1400m3/H Jsd3010 Jet Suction Dredger With Pump for Sea & River Construction *HP
US$ 75,000 - 105,000
MOQ: 1 Combo
Key Specifications
Get Latest Price
Brand Name:
HengPeng
Place of Origin:
China
Model Number:
HP-JSD3010
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao
Delivery Detail:
30 days
Related Products
-
China Origin High-Performance 900m3/H Small Suction Dredger Weichai EngineUS$ 65,000 - 95,000MOQ: 1 Combo -
Efficient Mini Sand Pump Dredger for Quality Water ExcavationUS$ 9,500 - 12,000MOQ: 1 Combo
-
Hengpeng Shipyard 20t Dismountable Amphibious Dredger for Sand MiningUS$ 240,000 - 270,000MOQ: 1 Combo
-
Efficient Water Plant Harvesting Boat Gc16-16*5 From ChinaUS$ 18,000 - 84,000MOQ: 1 Combo
-
Modular Pontoon Excavator Transportation Carrier Barge/Floating Working Platform/Cargo Deck Barge Support Excavator Operate Dredging in Inland River LakeUS$ 100,000 - 350,000MOQ: 1 Combo
Brand Name
HengPeng
Place of Origin
China
Model Number
HP-JSD3010
Type
Other, Jet Suction Dredger
Certification
CCS BV ISO9001 ZC DNV
After-sales Service Provided
Engineers available to service machinery overseas
Warranty
12 Months Free Warranty, Free Repair
Power Type
Diesel
Condition
New
Dredging Depth
10m
Basic Info.
Model NO.
HP-JSD3010
Customized
Customized
Condition
New
Warranty
1 Year
After-sales Service
Lifetime Technical Support
Certification
CE/CCS/Zc/ISO9001
Engine
Weichai/Cumins/Jichai
Mining Object
Sand, Mud, Surry, Sludge, Salt, Iron
Usage
River Sand/Mud Dredging
Discharge Distance
1000m
Dredging Depth
10m
Water Flow Capacity
1400m3/H
Transport Package
in Containers
Specification
HP-JSD3010
Trademark
HengPeng Shipyard
Origin
Qingzhou City, Shandong Province, China
HS Code
89051000
Production Capacity
100sets
Product Description
1400m3/h SOTCK NEW HP-JSD3010 JET SUCTION DREDGER HENG PENG SHIPYARD
We set up Sand Mine Equipment Development Research Institute in 2004, and established good business relationship with the national scientific research institute. At present, there are 5 senior engineers and 12 professional R&D staff members in our company. They can rapidly work out reasonable and feasible plans according to customer requirements. All parts are dimensioned to allow the Jet suction dredger to be transported by road, rail or water. The dredger is equipped with a rapid connection-disconnection system for the pontoons, achieved using bolts at deck level, hull front and rear, and hooks at the bottom. Further salient features of the dredger are the dredger is powered by a Marine engine.
The hull is of all welded, steel construction to give the dredger the necessary strength required for dredging operations.
The hull steel plate used is CCSB (shipbuilding steel plate ).
Main Parameter information:
| Jet Suction Dredger Specs HP-JSD3010 | ||
| Model | Specifications | Remark |
| Overall Length | 24m | |
| Side Pontoon Length | 16m | |
| Breadth | 5.2m | |
| Main engine | kw | Weichai/Cumins/JiChai |
| Generator | kw | Weichai |
| Pump | WN | Shijiazhuang |
| Suction dia | 300mm | |
| Discharge dia | 250mm | |
| Water flow capacity | 1400m3/h | |
| Discharge distance | 1000m | |
| Working weight | 25 Ton | |
| Dredging depth | 1~10m | |
| Operation | Electric System | |
| Steel plate | Bottom:8mm; Side:6mm; Deck:4mm | |
| Transport Package | in Containers | |
| Waranty | 1 Year | |
| Delivery Time | 20-30 Days | |
1.The ship is suitable for construction in closed seas and inland rivers and lakes.
2.The working principle is to use a strong current to make the sediment float and let the sediment pump suck it away through the pipeline.
3.Fan-shaped mud suction operation in front of the bridge, flexible and convenient in-depth and fan operation.
4. Designed in accordance with China Ship Inspection CCS Standard, ZC Standard, and produced in accordance with enterprise standards.
5. The engine and pump are located in the middle main engine compartment, and the side hulls on both sides serve as fuel tanks, ballast tanks, and storage bins. Four ballast tanks are located at the front and rear ends of the side appendage.
6.The whole ship can be disassembled, transported by car or container.
7. Large and bright operating room with air-conditioning and adjustable seats, comfortable working environment.
8. One driver operates all monitoring instruments, light control buttons, and action command buttons.
2.The working principle is to use a strong current to make the sediment float and let the sediment pump suck it away through the pipeline.
3.Fan-shaped mud suction operation in front of the bridge, flexible and convenient in-depth and fan operation.
4. Designed in accordance with China Ship Inspection CCS Standard, ZC Standard, and produced in accordance with enterprise standards.
5. The engine and pump are located in the middle main engine compartment, and the side hulls on both sides serve as fuel tanks, ballast tanks, and storage bins. Four ballast tanks are located at the front and rear ends of the side appendage.
6.The whole ship can be disassembled, transported by car or container.
7. Large and bright operating room with air-conditioning and adjustable seats, comfortable working environment.
8. One driver operates all monitoring instruments, light control buttons, and action command buttons.
HP-JSD3010 Jet Suction Dredger could been transport In container.
