 Plug(24.42Wh/6.6A),for Simplehuman Sensor Makeup Mirror ST3026 BT1080 thumbnail-1
18650 3.7v 6.6Ah 1S3P Li Ion Rechargeable Battery Pack With JST-PH2.0 Plug(24.42Wh/6.6A),for Simplehuman Sensor Makeup Mirror ST3026 BT1080 thumbnail-2
18650 3.7v 6.6Ah 1S3P Li Ion Rechargeable Battery Pack With JST-PH2.0 Plug(24.42Wh/6.6A),for Simplehuman Sensor Makeup Mirror ST3026 BT1080 thumbnail-3
18650 3.7v 6.6Ah 1S3P Li Ion Rechargeable Battery Pack With JST-PH2.0 Plug(24.42Wh/6.6A),for Simplehuman Sensor Makeup Mirror ST3026 BT1080 thumbnail-4
18650 3.7v 6.6Ah 1S3P Li Ion Rechargeable Battery Pack With JST-PH2.0 Plug(24.42Wh/6.6A),for Simplehuman Sensor Makeup Mirror ST3026 BT1080 thumbnail-5
18650 3.7v 6.6Ah 1S3P Li Ion Rechargeable Battery Pack With JST-PH2.0 Plug(24.42Wh/6.6A),for Simplehuman Sensor Makeup Mirror ST3026 BT1080 photo-1
18650 3.7v 6.6Ah 1S3P Li Ion Rechargeable Battery Pack With JST-PH2.0 Plug(24.42Wh/6.6A),for Simplehuman Sensor Makeup Mirror ST3026 BT1080 photo-2
18650 3.7v 6.6Ah 1S3P Li Ion Rechargeable Battery Pack With JST-PH2.0 Plug(24.42Wh/6.6A),for Simplehuman Sensor Makeup Mirror ST3026 BT1080 photo-3
18650 3.7v 6.6Ah 1S3P Li Ion Rechargeable Battery Pack With JST-PH2.0 Plug(24.42Wh/6.6A),for Simplehuman Sensor Makeup Mirror ST3026 BT1080 photo-4
18650 3.7v 6.6Ah 1S3P Li Ion Rechargeable Battery Pack With JST-PH2.0 Plug(24.42Wh/6.6A),for Simplehuman Sensor Makeup Mirror ST3026 BT1080 photo-5
US$ 10.99 2 - 99 Units
US$ 9.99 100 - 499 Units
US$ 8.99 ≥500 Units
Key Specifications
Get Latest Price
Type:
Li-ion Battery
Size:
Small
Cathode Material:
NCM
Contact Supplier Request Quote Chat Now
Xiangyang Battery Electronic Technology Co., LTD.
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
SHENZHEN
Delivery Detail:
7 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Li-ion Battery
Size Small
Cathode Material NCM
Rechargeable Yes
Transport Package cartons
Specification 6.75x5.5x1.84cm
Trademark BETTERYSELER
Origin CN
About this item

  • This lithium ion pack is made of 3 balanced 2200mAh cells for a total of 6600mA capacity! The cells are connected in parallel and spot-welded to a protection circuit that provides over-voltage, under-voltage and over-current protection.

  • The 6600mAh 3.7v battery replacement for Simple human ST3026 sensor makeup mirror, compatible with Simple human ST3027 battery replacement, fits simple human st3028 battery replacement and st3029 battery replacement.

  • The lir18650 3p 3.7v 6600mah comes with a JST 2-pin PH2.0mm plug for use with AKS-APD660-3A charger board high efficiency charger board module to fast charging for the battery pack, fits simple human bt1080 battery replacement.

  • 【PLEASE NOTE】: Before using, please contrast with the old battery and check the polarity of the battery. Red wire connection power positive " +" , Black wire connect power negative pole "-". if is a reversed, you need position of interchange wires. otherwise device will demage.

  • 【POSITION OF INTERCHANGE WIRES】 --- If the polarity of the red and black wires are reversed, you need to exchange the position of the plug wires, You will need to take the wires out of the plastic plug and reverse them only. To do this, take the small blade you own, very gently pry up the two plastic tabs on the top of the plug one at a time, and gently pull the wire out of the plastic plug.( Don't yank!)

  • 【KNOW BEFORE USE 2.】Please make sure our battery max Instantaneous discharge current higher than your device's working current, otherwise battery will cut off work because of overdischarge protection. Also will damage battery if often overdischarge. our battery max Instantaneous discharge current will listi in below sepcification.

1x 3.7V 6600mah battery pack with PH-2Pin 2.0 connector3P PHSpecification:

1. Brand: BETTERYSALER

2. Model: 3.7v-6600mAh

3. Nominal voltage: 3.7v

4.Max discharge current: 8A

5. Capacity: 6600mAh

6. type : Lithium Cobalt Manganese Oxide (Li(NiCoMn)O2)

7. Length : 65.2mm 8. Diameter: 3*18.2mm

position: Three 18650cells paralleled

10.terminal:JST-Ph-2p 2.0 connector, please don't cut the wire if plug incorrect,so you can return,there will be correct plug battery in our shop.

NOTE: These are Three 18650 cells paralleled battery packs ,terminal is 2.0 JST PH-2P connector, wire length 24# wire 10cm. Pay attention The plug is forward when you discharge or charge the battery, incorrect use may cause device catch fire. of course they have protection inside which make it more Safe and convenient for home use. What's more the max discharge rate is 2C ( about 8.8A ), over discharge will damage the battery which will let battery cann't charge full.

Normal capacity 6600mAh(@1C charge)
Minimum capacity 6600mAh(@1C charge)
Normal voltage 3.7V
Charging voltage 4.2+/-0.05V
Discharging ending voltage 2.55 +/-0.05V
Standard charging current 0.5C(charge @3.3A,voltage upto4.2V, stop at end current 0.1A；
Standard discharging current 0.5C(Discharge @3.3A,cut-off 2.55V, capacity 6650mAh) ;
Max Continue discharg current 1C (Discharge @6.6A,cut-off 2.55V, capacity 6600mAh)
Max Instantaneous disc-current 2C (Discharge @12A, cut-off 2.55V,capacity 6540mAh ) ;
Max charge and disch cell °C Charge:0~60°C Discharge:-20~60°C
Internal resistance
Cell dimensions Length: 65.5mm Max , Width: 55.mm Max , Thickness: 18.5mm

Battery Application:

1)Photographic Lighting,

2)Airsoft Gun,

3) Vacuum Cleaner,

4)Drone,

5)Mobility Scooter,

6)Solar Devices

7) LED strip

8) POS machine

9) Electronic scale

10) Battery pack as power supply

11) Charging small fan

12) Digital toy

13) ST3027 Battery Replacement,

ST3028 Battery Replacement,

ST3026 Battery Replacement,

Simplehuman Sensor Makeup Mirror BT1080 Battery Replacement ,

14) Speaker and so on
